INSTALLATION AND OPERATION INSTRUCTIONS
FOR:
THERMO SUPREMA 18.5
TESTED TO EN 12815: 2001 +A1: 2004
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING, OPERATING OR SERVICING
THIS APPLIANCE.
This appliance must be installed and commissioned by a fully qualified, registered engineer.
ISSUE 08-C
© 2007-2008 Broseley Fires Ltd 1
Advertisement
Table of Contents
Related Manuals for Broseley THERMO SUPREMA 18.5
Summary of Contents for Broseley THERMO SUPREMA 18.5
- Page 1 TESTED TO EN 12815: 2001 +A1: 2004 PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING, OPERATING OR SERVICING THIS APPLIANCE. This appliance must be installed and commissioned by a fully qualified, registered engineer. ISSUE 08-C © 2007-2008 Broseley Fires Ltd 1...
- Page 2 It is important therefore, for appliances to be operated in accordance with our instructions in a manner that maintains a high temperature in the firebox with an adequate supply of air to ensure efficient combustion. A good indication of efficient combustion is a bright lively flame in the firebox. A dull flame or smoldering fire indicates poor or incomplete combustion. To maintain adequate heat in the firebox, it is very important to use dry, well seasoned wood with less than 20% moisture content. The wood must be correctly sized for the particular appliance and it also helps to have at least three or four pieces burning at the one time to assist the combustion process. Adding single pieces of unseasoned or wet wood to a fire will reduce the firebox temperature and prevent adequate combustion. This will result in increased smoke emissions causing the flue and internal components of the appliance to become blocked with tar and creosote more quickly. The tar and creosote deposits in the chimney will fuel a chimney fire. These instructions cover the basic principles to ensure the satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current Building Regulations, Local Authority Byelaws and other specifications or regulations as they affect the installation of the stove. It should be noted that the Building Regulations requirements may be met by adopting the relevant recommendations given in British Standards BS 8303, BS 6461 and BS 7566 as an alternative means to achieve an equivalent level of performance to that obtained following the guidance given in Approved Document J. We recommend that you seek the services of an installer who is conversant with stove installations and Building Regulations. The shop where you purchased the stove should be able to help in this respect. It is our general policy to supply specialist Fireplace shops and these shops can offer an after sales service and offer advice when necessary. Please note that it is a requirement under Broseley Fires Ltd’s warranty system that the installation of the appliance is carried out by a Competent Person registered with a Government approved Competent Persons Scheme. HETAS Ltd operate such a Scheme and a listing of their Registered Competent Persons can be found on their website at www.hetas.co.uk. © 2007-2008 Broseley Fires Ltd 2...
-
Page 3: Table Of Contents
MINIMUM PLUMBING REQUIREMENTS FLUE REQUIREMENTS LINING THE FLUE FLUE TERMINATION PROVISION OF A NOTICE PLATE SITING THE APPLIANCE HEARTH REQUIREMENTS STOVE CLEARANCES ADDITIONAL VENTILATION CHIMNEY FIRE ASSEMBLING THE HANDRAILS ANNUAL SERVICE RECORD LIMITED WARRANTY © 2007-2008 Broseley Fires Ltd 3... -
Page 4: Technical Data
Underneath is a storage draw that is suitable for the storage of cured logs / kindling. The heat is provided by radiation through the glass door and from the hot external surfaces of the stove. © 2007-2008 Broseley Fires Ltd 4... -
Page 5: The 'Air' Controls
As it a high precision device, we recommend you move the dial slowly and with care and never to force it. The damper will close the combustion air entering the appliance when the water temperature gets to 80º © 2007-2008 Broseley Fires Ltd 5... -
Page 6: The Lifting Grate
Ensure that the fire chamber and the crank mechanism are kept clean and well maintained. FIG. 2 © 2007-2008 Broseley Fires Ltd 6... -
Page 7: Fuel Advice
This appliance must be installed and commissioned by a fully qualified, registered engineer. HETAS engineers are recommended by Broseley Fires. For your nearest search www.hetas.co.uk THE SURFACES OF THIS APPLIANCE GET HOT WHEN IN USE. PLEASE ENSURE THAT CHILDREN, THE ELDERLY AND THE INFIRM ARE MADE AWARE OF THIS. -
Page 8: Lighting And Maintaining A Log Fire
If you have no garden, you can dispose of completely cold ash with your household trash. Place it in a tightly closed bag to keep it contained. Always ensure that there are no hot embers left buried in the ash before you transfer it into a flammable bin bag. © 2007-2008 Broseley Fires Ltd 8... -
Page 9: Operating In Transition Periods (Summer
Leaving soot to accumulate inside your appliance will drastically reduce the output of the appliance and prevent it from doing what it is designed to. Ensure that the ash inside every part of the appliance is removed, not just the ash pan. © 2007-2008 Broseley Fires Ltd 9... -
Page 10: G Flue Maintenance
THE APPARATUS MUST NOT BE MODIFIED. ONLY USE SPARE PARTS EXPRESSLY AUTHORISED AND SOLD BY BROSELEY FIRES LTD. CONSULT YOUR LOCAL AUTHORISED DEALER FOR ADVICE. Broseley Fires can supply an exploded drawing of the components that make up the appliance. INSTALLATION OF THE APPLIANCE THIS APPLIANCE MUST BE INSTALLED AND COMMISSIONED BY A FULLY QUALIFIED, REGISTERED ENGINEER. -
Page 11: Lining The Flue
(60°C) the valve opens allowing the hot water to flow throughout the remainder of the system. There are many valves available on the market Broseley Fires recommends the ESBE VTC511 Load Valve 60°C is readily available in the UK and is ideal for this situation. -
Page 12: Flue Termination
The thickness of the wall needs to be at least 75mm • The height of the wall needs to be at least 1.2m above the hearth. PLEASE REFER TO BUILDING REGULATIONS “WALLS ADJACENT TO HEARTHS” For further information on this subject. © 2007-2008 Broseley Fires Ltd 12... -
Page 13: Additional Ventilation
• Please comply with the technical data given in this instruction manual. • Illegal installations are not covered by any sort of guarantee. ASSEMBLING THE HANDRAILS © 2007-2008 Broseley Fires Ltd 13... - Page 14 TECHNICAL DRAWING: THERMO SUPREMA 18.5 REAR VIEW OF APPLIANCE SHOWING POSITION OF THE FLOW AND RETURN CONNECTIONS. (2 off) 1¼ BSP (FEMALE) © 2007-2008 Broseley Fires Ltd 14...
- Page 15 COMPANY NAME: COMPANY ADDRESS: POSTCODE: YEAR SERVICE completion date: SERVICE ENGINEER: . . REG. No. COMPANY NAME: COMPANY ADDRESS: POSTCODE: YEAR SERVICE completion date: SERVICE ENGINEER: . . REG. No. COMPANY NAME: COMPANY ADDRESS: POSTCODE: © 2007-2008 Broseley Fires Ltd 15...
- Page 16 Should you wish to claim under the warranty, please contact the supplier / dealer from whom you purchased the appliance. Do not claim directly to Broseley Fires, as they are unable to process any direct claim from an end user.
