Airius Operating Manual
12/10/06
11:40
Page 1
THE THERMAL EQUALIZER
OPERATING AND INSTALLATION MANUAL
FOR MODELS 10, 15, 25 & 35.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Airius System 10

  • Page 1 Airius Operating Manual 12/10/06 11:40 Page 1 THE THERMAL EQUALIZER OPERATING AND INSTALLATION MANUAL FOR MODELS 10, 15, 25 & 35.
  • Page 2: Technical Information

    RPM (Revolutions Per Minute) and the different RPM produce different rates of air flow to accommodate different heights from which the AIRIUS SYSTEM system will be installed in the ceiling. The heights are identified by the Model Number in Feet (10 feet = 3 Meters)
  • Page 3 East) both offer a refurbish program on all AIRIUS SYSTEMS that are no longer under the one-year warranty. Any AIRIUS SYSTEM unit that is no longer under warranty can be returned to either AIRIUS LLC or AIRIUS Europe Ltd (depending on location) and will be refurbished, or replaced, for one half of the then current end user price of the AIRIUS SYSTEMS as set by AIRIUS LLC or by AIRIUS Europe Ltd (as applicable).
  • Page 4: Exploded View

    T - 20 Torx ( 7 / 64 Hex) 8 - 32 x Pan Head Machine Screw 4 EA The above graphic contains all the descriptions/components of the AIRIUS SYSTEM models 10, 15, 25, 35 Note: ALL SCREW SIZES ARE ENGLISH THREAD with TORX® HEADS ENGLISH SIZED HEX WRENCHS CAN BE SUBSTITUTED TO OPERATE SCREWS 4.
  • Page 5 The AIRIUS SYSTEM use very little AMPERAGE (less than 1 amp) thus multiple outlets may be installed on one circuit. Outlets are available in many configurations, check with the local Electrical Contractor to determine preferred type for the facility.
  • Page 6 5. HANGING THE AIRIUS SYSTEM The AIRIUS SYSTEM is designed to be hung vertically as high in the ceiling of the facility as possible with the nozzle pointing to the floor for maximum thermal equalization.
  • Page 7 - Sketch out the floor plan of the facility, divide it graphically into 1200 sq ft (100 Sq M) squares and as closely as possible place an AIRIUS SYSTEM in the center of each square of the grid. Adjust placement to accommodate.
  • Page 8 AIRIUS SYSTEM where it can get wet or be exposed to long-term moisture. Mounting the AIRIUS SYSTEM in a high sealed sky light is an excellent way of recovering heat. Indoor cranes and other ceiling mounted machinery DO NOT interfere with the function of these machines.
  • Page 9 Page 9 8. THE AIRIUS SYSTEM SAFETY INFORMATION AND WARNING! EACH AIRIUS SYSTEM HAS A POLARIZED/GROUNDED PLUG TO REDUCE THE RISK OF ELECTRICAL SHOCK (NOT FITTED ON UNITS SENT TO EUROPE/MIDDLE EAST - SEE WIRING INSTRUCTIONS). THIS PLUG CAN ONLY FIT INTO THE DESIGNED POLARIZED/GROUNDED OUTLET ONE WAY.
  • Page 10 CAN BE MADE WITH A T-30 TORX DRIVER/WRENCH, OR A 5/32” HEX WRENCH MAY BE USED. OTHER TOOLS - T-20 (7/64 H) & T-25 (1/8 H) TORX. THE AIRIUS SYSTEM IS DESIGNED TO BE USED WITH ONLY THE ELECTRICAL VOLTAGE IDENTIFIED ON THE LABEL. THIS CAN BE LOCATED IN THE NOZZLE AND ON THE BOTTOM OF THE MOTOR, ANY OTHER VOLTAGE COULD DAMAGE THE MOTOR AND CREATE AN ELECTRICAL HAZARD.
  • Page 11 AMMONIAS, ALCOHOLS, OR OTHER CHEMICALS, TO CLEAN ANY PART OF THE AIRIUS SYSTEM THE PERFORMANCE AND RESULTS OF THE AIRIUS SYSTEM® SYSTEM ARE SUBJECT TO MANY VARIABLES SUCH AS, BUT NOT LIMITED TO, THE INTERIOR ENVIRONMENT, EXTERIOR ENVIRONMENT, CONDITION OF BUILDING STRUCTURE, HVAC SYSTEM PERFORMANCE AND/OR ELECTRICAL SERVICE AND THUS ACTUAL RESULTS MAY VERY.
