Summary of Contents for Ferguson egent 10
- Page 1 v1.20 User manual...
-
Page 2: Table Of Contents
Table of contents Downloadable software....................2 GNU/GPL licensing information..................2 User manual........................2 Markings and signs......................3 Basic information about the tablet..................4 1. Prior to first use.....................4 2. Contents of box......................4 3. Tablet parts and connectors..................5 Tablet operation......................7 4. Tablet first use.......................7 5. Basic operation of the Android operating system............8 5.1 Home screen elements..................9 5.2 Applications switching..................10 5.3 Application menu....................10... -
Page 3: Downloadable Software
Ferguson has taken every effort to provide users with software updates in order to ensure that the parameters of the tablet are up to date. Ferguson reserves itself the right to amend, change or modify the software used in the tablet as it shall choose and without prior notification. The http://www.ferguson-digital.eu... -
Page 4: Markings And Signs
When this crossed-out wheeled bin R&TTE Hereby Ferguson Sp. z o.o., declares symbol is attached to a product it that the device is in compliance with means that the product is covered by the essential requirements and other relev- the European Directive 2002/96/EC. -
Page 5: Basic Information About The Tablet
Do not operate the tablet while driving. You may go ahead and use your Ferguson tablet right out of the box, without charging the battery first. If the tablet isn’t switching on right out of the box, the battery is already completely drained and you should of course recharge it first. -
Page 6: Tablet Parts And Connectors
3. Tablet parts and connectors Figure 1 1. touch screen – support soft touch 2. camera for video conferencing... - Page 7 3. buttons quieter / louder 4. ON / OFF button - wake / sleep tablet, press and hold to turn on / off 5. microSDHC card slot 6. HDMI type C - audio-video output to HD TV 7. reset – restore factory defaults 8.
-
Page 8: Tablet Operation
Tablet operation 4. Tablet first use The very first start-up may take a while, approximately 2-3 minutes. When you first power on your tablet (press button ON/OFF Figure 1 point 4), you will be presented the Android Lock Screen. Figure 2 Slide the lock circle to the right (to open lock symbol) to unlock the tablet. -
Page 9: Basic Operation Of The Android Operating System
There is no need for a pen. To move items on the screen, change desktops, etc simply swipe your finger across the screen. Ferguson supports multi-touch so it is possible to zoom in and out with two fingers. In a similar manner, rotation is performed in applications that support it, such as maps, MapaMap. -
Page 10: Home Screen Elements
NOTE: Support for accelerometer and / or change the screen orientation depends on the application. 5.1 Home screen elements Figure 5 1. Search 2. Voice commands 3. Widget (analogue clock) 4. Application and widget menu 5. Application shortcuts Status bar is always displayed at the bottom of the tablet screen. The status bar displays both system information, as well as function keys. -
Page 11: Applications Switching
12.Battery level indicator Other indicators that may appear at the bottom right of the screen, near the indicators 10, 11 and 12: - new mail in the mailbox - airplane mode - USB connection - sound muted - downloading - alarm setup - other information The home screen consists of five pages which can be accessed by swiping the home screen left/right. -
Page 12: Application Menu
Figure 6 Click on a running app in the multitask view to quickly switch to it. You can close running app by long pressing on it and dragging it to the left. 5.3 Application menu Press the app and widget button (Figure 5 point 4) in the top right corner of your home screen: When the system displays the widgets, press "Apps"... -
Page 13: Adding Widgets And Shortcuts To Your Home Screen
Figure 7 Here you can find all the pre-installed programs or “apps” as well as additional apps that you installed. You can launch any app by just pressing the corresponding icon. 5.4 Adding widgets and shortcuts to your home screen To add a widget, press the app and widget button (Figure 5 point 4) in the top right corner of your home screen. -
Page 14: Wifi Configuration
Figure 8 To remove widgets and/or app shortcuts from your home screen, press and hold them and drag them to the trash icon. 5.5 WiFi configuration Press the Settings icon in the home menu or application menu to enter the settings menu. In the settings menu you can find the options to set up your tablet. -
Page 15: Basic Applications
5.6 Basic applications Ferguson tablet comes with pre-installed applications. Below is a brief description of the most important of these applications: Internet - The web-browser for viewing web sites. - Page 16 - Preinstalled default applications (like e.g. the calculator) cannot be uninstalled.
-
Page 17: Connecting Tablet To A Computer
5.7 Connecting tablet to a computer You can connect your tablet to a PC or Mac using the provided USB cable. When connected to a computer, you can access the tablet internal memory and, if present, an inserted microSDHC card as standard USB Mass Storage Device. Connect the USB cable to the USB port of your tablet and to a free USB port on your computer. -
Page 18: Connect The Tablet To A Tv
6 Connect the tablet to a TV Ferguson Tablet can connect to HD TV via HDMI cable (type C) – HDMI (type A) • HDMI (type C) – HDMI (type A) adapter and standard HDMI (type A) cable • These accessories are not included with the tablet! -
Page 19: Factory Reset
7 Factory reset You can restore tablet to the factory state. Press in menu „Settings” > „Backup & reset” option „Factory data reset” or Reset switch on the panel. NOTE: Restoring the factory default settings will erase all stored settings, user accounts and install by user applications. -
Page 20: Glossary Of Terms
Glossary of terms and signal receivers. The purpose of the system is to provide the user with information about the position and to facilitate the navigation area. Android operating system for mobile devices such as mobile phones, smartphones and Aspect ratio: The ratio of vertical and tablets. -
Page 21: Specification
Specification Main features screen capacitive, multitouch resolution 1280x800 10.1'' IPS processor dualcore Rockchip RK3066 1.6GHz Cortex A9, ARMv7 Processor (VFPv3, NEON) SDRAM memory 1024 MiB DDR3 Android 4.1 preinstalled 2D/3D Quadcore Mali-400 MP acceleration OpenGL ES 2.0 internal storage 16GB Nand flash WiFi IEEE 802.11 b/g/n Cameras...
