Page 1: Service Manual
COLOR TV SERVICE MANUAL CHASSIS : MC-022A MODEL:CT-29M30V/R/RX CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. -
Page 2: Table Of Contents
CONTENTS Contents ......................... 2 Safety Precautions ....................3 Specifications ..................... 4 Control Descriptions ..................5 Disassembly Instructions ................8 Adjustment Instructions ................9 Block Diagram ....................16 T rouble Shooting ....................18 Exploded View ....................22 Exploded View Parts List ................23 Replacement Parts List ................ -
Page 3: Safety Precautions
SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards. -
Page 4: Specifications
SPECIFICA TIONS Note : Specification and others are subject to change without notice for improvement. Video input system: PAL-B/G, D/K, I/I SOUND IF : 33.4MHz (B/G) SECAM-B/G, D/K/L/L’ 32.9MHz (I/I) NTSC M 32.4MHz (D/K,L) NTSC 4.43(AV) 34.4MHz (M) NTSC- M/PAL M-N 40.4MHz (L’) Intermediate Frequency (Unit : MHz) VISION IF : 38.9MHz,33.9MHz(SECAM-L’) -
Page 5: Control Descriptions
I/II LIST adjusts menu settings. SLEEP EYE/ 6. VCR BUTTONS (option) TEXT Q.VIEW control a LG video cassette recorder. 7. SSM (Sound Status Memory) TIME recalls your preferred sound setting. REVEAL MODE SIZE STILL POSITION 9/4 PIP 8. - Page 6 14. OK accepts your selection or displays the current mode. 15. LIST POWER displays the programme table. MUTE 16. EYE/ (option) switches the eye function on or off. 17. SLEEP sets the sleep timer. TV/AV 18. Q.VIEW returns to the previously viewed programme. MENU SOUND PICTURE...
-
Page 7: Front Panel
Front panel RF/RT-25/29CA40 series CF/CT-29K30 series MENU ON/OFF VIDEO L/MONO AUDIO TV/AV ON/OFF 1 2 6 7 8 9 CF/CT-29M30 series TV/AV ON/OFF VIDEO 7 8 9 MONO AUDIO (Function) 1. MAIN POWER selects volume, EYE (option), picture items or brief switches the set on or off. -
Page 8: Disassembly Instructions
DISASSEMBLY INSTRUCTIONS Important note Chassis Assy Removal This set is disconnected from the power supply through the Grasp both side of Frame and pull it backward smoothly. converter transformer. An isolating transformer is necessary for service operations on the primary side of the converter transformer. -
Page 9: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS 1. Safety Precautions 5. Screen Voltage & White Balance Adjustment 1. It is safe to adjust after using insulating transformer between 5-1. Adjustment of screen manually the power supply line and chassis input to prevent the risk of (Using ADJ.Remote Control) electric shock and protect the instrument. - Page 10 Adjust so that middle portion of the outermost left and right vertical line looks like parallel with vertical lines of the CPT. NOTE : If production line doesn’t the production line of LG TV,receive available deflection adjustment pattern. EC (East-west Coner) Adjust so that the vertical line at every 4 corners of the screen 6-2.
- Page 11 25/29” LG FLAT CPT(CT-25Q20RB) 29” S/S SEB FLAT CPT ITEM Z50Hz ITEM RANGE N50Hz W50Hz RANGE N50Hz Z50Hz W50Hz 0050~00CF 009A 0050~00CF 00A3 0025~00BF 00F3 0025~00BF 00F5 0000~009F 00D0 0000~009F 00D0 0600~0900 0774 0600~0900 0744 0000~003F 0019 0000~003F 0016 0400~0EFF...
- Page 12 00FD 00FD 00F8 00FD 00F9 7. SVC Data & PSM,SSM Data. PICTURE SETTING DATA (LINE SVC-3) 28” FLAT Menu Range 25/29” LG Flat 29” S/S-Flat 25” FST 28” FST 29” FST DVCO(Digital VCO) IBRM(BLACK CURRENT) 0~1FFH 00C8 00C8 00C8 00C8...
- Page 13 8-3. OPTION 1 Function 8-5. OPTION 3 Function Option Code Function Remark Function Option Code Remark 4:3 NORMAL MODEL TXT Model W/O GAME WIDE GAME WIDE FLAT MODEL W/O TXT Model GAME PACK GAME(HINDI MICOM) W/O TOP(FLOP BASIC) FORCED MONO NOT SETTING MONO WITH TOP FORCED MONO SETTING...
- Page 14 8-7. OPTION 4 Function OPTION CODE FUNTION Arab.Asia English Only(Eng.) 3834 Arab(Eng/Fr/Arab) Urdu(Eng/Fr/Arab/Urdu) Asia(Eng/Fr/Indonesia) Farsi English Only(Eng.) 3834 Arab(Eng/Fr/Arab) Farsi(Eng/Fr/Arab/Farsi) Arab-Asia English Only(Eng.) 3804 Arab(Eng/Fr/Arab) LANG. Urdu(Eng/Fr/Arab/Urdu) Arab all(Eng/Fr/Arab/Urdu/Farsi) Farsi ONly(Eng/Farsi) Asia(Eng/Fr/Indonesia/Malay) WEST-EU English Only(Eng.) 3834 Only(W/TXT) EU-7(E.Ger/Fr/Ita/Spain/Holand/Port) EU-NORTH(E-Ger/Fr/Holand/Swe/Nor/Den/Fin) EAST-EU English Only(Eng.) 3834 Only(W/TXT) Cyrilic(E.Russia)
- Page 15 OPTION CODE FUNTION Farsi only WEST-EU 3834 only(W/TXT) EAST-EU Turkey Cyrillic3 Arab/English Farsi/English TXT-L Arab-Asia WEST-EU 3834 only(W/TXT) EAST-EU Turkey Cyrillic3 Arab/English WEST EU WEST-EU 3834 only(W/TXT) EAST-EU Turkey Cyrillic3 EAST EU WEST-EU 3834 only(W/TXT) EAST-EU Turkey Cyrillic3 28” WIDE FLAT WEST-EU 3834 only(W/TXT) EAST-EU...
-
Page 16: Block Diagram
BLOCK DIAGRAM - 16 -... - Page 17 - 17 -...
-
Page 18: Trouble Shooting
TROUBLE SHOOTING RF- STEREO Selected correct system In menu Check the waveform Check / Replace At pin 17 of TU101 TU 101 Check the waveform Check The Voltage Check The voltage At pin 24,25 of IC661 At pin 16,33,46, of IC661 At pin of IC610, IC853 Check the waveform Check / Replace... - Page 19 NO RASTER CHECK B+ At D807 cathode Normal Abnormal Open Is the voltage at Check Pin 25, 54 of IC01 3.3V? Fuse of AC line Check / Replace Fuse , DB801 Check the In/out of Check pin 24 Check the Voltage IC06, IC07 Of IC01(H - Out) Of C804...
- Page 20 No Picture / No Sound Is any OSD displayed? Check receiving system in MENU Check IC01 pin37,42,43,44 & execute Auto - Program. (IK, R,G,B) Does the auto - Program Operate properly. Check / Replace IC01 Store on manual - program MENU Check Check 5V, 33V &...
- Page 21 AV Stereo Select correct system In menu Check the connection Of AV equipment Check the the waveform At pin47 of IC661 Check TU101 Tuner Check the voltage Check the waveform Of pin16,20 At pin 24, 25, of IC661 Check waveform Check / Replace At pin 4, 12 of IC602 IC602...
-
Page 22: Exploded View
EXPLODED VIEW P801 - 22 -... -
Page 23: Exploded View Parts List
The components identified by mark critical for safety. EXPLODED VIEW PARTS LIST Replace only with part number specified. LOCA. NO PART NO DESCRIPTIONS 6341V29002G CPT ASSY PAII+S/CHANG DY., NOR 6341V29002H CPT ASSY PAII+S/CHANG DY 2426GF120CF CPT SET 120-C77G SPEAKER,FULLRANGE C122P02K1459 8 OHM 1 4810V00088A BRACKET,SPEAKER 6140VC2001R... -
Page 24: Replacement Parts List
REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION D862 0DD420000BB DIODE,D4L20U SHINDENGEN DIODE,1N4148 TA D863 0DD414809ED IC01 0ICTMMN015A IC,VCT3804F LG10 M/F/A 0DD414809ED DIODE,1N4148 TA D864 “ 0ICTMMN014A IC,VCT3804B LG12 EUROPE D865 0DS113379BA DIODE,SWITCHING 1SS133 T-72 TP 0ICTMMN004B IC,VCT3834B LG24 E/EU “... - Page 25 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 26 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 27 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 28 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 29 220 OHM 1/2 W 5.00% TA52 R1231 0RD2200H609 220 OHM 1/2 W 5.00% TA52 SWITCH SW01 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V SW02 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V SW03 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V SW04 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V...
- Page 30 P/NO:3854VA0098A-S(1/2) 2002.03.25...
- Page 31 PRINTED CIRCUIT BOARD COMPONENT LOCATION GUIDE P/N: 3854VA0098A-S(2/2) DATE: 2002.03.25 C01 ..B4 C402 ..G4 C806..F2 F854..E3 G70 ..E2 J160 ..C4 J251 ..D5 J345 ..A3 Q110 ..B5 R140 ..A5 R526 ..C4 R908 ..A1 C02 ..B4 C403 ..G3 C807..F3 F855..D2 G71 ..E2 J161 ..C3 J252 ..D3 J346 ..E2...
-
Page 32: Svc. Sheet
SVC. SHEET : 3854V A0098A-S SVC. SHEET :... - Page 33 Jan.,2003 P/NO : 3828VD0118Q Printed in Korea...
