Thank you for buying the GSM alarm system EVOLVE Sonix.
WARNING!
This product uses the most modern technology, yet you cannot depend only on it at protecting your property.
So, please, pay attention to the points mentioned below. The producer, importer and sellers aren´t responsible
for any damage on the property, direct or indirect that could have occurred in connection with using this
product, and it´s not possible to exact any compensation for potential damage from them.
- The product is suitable as an additional securing of your property (house, flat, cottage, garage, garden
house, caravan, and so on)
- It is always recommended to use another system of securing and/or to have the particular property insured
- The product isn´t a professional security system and it is not possible to consider it unreserved instrument for
securing the property
- For the right function of the product it is recommended to check it and test it by yourself at least once a
quarter (the batteries state, the sensors and remote controls functionality, the messages sending functionality,
the central drive functionality and others)
- Do not forget to place the individual parts of the alarm system correctly; the installation and connection is
convenient to entrust to the specialized technician
Main unit
Remote control
User guide
EVOLVE Sonix
Wireless GSM alarm
PIR sensor
Door / window sensor
Mini siren
42
Loudspeaker
Power supply
Advertisement
Related Manuals for Abacus Electric Evolve Sonix
Summary of Contents for Abacus Electric Evolve Sonix
- Page 1 User guide EVOLVE Sonix Wireless GSM alarm Thank you for buying the GSM alarm system EVOLVE Sonix. WARNING! This product uses the most modern technology, yet you cannot depend only on it at protecting your property. So, please, pay attention to the points mentioned below. The producer, importer and sellers aren´t responsible for any damage on the property, direct or indirect that could have occurred in connection with using this product, and it´s not possible to exact any compensation for potential damage from them.
- Page 2 Put the main alarm drive to the safe place so you prevent the manipulation. DO NOT PUT it to the metal cupboard, the radio signal wouldn´t get through the metal. The window/door sensor: insert the battery into the part „A“. The magnetic sensor sends the signal to the central drive if the two parts move away from each other to more than 2 –...
- Page 3 alarm. You can get connected to the main drive by dialling or sending the SMS and program it by manual inserting the telephone numbers. 4. Connecting the siren to the alarm Connect the black wire to the grounding (GND) and the red wire to the siren. Black ...
- Page 4 The outputs with the open collector can be used directly if the device permits it, or they can control the relay. Connect the antiparalel diode to the relay coil. These outputs can be controlled only by the telephone commands or the SMS messages. Notes to the cabling: for controlling the household appliances The control box has four conductors: - Two yellow conductors AC for connecting to the household appliances...
- Page 5 - POWER: the alarm power supply. How to set up the telephone numbers and SMS in the device? EVOLVE Sonix is possible to control comfortably also using your smartphone: - Android – EVOLVE Sonix (Google Play) - iPhone – EVOLVE Sonix (App Store) You can set 5 groups of the telephone numbers and 7 SMS types by sending the message into the alarm.
- Page 6 - 123456#81#The front window opened# will save the fourth SMS message that is sent after connecting the fourth wireless detector - 123456#81#The back window opened# will save the fifth SMS message that is sent after connecting the fifth wireless detector - 123456#81#The middle window opened# will save the sixth SMS message that is sent after connecting the sixth wireless detector - 123456#81#The attic entrance opened# will save the seventh SMS message that is sent after...
- Page 7 1#0# Deactivation* (all the sensors don´t work) Switching on the warning tone for the Switching off the warning tone for the 21#1# 21#0# activation of the external alarm activation of the external alarm Switching on the warning tone for the Switching off the warning tone for the 22#1# 22#0#...
- Page 8 Note: a. The symbol ‘ * ’ in the table mentioned above means the standard setting. b. One beep at the telephone operations mentioned above means that the input was right; the long beep means that the sentence was input successfully and two short beeps mean that the input has failed and it is necessary to try it again.
- Page 9 B) Adding the sensors in the inner protective zone (the sensors in this zone work when the mode Full activation is active; if the alarm is in the mode Partial activation the inner sensors don´t work): When you activate the GSM module the LED warning light on the device will temporarily go red. Press the button “reset”...
-
Page 10: Troubleshooting
2200 DECLARATION OF CONFORMITY: Hereby, the company ABACUS Electric s. r. o. declares that this model EVOLVE Sonix is in compliance with the requirements of the norms and regulations, relevant for the given type of device. The complete text of Declaration of conformity can be found at ftp://ftp.evolve-europe.com/ce/.
