Summary of Contents for Hong Kong Easyweld Cut-40
- Page 1 EasyCut Cut-40/60/100 Plasma Cutters Operation Manual Hong Kong EasyWeld Limited...
-
Page 2: Warranty
Introduction The EasyCut series plasma cutter is a revolutionary new approach to plasma cutting technology. Easyweld introduced a more efficient way to cut metal while keeping the cost of operation lower. This was accomplished using several new approaches to the mainstream technology. One of these methods is our proprietary plug-and-play... -
Page 3: Safety Tips
Safety tips With the machine in use, do not switch the machine off or it ● will damage the internal circuitry. Make sure your circuit breaker can handle the required ● amperage draw of your machine. Use a UL approved outlet/receptacle and plug with your ●... -
Page 4: Main Specifications
MAIN SPECIFICATIONS EasyCut 40 EasyCut 60 EasyCut l00 Model Input Voltage (V) AC220V 380VAC 380VAC 50/60Hz Cut Capacity max/serve 0.5/0.75 1/1.5 Input KVA / AMPS 6/17 9/31 No—load voltage (V) Current range (A) 10~40 20~60 20~100 Rated output voltage (V) Rated duty cycle (%) Efficiency Power factor case... - Page 5 Pilot Lamp Compress Air Power Lamp Gas Regulator Power Lamp Power Switch Pilot Lamp Main Current Torch Connection Torch Ground Ground Connection Trigger Trigger Connection Connection Socket Socket Main Current Pilot Lamp Current Meter Power Switch Torch Connection Ground Trigger Pilot Arc Connection Socket...
-
Page 6: Installation
INSTALLATION Connecting the Power Cord Plug You will need to go to a hardware store to locate an electrical plug designed for your outlet. The machine requires either 110v/220vac at a specified amperage rating. Locate a plug rated at the correct voltage and amp rating your machine requires. - Page 7 If your machine comes with an air regulator/filter you will need to secure the bracket to the machine and then fasten the regulator to the bracket. Locate the in and out labeled on the regulator body. Cut a section of hose long enough to bend around the back of the machine as pictured and secure it to the outlet on the regulator and the inlet to the machine.
- Page 8 The assembly of the consumables is as pictured. The electrode is inserted in first, then seat the ring on the electrode. The copper tip should be placed on the ring and it should seat well and flat. Last you will secure all parts in place by turning the ceramic cup clockwise until it is snug.
-
Page 9: Operation
OPERATION 1. Plug the machine to the electrical outlet, first making sure the machine on/off switch is in the off position. 2. Connect the air compressor supply line to the input side of the air regulator/filter (if applicable). 3. Turn the on/off switch of your cutter to the ON position. The cooling fan(s) should come on and the ON indicator LED (if applicable) should come on. - Page 10 EasyCut 40 Cutting Guideline Table Steel, Stainless Steel, MOLY, Iron, etc. Aluminum, Copper, Brass, etc. Thin = 0-1/8” Thin = 0-1/16” Medium = 1/8”-3/8” Medium = 1/16”-3/16” Thick = 3/8”-1/2” Thick = 3/16”-3/8” Severance cut = 3/4” Severance cut = 9/16” When cutting thin material, you may start directly perpendicular to the work piece, there is no need to angle or start on the edge as the arc will pass through quickly.
- Page 11 Real lime arc curve delay issues Cutting Direction Real time arc curve delay When cutting thick materials you will need to keep a steady pace in the direction of your cut. Do not move the torch too quickly or you will experience an arc curve delay.
-
Page 12: Maintenance
MAINTENANCE 1. Clear dust that may accumulate in the machine at regular intervals with clean and dry compressed air; if the working condition has heavy smoke and pollution, the welding machine should be cleaned once a month. 2. Keep the machine exterior clean with mild soap and water. 3. - Page 13 EasyCut 40 Problems and Solutions Breakdown Solution The power switch is in Over-voltage protection, turns off the machine the ON position but fan for a while, and then restarts it. Simply wait does not turn on and 3-10 minutes. Or the power cord is connected machine doesn’t work.
- Page 14 EasyCut 60/100 Problems and Solutions Breakdown Solution 1. The assistant transformer on Power switch is turned on but no the control board is broken. activity, no fan and no lights. 2. The power input wires are not connected properly. 3. Wires or connectors have come loose inside the machine.
