Creda J051E Installation & User's Instructions

Installation & User Instructions
Jackson is a registered trademark of
General Domestic Appliances LTD.
You must read these instructions prior to using the
appliance and retain them for future reference.
For more information on our exciting product range ring
Creda Answer Centre 08701 54 64 74
Visit us on the NET at
http://www.creda.co.uk
Our site invites you to make use of our interactive cookbook and
product selector. Feel free to browse our product range to see
what's bubbling away at the moment or to ask for help on our
products and services
General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB
Creda Answer Centre 08701 54 64 74
Web http://www.creda.co.uk
It may be necessary from time to time to change the specification
outlined in this booklet without notice. Any change which is made
will not affect your statutory rights.
Your new appliance is guaranteed* and will give lasting service. This
guarantee is only applicable if the appliance has been installed in
accordance with the installation instructions detailed in this booklet.
To help make best use of your cooking equipment, please read this
booklet carefully.
The cooker is designed specifically for domestic use and responsibility
will not be accepted for use in any other installation.
When the cooker is first used an odour may be
emitted, this will cease after a period of use.
When first using the cooker ensure that the room is well ventilated
(e.g. open a window or use an extractor fan) and that persons who
may be sensitive to the odour avoid any fumes. It is suggested that
any pets be removed from the room until the smell has ceased. This
odour is due to temporary finish on oven liners and elements and also
any moisture absorbed by the insulation.
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users
Instruction Book.
(b) Has been properly connected to a suitable supply
voltage as stated on the rating plate attached to
this equipment.
(c) Has not been subjected to misuse or accident or
been modified or repaired by any person other
than the authorised employee or agent.
(d) Has been correctly installed.
J051E
OR
Installation
WARNING – THIS APPLIANCE MUST BE EARTHED.
Your cooker should have been checked to ensure
that the voltage corresponds with your supply
voltage, this is stated on the rating plate, which is
situated on the rear panel. The cooker must be
connected by a competent person eg, NICEIC
registered contractor to suitable double-pole
control unit with a minimum rating of 32A and a
minimum contact clearance of 3mm, which
should be fitted adjacent to the cooker, in
accordance with IEE regulations.
The power supply cable should conform to
B.S.6004 with a conductor size of 6mm
minimum.
The control unit should be easily accessible in the
event of an emergency, but must be within 2
metres of and not directly above an appliance.
This appliance conforms to EN 55014 regarding
suppression of radio and television interference.
Access to the mains terminals is gained by
removing the rear access cover.
The mains cable must pass through the cable
clamp adjacent to the terminal block. Sufficient
cable should be used to allow the cooker to be
pulled out for servicing.
Ensure that the mains cable is routed away from
any brackets affixed to the rear panel and is not
trapped to the rear wall when pushing the cooker
into position between cabinets.
The height of the cooker can be adjusted by
means of adjustable feet in the plinth (900mm -
915mm). Adjust the feet by tilting the cooker
from the side. Then install the product into
position.
Siting the Cooker
The cooker is designed to fit between kitchen
cabinets spaced 500mm apart. The space either
side need only be sufficient to allow withdrawal
of the cooker for servicing. It can be used with
cabinets one side or both as well as in an angled
corner setting. It can also be used free-standing.
This cooker is a type X appliance, as such adjacent
side walls which project above hob level, must
not be nearer to the cooker than 150mm and
should be protected by heat resistant material.
Any overhanging surface or cooker hood should
not be nearer than 650mm.
Disposal of your product
To minimise the risk of injury to children please dispose of your
product carefully and safely. Remove all doors and lids. Remove the
mains cable (where fitted) by cutting off flush with the appliance and
always ensure that no plug is left in a condition where it could be
connected to the electricity supply.
To help the environment, Local Authority instructions should be
followed for the disposal of you product.

Moving the Cooker

Before moving your cooker, switch off at the cooker control unit, ensure
that it is cool.
Movement of your cooker is most easily achieved by lifting the front as
follows:
Open the oven/grill door sufficiently to allow a comfortable grip on the
underside front edge of the oven roof, avoiding any grill elements or
oven interior furniture.
Note: Take care in moving the cooker as it is heavy.
Take care to ensure that any floor covering is not damaged.
Splash panel kit (wall mounted) optional, apply to Creda Parts
Department.
2
