User's Manual
ACC-ECU3
USB 3.0 ExpressCard

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACC-ECU3 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMagic ACC-ECU3

  • Page 1 User’s Manual ACC-ECU3 USB 3.0 ExpressCard...
  • Page 2 ABOUT THIS MANUAL This manual is designed for use with the USB 3.0 ExpressCard. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any commercial damage, including but not limited to...

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction ........................3 Features........................... 4 Package Contents ......................4 System Requirements...................... 4 2. Installation ........................5 Windows XP/ Vista/ 7....................... 5 3. Hardware Installation ....................9 4. Installation Verification ....................12 5. Notice ........................... 12 6. Specifications ......................13 7.

  • Page 4: Introduction

    1. Introduction The USB 3.0 ExpressCard is compliant to USB 3.0 standards and backward compatible with USB 2.0 devices. It also allows you to connect multiple peripherals to your PC at the same time. The USB 3.0 2-Port ExpressCard enhances the performance of transmission that excessively faster than existing USB 2.0 devices.

  • Page 5: Features

    Features  Add 2 ports to USB 3.0 devices.  Install easily into any ExpressCard slots of laptops.  Supports USB 3.0 transfer rate.  Plug and play. Package Contents  USB 3.0 ExpressCard  CD (Driver and User’s Manual) ...

  • Page 6: Installation

    2. Installation You will need to install the driver for your USB 3.0 ExpressCard first. Please follow the procedures as below. On Windows XP/ Vista/ 7 To Install the Driver: 1. Insert the provided CD into CD-Rom locates and double-click the Setup.exe file.
  • Page 7 After reading End-User License Agreement, please choose “I accept the terms in the License Agreement” and click Next. Please click Browse to choose the Destination Folder. After that, please click Next.
  • Page 8 Click Install to install NEC Electronics USB 3.0 Host Controller Driver. 6. It will take a while to install the driver.
  • Page 9 7. Please click Finish to complete the NEC Electronics USB 3.0 Host Controller Driver. *Actual strings depend on your operation system. These screen shots are from Windows 7 and might vary slightly for each operation system.

  • Page 10: Hardware Installation

    3. Hardware Installation Please find the CardBus port of your system, and insert the USB 3.0 2 Ports ExpressCard into the port. The USB 3.0 2 Ports CardBus Card supports hot-swapping, so you don’t need to turn off your system before the installation. For Window XP: A.
  • Page 11 B. Please choose “Install the software automatically” and click Next. C. Please click Finish to complete the Found New Hardware Wizard. *Actual strings depend on your operation system. These screen shots are from Windows XP and might vary slightly for each operation system Notice: The Installation of Found New Hardware Wizard will show up twice, please follow the above steps to complete the installation.

  • Page 12: Installation Verification

    4. Installation Verification After finishing driver installation and plugging this ExpressCard to PC, the system will detect the device. You can go to Device Manager to verify the entire installation. Windows XP...

  • Page 13: Notice

    Windows Vista/ Windows 7 5. Notice:  The Power Adapter is recommended to use for high power consumption devices.

  • Page 14: Specifications

    6. Specification  Compliant with Universal Serial Bus 3.0 Specification Revision 1.0.  Supports the following speed data rate as follows; Low-speed (1.5 Mbps)/ Full-speed (12 Mbps)/ High-speed (480 Mbps)/ Super-speed (5 Gbps).  Supports 2 downstream ports for all levels of speed. ...

  • Page 15: Regulatory Compliance

    7. Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received. Including interference that may cause undesired operation.
