Citizen ANO Instruction Manual

CITIZEN QUARTZ
ANALOG
CHRONOGRAPH
Caliber No. 0510, 0540, 0560
CTZ-P6746
MODEL No. ANO
AN1
• INSTRUCTION MANUAL
• Before Using The Watch
Confirm the Caliber No. of your watch by the stamp
on its case back as shown below.
This instruction manual explains how to use
Calibers: 0510, 0540 and 0560.
• Main Components
• Setting the Watch
0510 0540
1. Wait till small second hand is on "0" sec, then
crown to position (2) it stops the small second
hand.
2. Turn the crown to set the minute/hour hands to
the desired time. *The 24-hour hand 4 is
synchronised with the hour hand (0540). Use the
24-hour time display as a reference to confirm
a.m. and p.m. setting.
3. To start the small second hand, push the crown
back to position (0). *Reduction of power
consumption: crown at (2) movement stop.
0560
1. When the crown is pulled out in position (2), the
C.G 1/20 second hand 3 is instantaneously
returned to "0" position.
2. Turn the crown to set the minute/hour hands to
the desired time.
3. To start the C.G 1/20 second hand by one step
moving, push the crown back to position (0).
*Reduction of power consumption: crown at (2)
movement stop.
• Setting the Date
0510 0540 0560
1. Pull out the crown to position (1).
2. Turn the crown till the desired date appears.
*Do not set the date between 9:00 p.m. and
1:00 a.m. otherwise the date may not change
properly.
3. Push the crown back to position (0) after setting
the date.
