Page 2
With hinge held firmly in place, mark all hole locations on frame using center punch. Drill all holes as in step 1. Attach hinge leaf to door using fasteners provided and #3 phillips drive. See screw chart below. Note: Fasten top screw first, and bottom most screw second, making sure hinge is aligned correctly.
