Prologix GPIB-USB Controller User Manual

8.19. trg

This command issues Group Execute Trigger GPIB command to devices at the
specified addresses. Up to 15 addresses maybe specified. Addresses must be separated by
spaces. If no address is specified then Group Execute Trigger command is issued to the
currently addressed instrument (as set by a previous ++addr command). Refer to the
programming manual for a specific instrument's response to Group Execute Trigger
command.
SYNTAX: ++trg [<PAD1> [<SAD1>] <PAD2> [SAD2] ... <PAD15> [<SAD15>]]
MODES AVAILABLE: CONTROLLER

8.20. ver

This command returns the version string of the Prologix GPIB-USB controller.
SYNTAX: ++ver
MODES AVAILABLE: CONTROLLER, DEVICE

8.21. help

This command prints a brief summary of all available commands.
SYNTAX: ++help
MODES AVAILABLE: CONTROLLER, DEVICE

9. Specifications

Supported OS: Windows 98/2000/XP/Vista, Mac OS 8/9/X, Linux, FreeBSD
Supported Standards: IEEE 488.1, IEEE 488.2, USB 1.1, USB 2.0
GPIB commands not supported: PARALLEL POLL, PASS CONTROL
Power: USB bus powered, +5V, 100 mA (max)
Supported USB hubs: Self-powered and Bus-powered hubs
Indicators: TALK, LISTEN
Dimensions: 2.5 in. (L) x 2.5 in. (W) x 1.0 in. (H)
Weight: 3 oz.
Many thanks to Gerry Glauser for comprehensively reviewing this manual and suggesting several
improvements!
4/19/2011 15
