Summary of Contents for Monster Cable 3-Way
- Page 1 U SER GUI DE & WARRANTY Advanced 3-Way Switcher for HDMI ™...
-
Page 3: A Note From The Head Monster
A NOTE FROM THE HEAD MONSTER Dear Enthusiast, THANK YOU for purchasing the Monster Cable Advanced 3-Way Advanced 3-Way ® ® ® Switcher for HDMI . Our switcher allows ™ you to instantly connect three additional 1080p high defi nition sources to your HDTV and control them with your existing universal remote. - Page 4 1000 HD for HDMI Cable Ultra-high speed digital video and audio cable for the sharpest picture, deepest color, and highest resolution sound. For more details on all of our Monster Cable products, visit us at MonsterCable.com...
-
Page 5: Package Contents
Package Contents Advanced 3-Way Switcher for HDMI (1) External Low-Noise Power Supply (1) Mountable External Infrared Receiver (1) Mountable External External Low-Noise Infrared Receiver Power Supply 3-Way (3-In 1-Out) Advanced Switcher for HDMI... -
Page 6: Specifications
Specifi cations: • Signal Output ...............4.95 Gbps • Power Consumption (Max.) ..........1.0 W • Power Supply ..100~240V AC (50/60 Hz), 5V DC/0.5A • Video Resolution ..........Up to 1080p • HDMI Input/Output Connector ........Type A • Dimensions (H x W x D) ..179x80x177mm with stand •... - Page 7 Connecting the Advanced 3-Way Switcher Orient the switcher vertically or horizontally, based on your available space. Insert the power supply’s DC adapter into the switcher’s DC 5V input. Next, insert the power supply’s two-prong plug into a standard AC outlet. The INPUT...
- Page 8 Using Monster Advanced for HDMI Cables, connect up to three HDMI devices (DVD player, cable/satellite receiver, PLAYSTATION 3) to the HDMI inputs on the switcher. 3) to the HDMI inputs on the switcher. ® ® ® ������� ��������� �����...
- Page 9 Connect another Monster Cable for HDMI to the switcher’s output. Attach this cable to an HDMI input on your HDTV or monitor. ������� ���� ������ ��������� �����...
- Page 10 Attaching the Mountable External Infrared Receiver The Advanced 3-Way Switcher features an external IR receiver, allowing you to hide it from view, but still maintain full remote control. Place the switcher in the desired location. Select a location with convenient access to an AC outlet.
- Page 11 Switching HDMI Components Manually Press the INPUT 1, INPUT 2, or INPUT 3 button on the switcher to select that input’s connected component. Switching HDMI Components with a Universal Remote Control The switcher has a “learn” mode, which allows the unit to automatically learn your remote control.
- Page 12 Press the LEARN button. The LEARN indicator will illuminate. When the LEARN indicator lights up, press the INPUT 1 button. The INPUT 1 indicator will illuminate. Point your remote control (not supplied) at the switcher’s internal sensor, or the mounted external receiver, and press the button on your remote that matches the component connected to INPUT 1.
- Page 13 ����� ������ �������� ������ ������ Congratulations, you’ve successfuly installed your Advanced 3-Way Switcher. Visit us at MonsterCable.com/HDMI to fi nd more great Monster Advanced for HDMI products that deliver the best in high defi nition home theater.
- Page 14 FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. 3-Way Advanced Product HDMI Switcher Model HDMI SWC-3...
-
Page 15: Limited Warranty For Consumers
LIMITED WARRANTY FOR CONSUMERS Monster Cable Products, Inc., 455 Valley Drive, Brisbane, CA 94005, USA, (415) 840- 2000 (“Monster”) extends You this Limited Warranty. Statutory or common law may provide You with additional rights or remedies, which shall not be aff ected by this Limited Warranty. - Page 16 transferred ownership of the Product, whichever occurs earlier. Also, You must call Monster and obtain a Return Authorization Number (as described under “How to Make a Claim”) within two (2) months after You discover a Product Defect (or should have discovered it, if such Product Defect was obvious).
- Page 17 (30) days after receipt of Your Formal Warranty Claim (if You reside in the United States - forty-fi ve (45) days if You reside elsewhere), unless obstacles outside Monster’s control delay the process. Ver.062706 – US ©2003-2007 Monster Cable Products, Inc.
- Page 19 1-877-800-8989 7-800-8989 Monster, Monster Cable, the MC logo, the Certifi ed 1080p logo and the High Speed logo, the product and packaging are trademarks or registered trademarks of Monster Cable Products, Inc. or its subsidiaries in the U.S. and other countries.
