  • Page 1 TSR750 User's Manual Comfortable use with touch screen...

  • Page 3: Safety Precautions

    C o n t e n t s Chapter 1 | Preparing to Use the Product Product Features Safety Precautions Components Parts Diagram Recharging and Turning Power On/Off Chapter 2 | Learning to Use the Menus Display Structure <DEVICES> Mode www.remotesolution.co.kr OPERATING SET-UP PHOTO...

  • Page 4: Table Of Contents

    Product Features I Product Features Product Features Product Features ......... . . 5 Touch screen that facilitates usage convenience Safety Precautions About the Power Supply.

  • Page 5: Safety Precautions

    Safety Precautions Safety Precautions The following information is included to promote user safety and prevent any possible injury or property damage. Please read the directions carefully and use the product correctly. I About the Power Supply I About the Product Only charge using the power supply Do NOT touch the power plug with wet Do not use the product in high temperatures...

  • Page 6: Components

    Components Parts Diagram Components may be replaced without any prior notice in the interest of improving product quality or The diagram may differ with the purchased product. performance. The components shown here in the manual may differ from the components included with purchase.

  • Page 7: Parts Diagram

    Parts Diagram Parts Diagram The diagram may differ with the purchased product. The diagram may differ with the purchased product. I Remote I Cradle (Rear) DC 5.0V Cradle Remote Control Receiver Used when using a wireless remote control. Cradle connector Connects to the cradle.

  • Page 8: Rf Receiver & Ir Converter (Optional)

    Parts Diagram Recharging and Turning Power On/Off The diagram may differ with the purchased product. I RF Receiver & IR Converter (Optional) I Recharging with an Adapter Adaptor Specs : DC 12V, 300mA Insert the adapter cable into the cradle and then plug the other end into a power outlet. Receives RF signals from the main remote control and converts them to IR signals.

  • Page 9: Display Structure

    Main Screen ..........16 Display Structure REMOTE - Screen .

  • Page 10: Main Screen

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus Screen Configuration Display Structure I Main Screen I REMOTE - Screen Press the menu icons on the remote control LCD screen following steps 1 2 to open the menu.

  • Page 11: Devices> - Tv Screen

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus Display Structure <DEVICES> Mode [ <TV>, <AVR>, <TIVO>, <DIRECTV>, <DVR>, <DVD>, <CABLE>, <SATELLITE>, etc. Follow the same instructions to move to the [DEVICES] menu. I <DEVICES>...

  • Page 12: Operating Set-Up

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus OPERATING SET-UP OPERATING SET-UP I BRAND(CODE) SET-UP (TV Remote Control Setting) Press the [DEVICE-TV] icon on the screen. Point the remote control at the TV. Press the menu icons on the screen following steps 1 2 to open the menu.

  • Page 13: Code Learning

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus OPERATING SET-UP OPERATING SET-UP I CODE LEARNING Press the menu icons on the screen following steps When the TV power turns on, press the [VERIFY] icon. 1 2 to open the menu.

  • Page 14: Select Signal Between Ir/Rf

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus OPERATING SET-UP OPERATING SET-UP I SELECT SIGNAL BETWEEN IR/RF Select a device that you want to learn. Press the menu icons on the screen following steps 1 2 to open the menu.

  • Page 15: Pairing The Remote Control With The Receiver

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus OPERATING SET-UP OPERATING SET-UP I PAIRING THE REMOTE CONTROL WITH THE RECEIVER For security purposes, the entire following procedure must be completed within 60 seconds of turning on the receiver.

  • Page 16: Photo

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus OPERATING SET-UP PHOTO I PHOTO DISPLAY Press the menu icons on the screen following steps with the remote unit. 1 2 to open the menu. The name of the receiver to be paired with the remote The [PHOTO] screen appears.

  • Page 17: Setting

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus SETTING SETTING I SETTING Main Screen I SYSTEM SET-UP Press the menu icons on the screen following steps 1 2 to open the menu. The SYSTEM SET-UP screen appears.

  • Page 18: Start Program

    Chapter 2 | Learning to Use the Menus Chapter 2 | Learning to Use the Menus SETTING SETTING I START PROGRAM I DISPLAY MODE SET-UP WHILE CHARGING SELECT A START PHOTO: Runs the PHOTO function of the remote control Runs automatically upon product operation as set by the user. SELECT A DISPLAY PROGRAM CLOCK: Displays the current time and year, month, day...
