Expand Your Factory Radio
Harness Connection
Port 1
Port 2
FORD
LINCOLN
MERCURY
Owner's Manual
Media Gateway
ISFD11
PGHFD1
iSimple®
A Division of AAMP of America™
13190 56th Court Clearwater, FL 33760
Ph. 866-788-4237
support@isimplesolutions.com
©2009 AAMP of Florida, Inc.
www.isimplesolutions.com
Dip Switches
USB
(See Manual)
add
Satellite
Radio
Rev. 10-05-09
Inst023
Advertisement
Table of Contents
Related Manuals for iSimple ISFD11
Summary of Contents for iSimple ISFD11
-
Page 1: Satellite Radio
Dip Switches Port 1 Port 2 (See Manual) FORD LINCOLN MERCURY Owner’s Manual Media Gateway ISFD11 PGHFD1 iSimple® A Division of AAMP of America™ 13190 56th Court Clearwater, FL 33760 Ph. 866-788-4237 support@isimplesolutions.com ©2009 AAMP of Florida, Inc. www.isimplesolutions.com Satellite Radio Rev. -
Page 2: Table Of Contents
Table of Contents 1. Introduction 2. Precautions 3. Compatibility Notes 4. Programming the Media Gateway (PXAMG) 5. Installation 6. Sirius Satellite Radio Operation 7. Selecting AUX Input 8. Troubleshooting 9. Warranty Info Pages... - Page 3 Media Gateway & Optional Add-ons *The Media Gateway will only support 2 inputs. Media Gateway Harness Part #: PGHFD1 LCD Retention Harness Part #: PGHFD1A DVD Player (not included) MP3 Player (not included) Media Gateway Part #: PXAMG Harness Connection ...
-
Page 4: Introduction
1. Introduction ® Thank you for purchasing the iSimple Media Gateway. The Media Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your SCC1 satellite radio tuner performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Media Gateway. -
Page 5: Installation
Radio Requirements All 2005-2008, select 2009-2010 Non-Navigation Center Stack** - All 2005-2008 radios, navigation or non-navigation, that feature an “AUX” or “SIRIUS” button are compatible.* Select 2009-2010 non-navigation center stack radios that feature a “Sirius” button are compatible. In these vehicles the Media Gateway emulates a satellite tuner, therefore it is required that the vehicle be either equipped with an external satellite tuner or be Satellite Radio ready. -
Page 6: Installation
5. Installation IMPORTANT NOTE If you are installing the Media Gateway into any of the following vehicles the PGHFD1A harness is also required: 2008-2010 Ford Escape Non-Navigation 2009-2010 Ford F-150 Non Navigation 2009 Ford Flex Non-Navigation 2008-2010 Ford Focus 2008-2010 Mercury Mariner Non-Navigation 2009 Lincoln MKS Non-Navigation 2010 Ford Fusion Non-Navigation 2010 Ford Mustang Non-Navigation... - Page 7 7. To complete the installation secure the Media Gateway (PXAMG) and Satellite Radio tuner (SCC1) into the cavity in the dash behind the radio. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables.
-
Page 8: Sirius Satellite Radio Operation
6.Sirius Satellite Radio Operation (Non-Navigation Radios) Press the AUX or Sirius button repeatedly (Must press SR icon & then use the SR123 icon on navigation radios) until “SIR-1” is displayed on the screen. *** NOTE When you press the AUX or SAT button, you will see the corresponding SAT mode (for example SAT 1), a slight delay, and then the current Gateway mode will be displayed (HD Radio/iPod/Sir1 - Sir 2 - Sir 3/Line In) Channel Up... -
Page 9: Selecting Aux Input
Category Selection Press Preset 6 to bring up the Categories menu. Press the ▲ or ▼ icons on the screen to scroll through the categories. Press the icon that represents the category you wish to select. Store Presets Press and hold the preset button on which you want to store the channel Recall Presets Press the button that corresponds with the channel you want to recall 7. -
Page 10: Troubleshooting
8. Troubleshooting Symptom Radio shows “DEV INIT” Media Gateway device is initializing. The Media Gateway does The SCC1 tuner was not not recognize the SCC1 properly connected when the PXAMG was first connected and initialized. I hear the Satellite Radio The PGHFD1A harness but the separate screen is required for vehicles... -
Page 11: Fcc Class B Radio Frequency Interference Statement
® above, iSimple will repair or replace the product at their discretion, if it is defec- tive in material or workmanship providing it is returned to an Authorized iSimple dealer, with PROOF OF PURCHASE from an authorized iSimple Warning: This equipment may be reset by unintentional electrostatic discharge during operation. - Page 12 Notes ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________...
- Page 13 Notes ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________...
- Page 14 www.isimplesolutions.com For Best Performance Have It Professionally Installed.
