SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SERVICE MANUAL
Wireless type
Models
MUZ-FA25VA -
MUZ-FA35VA -
MUZ-FA25VAH -
MUZ-FA35VAH -
NOTE:
This service manual describes technical data of the outdoor units.
•As for indoor units MSZ-FA25VA-
E1
E1
E1
E1
Indication of
model name
MUZ-FA25VA -
E1
MUZ-FA35VA -
E1
MUZ-FA25VAH -
E1
MUZ-FA35VAH -
E1
and MSZ-FA35VA-
, refer to the service manual OB371.
E1
E1
www.ilmalämpöpumput.com
HFC
utilized
R410A
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················5
3. SPECIFICATION·················································5
4. NOISE CRITERIA CURVES ·······························7
5. OUTLINES AND DIMENSIONS ·························8
6. WIRING DIAGRAM ············································9
7. REFRIGERANT SYSTEM DIAGRAM ··············11
8. PERFORMANCE CURVES ······························13
9. ACTUATOR CONTROL····································21
10. SERVICE FUNCTIONS·····································22
11. TROUBLESHOOTING ······································22
12. DISASSEMBLY INSTRUCTIONS·····················39
13. PARTS LIST······················································42
No. OB372
