ACROBAT Vac-U-Drive

Automatic Pool Cleaner

VAC-U DRIVE Swinging float arm for Acrobat like agility

36 Fin disk with DEEP VEE Scoop

Proven technology:

Unique hose design for extra spring

Three year warranty on main body

Adjustable flow valve to control ACROBAT TRAVEL speed

Adjustable diaphragm for longevity

Suitable for all in-ground pool surfaces in good condition

OPERATING AND

Troubleshooting GUIDE

www.solarsplash.com.au

Diaphragm driven strength & quietness

Table of Contents

Need help?

Do you have a question about the Vac-U-Drive and is the answer not in the manual?

Questions and answers

Summary of Contents for Acrobat Vac-U-Drive

Page 1 ACROBAT Vac-U-Drive Automatic Pool Cleaner VAC-U DRIVE Swinging float arm for Acrobat like agility Ÿ 36 Fin disk with DEEP VEE Scoop Ÿ Proven technology: Diaphragm driven strength & quietness Ÿ Unique hose design for extra spring Ÿ Three year warranty on main body Ÿ...
Page 2 5. Attach the Hoses to thick tube of main body at the opposite end to the hand nut, push hose on firmly. INSTALLING THE ACROBAT POOL CLEANER 1. Connect Acrobat machine to your hoses, sufficient hose should be installed for the hose to reach the furthest place from the skimmer box plus one length of hose.
Page 3 6. Setting control valve too fast ie too much suction can stretch the diaphragm and damage it, depending on the pump size set suction so ACROBAT moves 2,5m to 3m per minute. If there is excessive suction the ACROBAT hoses will make a great deal turbulence.
Page 4 1. Adjust the hose length by adding or removing a hose. 2. Ensure that the Eyeball return is not interfering with the flow of the Acrobat. If so adjust Eyeball return nozzle to direct the flow away from the ACROBAT.
Page 5 1. Ensure the Control valve is free of debris and not jammed shut. 2. Set Control valve to a lower setting to divert more water. ACROBAT IS MOVING IN A SET PATTERN 1. Ensure hoses are in a good flexible condition and not coiled.
Page 6 Main SC outer Acrobat float stability extension & float arm weight pipe and hand Acrobat weight chamber Bumper ring Acrobat main body SC inner extension pipe SC diaphragm retainer SC diaphragm SC Flexi foot pad SC 36 finned disc DEEP VEE Scoop...
Page 7 DIAPHRAGM INSTALLATION Step 1 Step 5 Turn nut anticlockwise Place yellow disk around diaphragm and place into diaphragm tool Step 2 Step 6 Remove cover pipe from diaphragm Pull diaphragm tool with diaphragm through machine until it “pops” and releases Step 3 Step 7 Squeeze ridges and push diaphragm down...
Page 8 NOTE: Most problems are caused by incorrect installation, poor water chemistry and wear and tear. Please regularly check the condition of flexi foot pad & 36 finned disk, these are like the tyres on a car & need replacement from time to time. www.solarsplash.com.au...
