- Page 1 5505(G) cover_cover.qxp 2010-07-20 오전 11:23 페이지 1 OPERATING INSTRUCTIONS TX-5505 AM/FM STEREO TUNER...
-
Page 2: Read This Before Operating Your Unit
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 2 ntroduction READ THIS BEFORE OPERATING YOUR UNIT This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Table Of Contents
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 3 CONTENTS Introduction • READ THIS BEFORE OPERATING YOUR UNIT Rear Panel Connections Front Panel & Remote Controls • REMOTE CONTROL OPERATION RANGE • LOADING BATTERIES Operations • LISTENING TO RADIO BROADCASTS • LISTENING TO RDS BROADCASTS (FM ONLY) •... -
Page 4: Rear Panel Connections
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 4 Rear Panel Connections • Do not plug the AC input cord into the AC outlet when making connections. • Be sure to connect the white plugs to the L(Left) jacks and the red plugs to the R (Right) jacks when making connections. - Page 5 TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 5 CONNECTING AMPLIFIER • Connect the ANALOG L and R Jacks to the TUNER IN jacks of your amplifier. ANALOG Amplifier TUNER AC INPUT CORD • Plug the cord into a wall AC outlet.
-
Page 6: Front Panel & Remote Controls
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 6 Front Panel & Remote Controls Front panel controls TUNING / PRESET STEREO TUNED STANDBY ON/ STANDBY DIMMER T/ P MODE BAND AUTO PRESET TX-5505 AM / FM STEREO TUNER 3 4 5 Remote controls... - Page 7 TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 7 1. POWER ON/STANDBY button 12. PRESET UP/DOWN (+/-) buttons Each time the POWER ON/STANDBY button is Press these buttons to tune in the preset stations pressed, this unit is turned on to enter the operating without selecting the preset mode.
-
Page 8: Remote Control Operation Range
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 8 REMOTE CONTROL OPERATION RANGE TUNING / PRESET STEREO TUNED STANDBY ON/ STANDBY DIMMER T/ P MODE BAND AUTO PRESET AM / FM STEREO TUNER TX-5505 • Use the remote control unit within a range of about 7 meters (23 feet) and angles of up to 30 degrees aiming at the remote sensor. -
Page 9: Operations
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 9 Operations LISTENING TO RADIO BROADCASTS • Each time the BAND button on the remote control, the Before operation band changes as follows : FM ↔ AM • Turn the power on. • For details on FM mode, see “Listening to FM stereo broadcasts”... - Page 10 TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 10 Manual tuning Manual presetting • Manual tuning is useful when you already know the • You can store up to 40 preferred stations in the memory. frequency of the desired station. • After selecting the desired band (and the tuning mode in...
- Page 11 TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 11 Continued ■On the remote control Press the CURSOR UP(▲)/DOWN(▼) buttons to enter the desired character on the flickering digit. Select the desired preset number(1~40) and press the ENTER button. • You can enter the desired among blank, A~Z, 0~9, ^, ’, (, , +, ,, -, ., /, =.
- Page 12 TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 12 Tuning to preset stations Press and hold down the TUNING/PRESET knob or the MEMORY button for more than 3 ■On the front panel seconds. • Press the TUNING/PRESET MODE button to select the preset mode, then rotate the TUNING/PRESET knob to select the desired preset number.
-
Page 13: Listening To Rds Broadcasts (Fm Only)
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 13 LISTENING TO RDS BROADCASTS (FM ONLY) RDS(Radio Data System) is a method for sending information signals together with the transmitter signals. Your tuner is capable of translating these signals and putting the information on the display. These codes contain the following informations. -
Page 14: Adjusting The Brightness Of The Fluorescent Display
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 14 ADJUSTING THE BRIGHTNESS OF TP search THE FLUORESCENT DISPLAY • Use this function to automatically search and receive the stations broadcasting the traffic program. DIMMER Perform the steps 1 and 2 in “RDS search”... -
Page 15: Troubleshooting Guide
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 15 Troubleshooting Guide If a fault occurs, run through the table below before taking your receiver for repair. If the fault persists, attempt to solve it by switching the unit off and on again. If this fails to resolve the situation, consult your dealer. -
Page 16: Specifications
TX-5505(G)_ENG_100819_TX-5505(G)_ENG 2010-08-19 오후 5:31 페이지 16 Specifications ■ FM TUNER SECTION • Tuning frequency range 87.5~108 MHz • Usable sensitivity, THD 3%, S/N 26 dB 12.8 dBf • 46 dB quieting sensitivity, mono/stereo 20.2 / 45.3 dBf • Signal to noise ratio, 65 dBf, mono/stereo 70 / 65 dB •... - Page 17 5505(G) cover_cover.qxp 2010-07-20 오전 11:23 페이지 2 TX-5505 AM/FM STEREO TUNER 5707-00000-407-0S...
