Page 1: Instructions For Use
OKF921G, OKF621G INSTRUCTIONS FOR USE Kitchen extractor hood Before starting the appliance, please read this operating manual carefully. - Page 3 Dear Customer, You are now a user of the newest generation kitchen extractor hood of OKF921G or OKF621G type. This hood has been designed and manufactured specially with a view to satisfying your expectations and it will certainly constitute a fitting element of a modern kitchen. The modern structural solutions and the newest technologies used in production of this hood guarantee its high effectiveness and good appearance.
-
Page 4: Table Of Contents
CONTENTS Guidelines concerning safe use...............5 Installation........................7 Maintenance......................10 Construction......................11 Cleaning and maintenance...................13 Technical data....................14 Guarantee, after-sale service................14... -
Page 5: Guidelines Concerning Safe Use
GUIDELINES CONCERNING SAFE USE RECOMMENDATIONS:: 1. Check if the voltage value provided on the rating plate corresponds to the local electric supply parameters. 2. Uncoil and straighten the electric supply cable before the installation. 3. This equipment is not to be used by persons (to include children) with limited physical, sensory, or mental capacities, unless they do so under supervision or in accordance with the equipment use instructions given to them by persons who are responsible for their safety. - Page 6 WARNING: Before the ventilation hood is connected to the power supply network and before its proper operation is checked, it is necessary to verify if the supply cable has been installed properly and has NOT been crushed by the ventilation hood during the assembly.
-
Page 7: Installation
INSTALLATION Installation of the ventilation hood in the exhaust mode (extracting of used air to the outside) 1. Fix the wall section of the ventilation hood to the wall, using fixing pins and screws from the installation packet, at a height so that the suspended ventilation hood in on the level of 650-750 mm over the top of the stove. 2. Remove the fat filter of the ventilation hood (the number of filters depends on the type of the hood) by unfastening the snap fastener. - Page 8 INSTALLATION GOOD 5. Put the air outlet pipe into the connection port of the air outlet at the ventilation hood body and fix it with 3 small screws (the pipe and the screws are supplied). The other end of the pipe (marked HL) connect with the ventilation channel. 6. Install the grip of the upper chimney masking element in the axis of symmetry of the ventilation hood (over the ventilation duct).
- Page 9 INSTALLATION Setting the ventilation hood in the scent absorber mode In this mode, air filtered through the active carbon filter returns to the room by the oblong openings of the cleaned air outlet located on the upper masking element. If the ventilation hood is to be used in this mode, it is necessary to purchase and install an active carbon filter.
-
Page 10: Maintenance
MAINTENANCE 6. Take off the protective film from the chimney masking elements. 7. Set the length of the upper masking element as required and fix it to the grip with two side screws (item A1 below). 8. Fix the carbon filter (which must be purchased separately) to the inside frame of the ventilation hood body (which is accessible only after the air filter/-s is/are remo- ved). When buying an air filter, information on the type of the ventilation hood must be provided to the seller. The information can be found on the rating plate. The rating plate can be found inside the hood. 9. Re-install the fat filter (the number of filters depends on the type of ventilation hood). 10. Connect the ventilation hood to the power supply network. Control panel The operation of the ventilation hood is controlled by a combined switch that can be found on the front of the ventilation hood body. -
Page 11: Construction
CONSTRUCTION Exhaust pipe Air outlet openings Power supply cable Upper masking element Lower masking Electric cover element Motor Casing (hood) Control panel Ventilation hood glass screen Lights Fat filters (the number depends on the type of the ventilation hood) Connecting the hood to power supply network and controlling its operation After connecting the hood to the electric network (in accordance with the previously de- fined requirements), it is necessary to check if the light of the ventilation hood works and if the motor works properly. - Page 12 Lighting The lighting installation consists of 20 W halogen bulbs. In order to change a broken bulb, one must: a) lever the ring holding the glass of the halogen lamp (in three points) using a flat tool or a screwdriver and take the bulb out while holding the ring, b) change the bulb, holding it with a cloth or a piece of paper, c) reinstall the ring and the glass by doing things in the reverse order.
-
Page 13: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning Before any cleaning and maintenance operations are performed, the ventilation hood must be disconnected from its electric supply by unplugging it from the power socket or by swit- ching off the main supply switch. The ventilation hood must be cleaned frequently, both on the outside and inside, using a cloth damp cloth with gentle cleaning substances. -
Page 14: Technical Data
TEChNICAL DATA Type of ventilation hood OKF921G OKF621G Electric supply voltage AC 230V ~50Hz Number of fan motors Number of fat filters 2 1 Lighting power [W] 2 x 20 Fan speed gears Width [cm] Depth [cm] Height [cm] 59,2-108,2 60,7-109,6 Outlet [Ø mm] Output [m3/h] max 680 Power consumption [W]... - Page 16 Amica Wronki S.A. ul.Mickiewicza 52 64-510 Wronki IO 00317...
