Competition Pro TL-2092 Owner's Manual

Technical Specifications

Max Output Power (14.4v)
RMS Output Power (14.4v) @ 4 ohm per channel
RMS Output Power (14.4v) @ 2 ohm per channel
RMS Output Power (14.4v) @ 4 ohm (bridge)
RMS Output @ THD+N < 1%
Frequency Response
Low Pass/High Pass Filter slopes
Low Pass Filter Range
High Pass Filter Range
Input Sensitivity
TDH @ 4 ohm load
(30% Rated Power)
Signal/Noise Ratio
Channel Separation
Minimum load (speaker) impedance per channel
Minimum load (speaker) impedance (bridge)
Overheat protection temperature
Power Supply
External fuse (must be installed in power cable)
(not included)
Dimensions
(length x width x height)

Features

•
Class AB mosfet full range amplifier
•
2/4 channel input
•
2/3/4 channel output
•
Input switch allows full 4 channel operation from only 2 channel input (one RCA pair)
•
Huge power output
•
Hi fidelity audio components
•
High performance Low Pass and High Pass filters with 40 dB/octave slope
•
Continuously adjustable filter frequency
•
Advanced noise rejection circuitry
•
Excessive heat, Low voltage, Short circuit and Overload protection circuitry
•
Heavy-duty gold plated connection terminals
•
Heavy-duty aluminium heatsink
All content © Copyright TheLoudest.com 2006
OWNER'S MANUAL
TL-2091 TL-2092
2000 Watts Max 3000 Watts Max
4 x 100 Watts RMS 4 x 160 Watts RMS
4 x 140 Watts RMS 4 x 210 Watts RMS
2 x 250 Watts RMS 2 x 450 Watts RMS
4 x 85W @ 4 ohm 4 x 135W @ 4 ohm
4 x 120W @ 2 ohm 4 x 170W @ 2 ohm
2 x 225W @ 4 ohm 2 x 330W @ 4 ohm
10 Hz – 25 kHz 10 Hz – 25 kHz
40 dB/oct 40 dB/oct
50 ~ 500 Hz 50 ~ 500 Hz
50 ~ 500 Hz 50 ~ 500 Hz
0.2 ~ 5V 0.2 ~ 5V
< 0.02% < 0.02%
>90 dB >90 dB
>89 dB >89 dB
2 ohm 2 ohm
4 ohm 4 ohm
80°C 80°C
DC 12V DC 12V
60A 80A
282 x 199 x 62 mm 347 x 199 x 62 mm
HIGH PERFORMANCE
4-CHANNEL MOSFET CLASS AB
CAR AMPLIFIER
2,000 Watts Max
Up to 560 Watts RMS
OWNER'S
MANUAL
SAFETY GUIDELINES | TECHNICAL SPECIFICATIONS
FEATURES | INSTALLATION AND OPERATION INSTRUCTIONS
3,000 Watts Max
Up to 900 Watts RMS
