Summary of Contents for Iomega G3
- Page 1 ™ Installation and User’s Guide ® ® For Apple Power Macintosh...
- Page 2 The Buz card is a PCI adapter that provides professional quality video capture, real-time hardware Motion-JPEG video compression and video output. It is also an intelligent, high-performance PCI* Ultra-SCSI** host adapter, ideally suited for connection to Iomega’s Jaz drives and other fast SCSI devices. ®...
- Page 3 This Installation Guide will lead you through the installation process including how to connect your Buz Box to the back of your computer and to video and audio devices. Iomega Buz EasyGuide for Adobe Premiere 4.2 LE steps you through the software ®...
- Page 4 Buz Performance Characteristics Video Specifications Compression Resolution Capture Format Video Data Rate Production Format Still Images Video In/Out Audio In/Out SCSI Specifications Technology Transfer Rates Interfaces Connectors SCSI Addresses Hardware Motion JPEG (MJPEG) Up to 720x480 at 29.27 frames per second (60 fields) NTSC Up to 720x576 at 25 frames per second (50 fields) PAL/SECAM Up to 24 bit (16 million) colors QuickTime Movie (Motion JPEG A)
-
Page 5: Table Of Contents
Index Installation Guide ... 2 Install Your Software ... 7 Buz Box Connections ... 8 Video/Audio Connections ... 14 Optimizing Your System ... 15 Your Legal Responsiblities ... 16 SCSI Guidelines ... 17 Software Features ... 18 Special Notes ... 19 Adobe Features Not Supported ... -
Page 6: Installation Guide
Insert the Buz Installation CD in your CD-ROM drive, double click on Start Here and choose Hardware Install Guide. Buz installs on three types of Apple Power Macintosh G3 systems: Mini Tower, Desktop and All-in-one. View the video tutorial on installing the Buz card in... - Page 7 If you are unsure about how to open your computer, please refer to the user’s manuals that came with your system. Lay the Mini Tower G3 on its side, press the latch button, lift the cover panel up a few inches, and lift it off.
-
Page 8: Open The Computer
2. Open the computer. The Mini Tower G3 has two green colored locking levers. Pull the levers up and out to release the chassis, then open the chassis by pulling up the big brown handle. Pull the All-in-one G3 logic board tray out carefully until it stops. Be careful that you do not tip the computer over. - Page 9 (Save the slot cover screw for use in the next step.) Support the tray with your hand while installing the Buz card PCI slots Remove slot cover and retain screw MINI TOWER G3 Swing the chassis open until it rests firmly on the work surface ALL-IN-ONE G3...
- Page 10 4. Unpack the Buz card. CAUTION Touch a grounded metal object to discharge any build-up of static electricity before handling the Buz card. Handle the card by its edges. If you lay it down, place it on the static-proof bag it is shipped in.
-
Page 11: Install Your Software
• The default install settings will automatically install the software drivers and will create the Iomega Buz folder on your hard drive and will install all of the Buz software pieces (drivers, applications, utilities, etc.). At the end of the software installation you will be asked to register your Buz Multimedia Producer. -
Page 12: Buz Box Connections
Buz Box Connections 1. Connect the Buz box cable to the Buz card on the back of your computer. The longer connector on the back of the Buz card is the connector for external SCSI devices (such as Jaz drives). A variety of SCSI devices can connect to the Buz card. See your SCSI device documentation for proper connection. - Page 13 Buz Box connector: The fifteen-pin connector from the Buz Box goes to the matching connector of the Buz card. Look at this plug carefully. Check orientation before connecting. After connecting, tighten the thumbscrews. Avoid bending any pins. Audio In: The smaller of the two Buz audio connectors is the Audio In connector. Connect it to the Microphone port on the back of your computer.
- Page 14 Out: Audio The larger of the two Buz audio connectors is the Buz Audio Out Pass- through connector. It should be plugged into the speaker port on the back of your computer. If you have a connector for external speakers already plugged into the speaker port, disconnect and reconnect it into the back of the Pass-through connector so your speakers will continue to work.
- Page 15 Pass-through Connector Your Existing Speaker's Connector External SCSI Connector Buz Box Connector NOTE: The back of your Macintosh may not look the same as the graphic. If you are unsure about the connections, refer to your Power Macintosh G3 User’s Guide.
- Page 16 4. Plug your audio and video input and output devices into the Buz Box. Input from Source Side Audio Left Channel Audio Right Channel S-Video Input Composite Video Input CAUTION Do not connect your audio equipment to the composite video input or output jack.
- Page 17 If your Power Macintosh G3 system has the Personality card installed, it is equipped with high quality audio inputs. You may want to connect RCA audio connectors directly to these rather than connecting through the Buz box. If you do, you must change your settings in the Control Panel setting: Monitors and Sound/ Sound/Sound Monitoring Source/RCA in.
-
Page 18: Video/Audio Connections
Video/Audio Connections Video: If your camcorder or VCR has an S-Video connector, use it for better video quality. To select S-Video, launch Adobe Premiere 4.2 LE. Select File, then Capture, then Movie Capture. A new menu item appears: Movie Capture. Select the Video Input command in this menu. -
Page 19: Optimizing Your System
• Iomega Jaz drives and disks are ideal storage solutions for video capture and production. Make sure to turn off write verification (using the Iomega Tools application) and to use new or newly formatted disks for optimal performance. -
Page 20: Your Legal Responsiblities
The next step in optimally configuring your system and becoming familiar with Buz is to carefully read the Iomega Buz EasyGuide for Adobe Premiere 4.2 LE. This tutorial has been created to let you quickly gain proficiency with this powerful video editing software program. -
Page 21: Scsi Guidelines
The Buz adapter card is shipped with the Ultra SCSI function turned on. Refer to the Iomega Tools folder located in the Iomega Buz folder on your hard drive for software utilities and information about your Iomega Jaz or Zip drive. -
Page 22: Software Features
Use the Iomega Buz EasyGuide for Adobe Premiere 4.2 LE to help you get the basics for creating movies in Premiere. Study the Premiere LE User’s Guide pdf file (located in the Adobe Premiere 4.2.1 LE ƒ... -
Page 23: Special Notes
Special notes about Adobe Premiere and Buz For additional information not included here, review the Read Me file located in the Iomega Buz folder on your hard drive. For the most up-to-date Buz information visit the Iomega web site at URL: http://www.iomega.com/buz Switching between NTSC and PAL modes Use the Buz Video control panel to switch between NTSC and PAL. - Page 24 “Why is my last video frame always displayed on my TV monitor?” The purpose of the Iomega Buz Startup file (located in the Startup Items folder of your System folder) is to provide optimal Buz performance in certain areas of Adobe Premiere LE. You can disable it if it annoys you by using the Extensions Manager.
-
Page 25: Adobe Features Not Supported
Buz For additional information not included here, review the Read Me file located in the Iomega Buz folder on your hard drive. For the most up-to-date Buz information visit the Iomega web site at URL: http://www.iomega.com/buz The Buz driver supplied with the present Installation CD does not currently support the following features of Adobe Premiere. -
Page 26: How To Get Help
All you need to view and print the latest Iomega documentation is the Acrobat Reader. If you don’t already have the Acrobat Reader installed on your system, you can download it from http://www.adobe.com... - Page 27 *1-800-879-7660 is available in the U.S. and Canada. Support Forums – America Online If you use the America Online service, you have access to Iomega support forums for Zip, Jaz, and Ditto products. All forums include hypertext links to Iomega’s Home Page on the Web so that you can readily access our total Internet solutions.
- Page 28 - our trained support personnel can often resolve the problem over the phone. If you choose to contact Technical Support, you will not be charged the standard support fee for the call if your Iomega product is still under warranty and is determined to be defective.
-
Page 29: Warranty Information
If you have a question about the limited warranty on your Buz card, Buz Box, or other Iomega product, please call 1-888-4-IOMEGA and choose the option for warranty information. If you choose to contact Technical Support, the standard support fee may apply. -
Page 30: Regulatory Agency Statements
Other types of cables may violate FCC rules and regulations. Also, changes or modifications to the electronics or enclosure of this product must be expressly approved by Iomega; otherwise, the user’s authority to operate the equipment may be voided by the FCC. -
Page 31: Fcc Declaration Of Conformity
The Buz Multimedia Producer PCI card has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. Model: Buz. Manufacturer’s Name: Iomega Corporation. Manufacturer’s Address: 1821 West Iomega Way, Roy, UT, USA. Manufacturer’s Telephone Number: (801) 778-1000. Responsible Party: John Glavin. - Page 32 © 1998 Iomega Corporation. Iomega, Jaz, Zip and the stylized “i” logo, are registered trademarks of, and Buz, Buz Multimedia Producer, RecordIt are trademarks of, Iomega Corporation. Adobe and Adobe Premiere are trademarks of Adobe Systems Incorporated which may be registered in certain jurisdictions.
