Summary of Contents for Clear2there C2TDVR1004

  • Page 2: Important Safety Instructions

    1. IMPORTANT SAFETY INSTRUCTIONS 8.4.6 CONTROL DEVICE 2. BEFORE INSTALLATION 8.5 EVENT /SENSOR 3. MAIN FEATURES 8.5.1 HDD EVENT 4. SYSTEM ORGANIZATION 8.5.2 ALARM INPUT 5. SYSTEM CONTENTS 8.5.3 ALARM OUT 6. SYSTEM SURFACE OVERVIEW 8.5.4 BUZZER OUT 6.1. FRONT 8.5.5.

  • Page 3: Main Features

    ● Installation should be carried out only by qualified personnel and in accordance with any electrical regulations 1) Read these instructions. in force at the time. 2) Keep these instructions. ● The DVR must be placed on a stable surface or mounted 3) Heed all warnings.

  • Page 4: System Contents

    for each channel and telemetry speed can be adjusted to suit particular speed domes. LIVE DISPLAY The DVR displays single or multi screen images and also has several sequence modes. CONFIGURATION BACKUP All configuration settings on the DVR can be saved to USB memory stick or a PC remotely.

  • Page 5: Remote Controller

    6.1. FRONT USB PORT Port for USB devices such as mouse and USB backup 6.2.7 DC-12V device. Connect Power Source from Power Adapter. POWER DISPLAY SEARCH MENU POWER Turn on power of system. DISPLAY Shift display mode between split and full screen mode. ♣...

  • Page 6: Sequence Mode

    and Click the SETUP menu. Press the SETUP button to bring up the menu login screen. Only operators with ADMIN rights can configure the DVR. Enter the default password of ‘1234’. 8.1. DISPLAY 8.1.1. OSD Display Status Bar System Setup Monitor Camera Title Event Icon...
  • Page 7 8.2. DISPLAY 8.2.1 CAMERA TITLE Camera Camera Title System Setup Color Setup PTZ Setup Motion Sensor Click the CAMERA TITLE menu and click the ON/OFF menu on the COVERT menu. Click the CAM No on the TITLE menu and change the AREA SETUP: Choosing this option allows the operator to camera name.

  • Page 8: Web Server Port

    Click the DATE / TIME menu and click the ON/OFF menu. connect by two different ways. (Mac address / Own host name) DATE TIME: Allows the operator to set or modify the a. 00115ff00213.dvrlink.net current date & time. b. 1234.dvrlink.net, DATE FORMAT: Determines how the date is displayed.

  • Page 9: Event /Sensor

    And select the SYSTEM ID, PTZ Protocol and camera 8.4.5 SYSTEM MANAGEMENT BAUD RATE. Click the SYSTEM MANAGEMENT menu. This will allow up to 254 DVRs to be controlled from the And click the PRESS menu for FW Upgrade, Factory same keyboard.

  • Page 10: Email Notification

    Can be either TRANSPARENT (the output is active only 8.5.5. E-MAIL NOTIFICATION. when the trigger criteria is present) or LATCHED (the NOTIFICATION System Setup EVENT/SENSOR HDD EVENT output is active for a set period of time after a trigger). ALARM INPUT HDD EVENT If set to <LATCHED>, the alarm will sound for as much time as defined in DURATION.

  • Page 11: Record Setup

    9. RECORD SETUP RECORD SETUP RECORDING OPERATIONS SIZE 9.1 SIMPLE RECORDING SIMPLE RECORDING RECORD SETUP RECORDING OPERATIONS RECORDING MODE MANUAL RECORDING QUALITY SIMPLE RECORDING SCHEDULE MODE AUDIO MANUAL RECORDING PRE EVENT RECORDING TIME MANUL RECORD TIME Set recording configuration for Panic Recording. POST EVENT RECORDING TIME During panic recording mode, the DVR will override all Click the RECORD SETUP menu.

  • Page 12: Archive Setup

    11. ARCHIVE SETUP WEB RA MINIMUM PC REQUIREMENT P4 3.0 or Higher ARCHIVING FROM ORIGINAL SIZE CH SIZE 512MB or Higher PREVIEW LOG SIZE Geforce MS 400, Radeon 7500 or CH SELECT higher Include Audio Gefore 8 series or higher Include Log VGA MEMORY 64MB...

  • Page 13: Live Mode

    In case of, unable to install active-X, User needs to check the option of activeX on IE security menu. Explanation of function button in LIVE mode Select live division screen. Move to next screen and make full screen Select live channel. Activate Mic to send a sound to DVR.
  • Page 14 Alarm input. Motion- Indicator will be marked when system detects Motion Video Loss - Indicator will be marked when system detects Alarm input. Recording – Display current recording mode (T: Continuous, M: Motion, A: Alarm recoding) Alarm Out - Indicator will be marked when system detect Select a time line on time table or set an exact time.

  • Page 15: Setup Mode

    the related camera’s image and pop up fuction. 12.5 SETUP MODE All settings are same as DVR setup. CAMERA Sound user can configure camera’s attribute such as title, live color, Audio Setting – Select a live audio channel and PTZ setup or motion activation Buzzer setting –...
  • Page 16 12.6 INFORMATION Check DVR model name and WEB version. Network User can check the system’s network information and selectable speed level. But IP settings are not allowed to change on remote site. Network IP only can set on system. For email notification, user can input the SMTP server detail on below setup.
  • Page 17 ♣ Blackberry 1. Select the Web browser 13 SMART PHONE CONNECTIONS ♣ I-PHONE 1. Select the Safari browser Enter the IP address or URL to connect. And press the Enter button. 2. Enter the IP address or URL to connect. And Click the [GO] button.
