- Page 1 COLOR TELEVISION RECEIVER INSTRUCTION MANUAL Q2049J Before operating the unit, please read this manual thoroughly.
-
Page 2: Table Of Contents
PART 2 TELEVISION OPERATIONS Contents Important safety instructions-1 Sound Control --------------------17 Identification of Controls-------3 Timer Setting ----------------------18 Front ------------------------------------------------------3 To enter the TIMER menu--------------------------18 Back-------------------------------------------------------4 Setting the Clock -------------------------------------18 Remote Controller -------------------------------------5 Setting Sleep timer ----------------------------------18 Installing batteries -------------------------------------6 Setting the Off Time ---------------------------------19 Effective range of the Remote----------------------6 Setting the On Time ---------------------------------19 Installation --------------------------7... -
Page 3: Important Safety Instructions
Important safety instructions The lightning flash with arrowhead symbol, within an equilateral triangle is intended to CAUTION alert the user to the presence of uninsulated dangerous voltage within the product's RISK OF ELECTRIC SHOCK enclosure that may be of sufficient magnitude DO NOT OPEN to constitute a risk of electric shock to persons The exclamation point within an equilateral... - Page 4 Important safety instructions(continued) 13. LIGHTNING To protect your product from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.
-
Page 5: Identification Of Controls
Introduction Identification of Controls Front T V/AV MENU 1. TV/AV button: video input select. 2. MENU button: to enter into menu operation. 3. VOL button: volume down select; menu item adjust. 4. VOL button: volume up select; menu item adjust. 5. -
Page 6: Back
Back VIDEO VIDEO S-VIDEO AUDIO 1. Antenna input 2. DVD input (Y, C , C , AUDIO L, R) 3. AV input (VIDEO, AUDIO L, R) 4. S-VIDEO input Earphone jack AV input (VIDEO, AUDIO L, R) Notes: The S-VIDEO terminal is prior to the VIDEO terminal, if you want to watch video program from the VIDEO input terminal, please disconnect the S-VIDEO first. -
Page 7: Remote Controller
Introduction Identification of Controls (continued) Remote Controller Indicator: the indicator lights Turn On/Off the the unit up when any button is pressed HIFI CATV To select to view program from To mute the sound external video equipment (VCR, DVD, VCD,etc.) Direct channel selector To select three Quickly returns to previous... -
Page 8: Installing Batteries
Installing batteries Effective range of the Remote Open the battery cover. Install two "AAA" batteries matching the +/- polarities of the battery to the +/- HIFI CATV marks inside the battery compartment. SLEEP STEREO SOUND Notes: Replace the battery cover. When there is an obstacle between the TV Notes: and the transmitter, the transmitter may not... -
Page 9: Installation
INSTALL the unit in a room where direct light will not fall upon the screen. Total darkness or a reflection on the picture screen may cause eyestrain. Installation Soft and indirect lighting is recommended for comfortable viewing. Antenna installation Optimum reception of colour requires a good signal and will generally mean that an outdoor antenna must be used. -
Page 10: Connecting Video And Audio Equipment
Connecting video and audio equipment This TV set provides 2 groups of AV input terminals including one Video (S-Video) and one group of DVD input terminals for your convenient connection to VCR, DVD or other video equipment. To enjoy the high quality picture. -
Page 11: Turning On/Off
Operations Turning on/off Turning on AC Outlet Insert the AC plug (with the 2 blades) into a conveniently located AC outlet having 120V, 60Hz. AC Plug If no picture appears and the red indicator lights up, then the TV set is in STANDBY mode. -
Page 12: Select Input Signal
Operations Select Input Signal Watching AV program Video This TV set provides 2 groups of AV input terminals including one Video (S-Video) and one group of DVD input terminals for your convenient connection to VCR, DVD or other video equipment. Press TV/AV button on the TV set or AV button on the remote controller. -
Page 13: Tuning In
Operations Tuning in To enter the TUNING menu PICTURE TIMER TUNING SET UP Press MENU button. Channel Color system AUTO TV/CATV Add/Erase Fine Press VOL+ or VOL- button to Auto search select Tuning icon Move[ Adjust[ Press CH- button to display the TUNING menu. -
Page 14: Erasing An Unnecessary Channel
Erasing an unnecessary channel PICTURE TIMER TUNING SET UP Please enter the TUNING menu first. Channel Color system AUTO TV/CATV Press CH+ or CH- button repeatedly to highlight Add/Erase Erase Fine Channel item. Auto search Move[ Adjust[ Press VOL+ or VOL- button to select a channel number (for example, channel10) Press CH+ or CH- button repeatedly to highlight T V /AV... -
Page 15: Setting The Tv/Catv Option
Operations Tuning in (continued) Setting the TV/CATV option PICTURE TIMER TUNING SET UP Please enter the TUNING menu first. Channel Color system AUTO TV/CATV Add/Erase Press CH+ or CH- button repeatedly to highlight Erase Fine TV/CATV item. Auto search Move[ Adjust[ Press VOL+ or VOL- button to select TV or CATV. -
Page 16: Channel Selection
Operations Channel Selection Before you select a channel, please select TV or CATV input signal. TV 10 Please see the section of "To set the TV/CATV option ". Mono When you select TV, only channels received on antenna can be selected; When you select CATV, channels received on cable can be selected. -
Page 17: Adjusting Picture
Operations Adjusting Picture To enter the PICTURE menu PICTURE TUNING SET UP TIMER Press MENU button. Contrast Brightness Color Sharpness Tint Picture mode Sports More Press VOL+ or VOL- button to Move[ Adjust[ select PICTURE icon. Press CH- button to display the PICTURE menu. -
Page 18: Setting Blue Background Option
Auto search/Manual search/Channel skip/Fine tuning Setting Blue background option Please enter the PICTURE menu first. PICTURE TIMER TUNING SET UP More Blue back: Noise reducer: Press CH+ or CH- button to select Blue Back item. Move[ Adjust[ Press VOL+ or VOL- button to select On or Off. If the Blue Back is set to On, the TV set will display a blue background when there is no input signal. -
Page 19: Sound Control
Operations Sound Control Adjusting volume/Muting the Sound Use VOL+ or VOL- button. Press VOL+ button, the volume increases; Press VOL- button, the volume decreases. The minimum volume is 0 and the maximum volume is 100. Volume Use MUTE button. T V /AV MENU If you want to mute the sound, press MUTE button on the remote. -
Page 20: Timer Setting
Operations Timer Setting To enter the TIMER menu PICTURE TUNING SET UP TIMER Press MENU button. Off Time AM 12:00 On Time AM 12:00 Channel TV/CATV Clock AM 8:00 Press VOL+ or VOL- button to Move[ Select[ select TIMER icon. Press CH- button to display the T V /AV MENU... -
Page 21: Setting The Off Time
Notes about On Time function: Operations When the set is turned on automatically at the preset time, Timer Setting if there is no operation to the set within 2 hours, the set will (continued) regard this as no one is watching. For the sake of power saving, the TV set will go to STANDBY mode automatically. -
Page 22: System Setting
Operations System Setting To enter the SET UP menu PICTURE TIMER TUNING SET UP Press MENU button. Language: ENGLISH FRANCAL ESPANOL Menu Demo: Stop Child lock menu: More Press VOL+ or VOL- button to Move[ Confirm[ ] select SET UP icon. Press CH- button to display the T V /AV MENU... -
Page 23: Setting Closed Caption(Ccd)
Operations System Setting (continued) Setting Closed Caption(CCD) PICTURE TUNING SET UP TIMER Please enter the SET UP menu first. More Closed Caption Vchip password Press CH+ or CH- button to select Closed Caption item Move[ Select[ Press the VOL+ or VOL- button to select. You can select the caption data channel (C1/C2/C3/C4), the text service channel (T1/T2/T3/T4) or turn off the Closed Caption (Off). -
Page 24: Parental Control
Operations Parental Control Child lock To enter Child lock submenu PICTURE TUNING SET UP TIMER Please enter the SET UP menu first. Language: ENGLISH FRANCAL ESPANOL Press CH+ or CH- button to select Child lock menu Menu Demo: Stop Child lock menu: item. -
Page 25: Setting V-Chip
Operations Parental Control (continued) Setting V-chip To enter the V-chip menu Please enter the SET UP menu first. PICTURE TIMER TUNING SET UP MPAA RATING TV PARENTAL GUIDELINES CANADIAN ENGLISH RATING Press CH+ or CH- button to select Vchip password CANADIAN FRENCH RATING BLOCK item. -
Page 26: Tv Rating Set-Up
V-Chip enables parents to prevent their children from watching inappropriate material on TV. V-Chip reads the ratings for programming (except for news, sports, unedited movies on premium cable and Emergency System signals ), then denies access to programming if the program's rating meets the limitations you select. In this case, the program will be blocked. -
Page 27: Setting Individual Content Categories For Tv Rating
Operations Parental Control (continued) Setting V-chip Setting individual Content Categories for TV Rating Please enter the TV PARENTAL GUIDELINES sub-menu first. PICTURE TIMER TUNING SET UP CONTENT TV-Y Press CH+ or CH- button to TV-Y7 FANTASY V VIEW NONE TV-G VIOLENCE TV-Y select CONTENT item. -
Page 28: Canadian French Rating Set-Up
CANADIAN FRENCH RATING SET-UP PICTURE TIMER TUNING SET UP Please enter the V chip menu first. 8 ans+ 13 ans+ Press CH+ or CH- button to 16 ans+ 18 ans+ MPAA RATING select CANADIAN FRENCH TV PARENTAL GUIDELINES Move[ Select[ CANADIAN ENGLISH RATING RATING item. -
Page 29: Troubleshooting Guide
Others Troubleshooting Guide Check the following before requesting service. SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION Connect the AC power cord No power The AC power cord is not connected. to the AC outlet TV station experiencing problems. Try another channel. Picture control is not adjusted. Check picture control adjustments. -
Page 30: Care And Maintenance
RECEPTION DISTURBANCES Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results if not using cable or a satellite. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local cable company broadcast. -
Page 31: Specifications
Others Specifications Power Supply: AC 120V, 60Hz Power Consumption: 70W Dimensions: 23.2(W) 18.2(H) 18.5(D) inch Weight(kg/lb): 26 kg/58 lb CRT: 20" FLAT SCREEN Audio Output: Receiving channel: 2-13 14-69 CATV 2-69, (A-6)-(A-1), A-W, (W+1)-(W+28) Total 181 channels Color System: Television: NTSC-M AV: NTSC3.58/4.43, PAL 4.43 Antenna Impedance: VHF/UHF 75 ohm... - Page 32 PRINTED IN RECYCLED PAPER 604-K20495-00...
