- Page 1 Installation Guide Installation USB 2.0 External VGA Video Card (GUC2015V) USB 2.0 External DVI Video Card (GUC2020DW6) GUC2015V/GUC2020DW6 PART NO. M1110...
- Page 2 All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this document.
-
Page 3: Table Of Contents
Table of Contents Package Contents Overview System Requirements Software Installation - For Windows XP user: - For Windows Vista user: - For Mac OS X 10.4 and above user: Configuration Software Un-installation Specifications Federal Communications Commission (FCC) Statement CE Statement Limited Warranty Contact... -
Page 4: Package Contents
Package Contents GUC2015V: – 1 x USB 2.0 External VGA Video Card – 1 x USB 2.0 Cable – 1 x Installation CD – 1 x User Manual – 1 x Warranty/Registration Card GUC2020DW6: – 1 x USB 2.0 External DVI Video Card –... -
Page 5: Overview
Easily connect up to six monitors using a USB 2.0 Cable • Enjoy resolutions of up to 1280 x 1024 at 32 bit color with GUC2015V USB External VGA Video Card; or 1600 x 1200 with GUC2020DW6 USB External DVI Video Card.. -
Page 6: System Requirements
System Requirements Minimum system requirements: • Computer with 1.2GHz or higher processor speed. Intel Pentium/Celeron family, or AMD K6/Athlon/ Duron family, or compatible processor recommended. • 256MB or RAM or higher (512MB recommended) • Available USB 2.0 port • 30MB of available disk space •... -
Page 7: Software Installation
Software Installation For Windows XP user: Insert the included CD to the CD-ROM/ DVD-ROM of your computer. The installation process will automatically load. Select the preferred language for the installation and click on I Accept to continue. Restart your system after the installation completes. -
Page 8: For Windows Vista User
For Windows Vista user: Insert the included CD to the CD-ROM/ DVD-ROM of your computer. The installation process will automatically load. Click on Run setup.exe to continue. Select the preferred language for installation and click on I Accept to continue. Restart your system after installation... -
Page 9: For Mac Os X 10.4 And Above User
For Mac OS X 10.4 and above user: Insert the included CD to the CD-ROM/DVD- ROM of your computer. Browse through the content on the CD and find a folder named Mac driver. Execute the Displaylink-OSX01.1.3b1.dmg to begin the installation for Mac OS. -
Page 10: Configuration
Card. Then connect the USB Type-A end of the cable to any available USB port on your computer. USB External VGA Video Card (GUC2015V) USB External DVI Video Card (GUC2020DW6) Once plugged in, you will see a monitor icon showing up in the system tray. - Page 11 GUC2015V, USB External VGA Video Card, connect the male end of the VGA cable (not included) to the VGA port on the USB External Video Card. Then connect the other male end of the VGA cable (not included) to the VGA port on your monitor/display.
- Page 12 Click on the monitor icon to bring up the configuration menu. When connecting the USB External VGA Video Card or USB External DVI Video Card to your computer, it is configured to function as the Extended Mode by default, and you can also change to Mirror mode as you prefer. Note: When in Extended Mode, you will see the wallpaper displaying on the monitor/display that is...
- Page 13 When in Mirror Mode, you will see a clone desktop displaying on the monitor/display that is connected to the USB External VGA Video Card or USB External DVI Video Card. You can also adjust the screen resolution using this menu. The supported resolution of your monitor/display will show up on the right side of the menu and you can select any preferred setting as you wish.
- Page 14 Another way to configure your setting is to select Advanced… and it will bring up the Display Settings window. You may apply different adjustments to your USB External VGA Video Card or USB External DVI Video Card.
-
Page 15: Software Un-Installation
Software Un-installation For Windows XP user: Click on Start, then select Control Panel. Double click on Add/Remove Programs then select Displaylink Graphics and click on Remove button to uninstall the program. When it is finished, restart your computer. For Windows Vista user: Click on the Vista icon on your desktop, then se- lect Control Panel. -
Page 16: Specifications
Specifications GUC2015V USB External VGA Video Card Function Power Consumption Video Resolution Ports Operating Temperature Storage Temperature Operating System Support USB specificaton Humidity Power Connections Connectors Video Ouput Color Depth GUC2015V 1280 x 1024 1 Female VGA / 1 USB 2.0 Type mini-B 68 ~ 122 °... - Page 17 GUC2020DW6 USB External DVI Video Card Function Power Consumption Video Resolution Ports Operating Temperature Storage Temperature Operating System Support USB specificaton Humidity Power Connections Connectors Video Connections Power Mode Color Depth GUC2020DW6 Max. 1600 x 1200 1 Female DVI / 1 USB 2.0 Type mini-B 68 ~ 122 °...
-
Page 18: Federal Communications Commission (Fcc) Statement
Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) his equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 19 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOL- LOWING TWO CONDITIONS: 1. this device may not cause interference and 2. this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 20: Ce Statement
CE Statement This device has been tested and found to comply with the requirements set up in the council directive on the approximation of the law of member states relating to EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC and R&TTE Directive 99/5/EC. The product has been approved for LVD and covered the following countries: Belgium, Denmark, France, Germany, Italy, Portugal, U.K., Spain, Sweden... -
Page 21: Limited Warranty
The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose.The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or updates. For further inquiries please contact IOGEAR. -
Page 22: Contact
Contact IOGEAR 23 Hubble Irvine, CA 92618 P 949.453.8782 F 949.453.8785 Visit us at: www.iogear.com... - Page 24 About Us About Us IOGEAR offers connectivity solutions that are innovative, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
