IOGear Bluetooth 2.0 USB Micro Adapter GBU421 Installation Manual

Bluetooth 2.0 usb micro adapter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation

Guide

Bluetooth

2.0 USB Micro Adapter

GBU421

PART NO. M1204

Table of Contents

Need help?

Do you have a question about the Bluetooth 2.0 USB Micro Adapter GBU421 and is the answer not in the manual?

Questions and answers

Summary of Contents for IOGear Bluetooth 2.0 USB Micro Adapter GBU421

Page 1 Installation Installation Installation Guide Bluetooth 2.0 USB Micro Adapter ® GBU421 PART NO. M1204...
Page 3 2.1Mbps data rate. They also enable wireless Personal Area Network (PAN) connectivity to Bluetooth enabled devices such as PDA’s, printers, cellular phones, computers, etc. ® We hope you enjoy using your IOGEAR Bluetooth to 2.0 USB Micro Adapter, another connectivity solution from IOGEAR.
Page 4: Table Of Contents
Table of Contents Package Contents Overview Features Requirements Introduction Installation-Windows XP Initial Bluetooth Conﬁ guration Wizard Installation-Windows Vista Uninstall Drivers Installation-Mac OS X Connect to a Cellular Phone Connect to Network Access Connect to a Printer Connect to a PDA Pairing Installation - Windows XP Service Pack2 Speciﬁ...
Page 5: Package Contents
1 Warranty Card / Registration Card The Bluetooth Installation CD contains the following: • Bluetooth drivers for Windows 2000/XP/Vista • User Manual for IOGEAR Bluetooth * If any items are damaged or missing, please contact your dealer. 2.0 USB Micro Adapter ®...
Page 6: Overview
Overview Bluetooth is a low-power wireless networking standard which uses short radio waves to allow electronic devices to communicate with each other without using cables. The following applications are supported by Bluetooth • Synchronize your Bluetooth PDA with your computer. •...
Page 7 Most Bluetooth-enabled devices have the capability to act as: • A Bluetooth server - these devices provide one or more services, such as access to the Internet, or to other Bluetooth devices. • A Bluetooth client - these devices use the service(s) provided by Bluetooth servers. Most Bluetooth devices that can act as both server and client, and can often do both at the same time.
Page 8: Features
Features • Eliminates cables between your computers • Controls and communicates with Bluetooth enabled devices • Enables wireless Personal Area Network (PAN) connectivity • Bluetooth speciﬁ cation 2.0 compliant • USB speciﬁ cation 1.1 compliant • Up to 10 meter (30 feet) wireless working distance for Bluetooth •...
Page 9: Requirements
Requirements System Requirements Hardware Requirements: • Available USB port Operation System: For PCs: Windows 2000/XP/Vista For Macs: OS X v10.3.9 or later...
Page 10: Introduction
Network (PAN) connectivity to Bluetooth™ enabled devices such as PDA’s, printers, cellular phones, computers, etc. The Wireless Bluetooth™ to USB adapter is compatible with both PC and Mac. It is easy to install and use, and very portable. Another great solution from IOGEAR for home and mobile ®...
Page 11: Installation-Windows Xp
CD and instead use the Microsoft Bluetooth drivers. Make sure that the IOGEAR Bluetooth adapter is NOT plugged into the computer at this moment. Insert the IOGEAR installation CD into your CD-ROM drive. The auto-start feature will bring up the installation window to begin the driver installation.
Page 12 Click on Next to continue The wizard is now ready to being the installation. Click Install to continue.
Page 13 If you accept the license agreement, click Next. When you approach the end of the installation process, the Driver Signature Notice may appear. Simply click OK to proceed with the installation...
Page 14 During the install, a “Bluetooth Device not Found” window will appear. Do not plug in ® the Bluetooth adapter at this time, click Cancel to continue. Once the driver installation has completed, click Finish.
Page 15 In order to complete the Bluetooth installation software you will be asked to Log off from your computer. Click Yes to log off.
Page 16: Initial Bluetooth Conﬁ Guration Wizard
Initial Bluetooth Conﬁ guration Wizard - Windows XP For Windows XP Double click on the Bluetooth icon in the system tray. This will start the “Initial Bluetooth Conﬁ guration Wizard.” Click Next to continue.
Page 17 Next, enter a unique name for this computer. This name will be displayed to other Bluetooth devices. Select a computer type from the drop-down menu and click Next. Click Next to conﬁ gure the services this computer will offer to other Bluetooth devices.
Page 18 Select the services that you would like your computer to offer. Click Next to proceed. The Bluetooth software will install the selected services. This process may take a while. If you wish to setup a Bluetooth device now click Next. Otherwise click Skip and click Finish on the ﬁ...
Page 19: Installation-Windows Vista
Installation-Windows Vista Insert the IOGEAR installation CD into your CD-ROM drive. Make sure the IOGEAR Bluetooth adapter is NOT plugged into the computer before installing the software. Insert the IOGEAR installation CD into your CD-ROM drive. The auto-start feature will bring up the auto play options for the instal- lation CD.
Page 20 Click Next to continue. If you accept the agreement, click Next to continue.
Page 21 Click Next to continue. Click Install to being the installation.
Page 22 If you are prompted by the windows security message select “Install this driver soft- ware anyway.” During the install, a “Bluetooth Device not Found” window will appear. DO NOT plug in the Bluetooth adapter at this time, simply click Cancel to proceed with the driver installation without connecting the Bluetooth device.
Page 23 Click Finish to complete the installation. In order to complete the Bluetooth software installation, you will be asked to Log off from your computer. Click Yes to log off.
Page 24 Initial Bluetooth Conﬁ guration Wizard - Vista Double click on the Bluetooth icon in the Click Next to continue. system tray. This will start the “Initial Bluetooth Conﬁ guration Wizard.
Page 25 Enter a unique name for this computer. This name will be displayed to other Bluetooth devices. Select a computer type from the drop-down menu and click Next. Click Next to conﬁ gure the services this computer will offer to other Bluetooth devices.
Page 26 Select the services that you would like your computer to offer. Click Next to proceed. The Bluetooth software will install the selected services. This process may take a while. If you wish to setup a Bluetooth device now click Next. Otherwise click Skip and click Finish on the ﬁ...
Page 27: Uninstall Drivers
Uninstall Drivers Windows XP Service Pack 2 First, unplug the IOGEAR USB Bluetooth 2.0 USB Micro Adapter from your computer Go to Control Panel (Start > Settings > Control Panel) Click on Add or Remove Programs Click on IOGEAR Bluetooth Software and...
Page 28: Installation-Mac Os X
Installation-Mac OS X Use of the IOGEAR Bluetooth Micro Adapter requires MAC OS X v10.3.9 or later. There is no need to install any additional drivers, as Apple provides all required Bluetooth drivers under Mac OS X v10.3.9. Simply plug in your Bluetooth available USB port on your computer, and go to System Preferences.
Page 29 If you have already connected a device under 10.5 the Bluetooth window will look like this. Instead of clicking the Set Up New Device button, click the button with a plus (+) symbol below the device list. This will initiate the Bluetooth Setup Assistant; click Continue to proceed...
Page 30 On this window, you can select what type of Bluetooth device you want to setup. Please make your choice below and then click Continue. Your computer will search Bluetooth devices in your area and display them under the window below. Select the device you wish to communicate with and then click Continue to pair/connect to your device.
Page 31: Connect To A Cellular Phone
Connect to a Cellular Phone How to connect to a Cellular Phone (Bluetooth Enable) For Windows XP Double-click on the IOGEAR Bluetooth icon in the system tray. Next, click on Search for devices in range. As illustrated below, the Bluetooth-enabled cell...
Page 32 To pair with your cell phone, right click on the cell phone that you would like to connect and select Pair Device. You will be prompted to enter a security code. If your cell phone has a speciﬁ c security code please enter on the security code ﬁ...
Page 33 To ﬁ nd out what services are available on your phone, simply double click on the phone icon. Services offered by your cell phone may depend on the features supported by your speciﬁ c model and may or may not require ad- ditional software by the phone manufacturer.
Page 34 Bluetooth Phone setup on Windows XP Right click on the system tray and select Add a Bluetooth Device Make sure to set your Bluetooth cellular phone in “discoverable” mode. Click Next to continue.
Page 35 Your computer will search for all Bluetooth devices in your area and list them as shown below. Select your cellular phone and click Next. If your cell phone has a speciﬁ c passkey you will need to enter it on the Bluetooth security code box, otherwise please enter a random 4 digit passkey and click Pair Now.
Page 36 Note: Your cell phone will prompt you to enter the same security code. Make sure you enter the same security code as on the computer to complete the pairing process. You will be asked to select the services that are available on your phone. It is recommended to leave all services checked.
Page 37: Connect To Network Access
Connect to Network Access For Windows XP Double-click on the Bluetooth icon in the system tray. Next, click on Search for devices in range. As illustrated below, the Bluetooth-enabled computer is found.
Page 38 Double click on the device to display a list of its services. To establish a network connection, right click on Network Access and select Connect to Network Access Point. A message by the Bluetooth software will appear below the task bar. Double click on the bluetooth icon or on the message bubble.
Page 39 You will be asked to enter a security code to establish a secure Blueooth connection with the other PC. Please enter a 4 digit security code and click OK. Note: Once you click OK, you will be prompted to accept/deny the connection on the other computer.
Page 40 For Windows Vista Double click on the Bluetooth icon in the task bar to bring up My Bluetooth Places. Double click on Find Bluetooth Devices...
Page 41 Your computer will search for all Bluetooth devices around your area. To connect to a Bluetooth computer, right click on the Bluetooth computer that you would like to connect and select Pair Device. To establish a secure connection with the other Bluetooth enabled computer, you will need to enter a passkey.
Page 42 On the other Bluetooth enabled computer that you are attempting to connect, you will receive a message on the task bar asking for permission to establish the Bluetooth connection. If you accept the connection, it will ask you to enter the same security code that you enetred on the ﬁ...
Page 43 As an example, we will establish a connection using the Network Access service. To do so, right click on the Network Access and select Connect to Network Access Point. A message will appear in the task bar. Please double click on the message and enter the same security code that you have entered to connect with the Bluetooth enabled computer.
Page 44 A Bluetooth connection is shown when you open Computer from the start menu. Now your device will be able to share its internet connection, printers, and ﬁ les. (Make sure the desired share options’ checkboxes are checked under Bluetooth setting by right-clicking on the Bluetooth icon in the system tray.
Page 45: Connect To A Printer
Connect to a Printer How to connect to a Bluetooth Enabled Printer For Windows XP Double-click on the IOGEAR Bluetooth icon in the system tray. Next, double click on “ in range”. Search for devices...
Page 46 Right-click the printer you would like to add and select Add Printer. Click OK to install the printer. Note: If this is a new printer you are setting up, you will need to install the driver and software of your printer. Please follow the printer setup wizard to setup your printer.
Page 47 If your printer is already installed, the printer properties window will appear. Click on Print Test Page to print a test page.
Page 48 How to connect to a Bluetooth Enabled Printer For Windows Vista Double-click on the IOGEAR Bluetooth icon in the system tray. Double click on Find Bluetooth Devices...
Page 49 Please make sure that your Bluetooth enabled printer is powered on. An icon of your printer will show up on the Bluetooth window. Right click on the printer and select Add Printer. If this is the ﬁ rst time your are setting up a printer, make sure that you install the printer driver prior to adding the Bluetooth enabled printer on your computer.
Page 50: Connect To A Pda
Connect to a PDA How to connect to a Bluetooth Enabled PDA For Windows XP Double-click on the Bluetooth icon in the system tray. Next, double click on “ in range”. Search for devices...
Page 51 Right click on the Bluetooth enabled PDA device and select Pair Device to establish the connection with the PDA. You will be asked to enter a four digit security code. Please enter a random 4 digit passkey and click OK to continue. Note: Your PDA will prompt you to enter the same security code .
Page 52 To ﬁ nd out what services are available on your PDA, double click on the Bluetooth PDA icon.
Page 53 How to connect to a Bluetooth Enabled PDA For Windows Vista Right click on the Bluetooth icon next to the task bar and select “Add a Bluetooth Device”. The Bluetooth Setup wizard will start, click Next to continue.
Page 54 The Bluetooth Setup wizard will identify all Bluetooth devices arround your area. Select the PDA and click Next to continue. You will be asked to enter a security code to connect with the PDA. Please enter a random 4 digit code and click Pair Now.
Page 55 Your PDA will prompt you to enter the same security code. Enter the security code on your PDA to establish the Bluetooth connection. Depending on your PDA, you will be asked to select the services that are equipped on your PDA.
Page 56: Pairing
Pairing What is “Pairing?” Pairing is a Bluetooth function that enables Bluetooth devices to remain permanently linked to another. What “Pairing” means in terms of security? As mentioned, Pairing allows devices to permanently link with each other. The pass key authentication will also be perpetuated in Pairing, meaning that devices will not ask for a pass key once they are paired.
Page 57 Pairing Devices Right-click on the Bluetooth device and select on “Pair device”. Enter a Pass Key when asked. Note: The Pass Key on both devices must be the same! Example: If Device 1 tries to pair with Device 2, Device 1 will prompt for a Pass Key. Enter any Pass Key.
Page 58: Installation - Windows Xp Service Pack2
For more information, please visit the Microsoft website at www.microsoft.com. To use the Microsoft Bluetooth stack, simply plug in your IOGEAR Bluetooth adapter into an available USB port on your computer. Windows will automatically detect the Bluetooth device and install all necessary drivers.
Page 59 Optionally, you can ﬁ nd this in >Bluetooth Devices. Control Panel To connect with your Bluetooth devices, simply right-click on the Bluetooth icon on the tray bar and select Add a Bluetooth Device.
Page 60 Make sure to set your Bluetooth device in “discoverable” mode and check the box as shown on the picture. Your computer will search for all theBluetooth devices in your area and list them. Select the desired device, and click Next.
Page 61 Please consult the user manual of your Bluetooth device to see if you need a Passkey to pair/establish a connection. Your Bluetooth device will then connect to the IOGEAR Bluetooth adapter. To ﬁ nish the process, simply click Finish.
Page 62: Speciﬁ Cation
Speciﬁ cations GBU421 Connectors Data Rate Frenquency Band Humidity Interface Modulation Operating Temperature Security Sensitivity Transmission Power Weight USB Type A1 2.1 Mbps 2.402 GHz - 2.4835GHz Unlicensed ISM band 10% - 90% non-condensing GFSK (Gaussian Frenquency Shift Keying) 0°C - 50°C Pairing, Encrption, Authentication Minimum - 76dB 4dBm max with power control (Class 2)
Page 63: Technical Support
Technical Support If you need technical support, please check out our IOGEAR Tech Info Library (T.I.L.) at www.iogear. com/support for the latest tips, tricks, and troubleshooting. The IOGEAR T.I.L. was designed to provide you with the latest technical information about our products. Most of the answers to your questions can be found here, so please try it out before contacting technical support.
Page 64: Federal Communications Commission
Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modiﬁ cations not expressly approved by the part responsible for com- pliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
Page 65 Operation is subject to the following two conditions: this device may not cause interference and this device must accept any interference, including interference that may cause undesired operation of the device. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the speciﬁ...
Page 66: Ce Statement
CE Statement This device has been tested and found to comply with the requirements set up in the council directive on the approximation of the law of member states relating to EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC and R&TTE Directive 99/5/EC.
Page 67: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or ﬁ...
Page 68: Contact
IOGEAR and the IOGEAR logo are trademarks or registered trademarks of IOGEAR, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc. IOGEAR makes no warranty of any kind with regards to the information presented in this document.
Page 69 The use of our technology solutions helps reduce electronic waste. HEALTH IOGEAR supports healthy and ﬁ t lifestyles. By integrating products with the latest scientiﬁ c developments, IOGEAR’s solutions enhance the life of end-users. © 2007 IOGEAR, INC.
