Summary of Contents for Wafian HR-F1
- Page 1 Wafian HR-F1 Setup and User Guide 1.3.0 Wafian Corporation 3525 Del Mar Heights Rd. #417 San Diego, CA 92130 www.wafian.com February 2008...
- Page 2 Ensure that nothing rests on your HR-F1's cables and that the cables are not located where they can be stepped on or tripped over. Do not push any objects into the openings of your HR-F1. Doing so can cause fire or electric shock by shorting out interior components.
- Page 3 NOTICE: To help avoid possible damage to the system board, wait 5 seconds after turning off the HR-F1 before disconnecting a device from the HR-F1. In addition, take note of these safety guidelines when appropriate: When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable itself. Some cables have a connector with locking tabs;...
-
Page 4: Table Of Contents
WAFIAN HR-F1 ® Thank You for choosing Wafian . This document will help you setup and use the Wafian HR-F1. For additional information please visit us at www.wafian.com/Support.htm. Table of Contents Introduction........................6 In the Box ........................6 Connections........................7 Power and Front Panel Features................... - Page 5 Playback ........................19 System Configuration ....................20 System Specifications ....................22 Notes and Troubleshooting ..................23 Recording Length and Storage Capacity ..............23 IMPORTANT DISCLAIMERS..................23 Software License Agreement..................24 Wafian HR-F1 One (1) Year Limited Warranty............. 27 Contact Wafian ......................28...
-
Page 6: Introduction
HR-F1 is a direct-to-disk high definition video disk recorder with HD-SDI and component inputs and outputs for field use. The HR-F1 can record Standard Definition or High Definition 4:2:2 10-bit video for 10+ hours. It can record 8 channels of embedded audio and 2 channels of analog or EBU/AES audio. It records at resolutions up to 1920x1080 at different frame rates. -
Page 7: Connections
The HR-F1 can be operated using DC power through external 24 volt XLR battery packs. A single Anton Bauer Cine VCLX battery pack will allow operation of the HR-F1 for approximately 6 hours while idle, or 4 hours while recording continuously. Note that if the power supply is overloaded, it will stop all output voltages. Once the problem has been resolved, it will automatically reset itself and the power off switch will be cycled, allowing normal operation. -
Page 8: Settings
Settings Before you record, your system must be setup to match your desired video settings. Access the Presets window to select preset settings, or to specify your own settings. To do so click on the media path and record settings link on the record mode window, which will open the Presets dialog. -
Page 9: Settings For 720P60 Slowmo @24P Recording (2.5X Slow-Mo Effect) Via Hd Component
HDSDI Video Format HDSDI_720p_5994 Component Video Input AnalogIn_720p_5994 Component Video Output AnalogOut_720pSMPTE Input Color Bit Depth 10-Bit YCbCr Encoder Quality High Record Type AudioAndVideo Final Framerate None Pull Down Removal Extract24pFrom60p Settings for 720p60 SlowMo @24p Recording (2.5x Slow-Mo Effect) Via HD Component Setting Value Input Source... -
Page 10: Settings For 1920X1080 W/Pulldown Removal (24P) Recording Via Hd-Sdi
Name rules are a flexible and powerful way for the HR-F1 to create unique clip names without constant user interaction. When starting to record, the HR-F1 creates the clip name from the text in the Name Rule field and replaces variables (text enclosed in curly brackets, {variable}) with their current value. Variables allow you to provide meaningful clip names, specify sub-directories, and uniquely identify clips. -
Page 11: Video Tab
Please see the Recording section of this document for details regarding freeze frame capturing. Video tab You need to set the HR-F1’s record settings to match your input source. Input Source Depending on the hardware connected to the HR-F1, users may choose to record using HDSDI (digital video) or Component Analog. -
Page 12: Hdsdi Video Format
Use HDSDI signal reference FreeRun Do not use a reference source In general the operator should use Input1 for this field. When linking one HR-F1 to another, be sure to set the reference source of the second HR-F1 to Input1. -
Page 13: Up Convert 8-Bit Source To 10-Bit (Cineform Intermediate Only)
Up convert 8-bit source to 10-bit (Cineform Intermediate Only) Users select this check box only when using a camera that outputs an 8 bit image. When selected, the HR-F1 compresses 8 bit video with the 10 bit video codec in order to increase precision and preserve quality. This mode increases the bit rate and disk consumption. -
Page 14: De-Interlace Input Video (Sd Only)
Users may select to record the time code embedded in the HDSDI input signal. Alternatively, time of the day may be used to generate a time code, or the HR-F1’s recording time code may be selected. Note that Record Run is a global setting stored by the system for any presets. -
Page 15: Optional Ltc Time Code
00;00;00;00. By default, the HR-F1 stores the time code of the first frame it records on every capture. This information is appended to the end of the files it generates. The HR-F1 recognizes this information and regenerates a time code based on the clock for the given file during playback. -
Page 16: System Settings Tab
HR-F1 system, or restart the Interface. Within the Media Library section, users can select to sort the clips in the media bin based on their creation date, or their file name. Access to the HR-F1’s Event Log is also present in this tab. -
Page 17: Recording
These meters are helpful for tuning and diagnosing settings that may cause frame dropping. Because the HR-F1 is a tool for professionals pushing the hardware’s performance, there are setting options that the hardware may not be able to sustain. -
Page 18: Auto Recording
To disable it, simply click on the AUTO button once again and deselect Auto Record. Keyboard Controls If you have a keyboard connected to your HR-F1, pressing Ctrl+r will cause recording to start, while pressing Ctrl+s will cause recording to stop. Freeze Frames To record freeze frames while previewing or recording, press the freeze frame button in the upper right corner of the screen. -
Page 19: Playback
Keyboard Controls If you have a keyboard connected to your HR-F1, pressing certain shortcut keys will allow you to skip to different parts of your clips. The right or left arrow keys on your keyboard will display the next or previous frame. You can... -
Page 20: System Configuration
Accessing Your Media Remotely The Wafian HR-F1 can show up as a node on your local network. Each Wafian HR-F1 is given a unique name based on its serial number. For example, if your serial number is HRF1-0003, the system name will be Wafian- HRF1-0003. - Page 21 Monitoring Video with External Monitors To connect your Wafian HR-F1 to a VGA or DVI monitor for external monitoring, use the VGA port in the rear panel. For DVI monitoring, simply connect your monitor using a DVI to VGA adaptor. This will mirror the control video interface displayed on the HR-F1 front panel at 1024x768 resolution.
-
Page 22: System Specifications
System Specifications HDSDI: HDSDI: 1 Input, 2 Output BNC Component and Composite: HD Component In & Out SD Component/Composite in & Out Video Formats: SDI, HDSDI 1920x1080: 23.98p, 24p, 25i, 25p, 29.97i, 29.97p, 30i, 30p 1920X1080: 23.98psf, 24psf, 25psf 1280X720: 50p, 59.94p, 60p NTSC 4:2:2 - 8 or 10 bit color Time code RP188, generated, time-of-day,... -
Page 23: Notes And Troubleshooting
For other formats such as 720p60 the HR-F1 can record up to 6.5 hour clips. However, recording length may vary if the HR-F1 is exposed to extreme heat, or if its disks are close to being full. For longer continuous recording duration, lower the encoding quality. -
Page 24: Software License Agreement
(tubes), and converters are in proper working condition. Please know that the quality of the image that the HR-F1 receives can be affected if you are connected to an irregular source of power or if your peripherals have been damaged. - Page 25 Software, even if Wafian has been advised of the possibility of such damages. UNDER NO CIRCUMSTANCES SHALL WAFIAN OR ITS RESELLERS BE LIABLE TO...
- Page 26 13. Licensee agrees not to export the Software or any part or direct product thereof in violation of U.S. export laws and regulations. Licensee may not assign this agreement to any third party without first obtaining the express written consent of Wafian, and any assignment by Licensee without such consent shall be null and void.
-
Page 27: 12. Wafian Hr-F1 One (1) Year Limited Warranty
Wafian Corporation (“Wafian”) warrants the hardware product against defects in materials and workmanship for a period of ONE (1) YEAR from the date of original purchase. If a defect exists, Wafian will, at its option, (1) repair the product at no charge, using new or refurbished replacement parts, (2) exchange the product with a product that is at least functionally equivalent to the original product. -
Page 28: Contact Wafian
Before delivering your product for warranty service, it is your responsibility to keep a separate backup copy of the software and data, and disable any security passwords. Data recovery is not included in the warranty service and Wafian in not responsible for data that may be lost or damaged during transit or repair.
