5-Speed
BENCH DRILL PRESS
with Laser
OWNER'S MANUAL
WARNING:
Read carefully and understand all INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.
Item # 155301

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 155301 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Industrial Tools 155301

Summary of Contents for Northern Industrial Tools 155301

  • Page 1 5-Speed BENCH DRILL PRESS with Laser OWNER'S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 155301...

  • Page 2: Intended Use

    Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For future reference, please complete the owner's record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Electrical Safety

    • Be aware of all power lines, electrical circuits, water pipes and other mechanical hazards in your work area, particularly those hazards below the work surface hidden from the operator's view that may be unintentionally contacted and may cause personal harm or property damage. •...
  • Page 4 • Avoid accidental starting. Do not carry the power tool with your finger on the switch. Ensure the switch is in the off position before plugging tool into power outlet. In the event of a power failure, while a tool is being used, turn the switch off to prevent surprise starting when power is restored.
  • Page 5 • Clamp workpiece or brace against the left side of the column to prevent rotation. If it is too short or the table is tilted, clamp solidIy to the table and use the fence provided. • If the workpiece overhangs the table such that it will fall or tip if not held, clamp it to the table. Provide auxiliary support.

  • Page 6: Getting To Know Your Drill Press

    Check the parts againts the above list and refer to the diagrams. Should there be any deficiencies or damage, you should contact Northern Tool + Equipment. GETTING TO KNOW YOUR DRILL PRESS 1. Belt Tension Lock Handles 2. Feed Handle 3.
  • Page 7 6. Find elevation worm gear shaft in the loose parts bag. Insert the elevation shaft into the table support and extend the shaft through the opening as far as possible. The crank is to be installed on the elevation worm gear shaft, the set screw is to be aligned with the flat portion of the shaft.
  • Page 8 Laser attachment Introduction Safety rules for laser lights The laser light/laser radiation used in the LightSabre system is Class 2 with maximum 1mW and 640 - 660nm wavelengths. These lasers do not normally present an optical hazard, although staring at the beam may cause flash blindness.

  • Page 9: Operation

    Fig 4 Fig 5 Fig 6 CAUTION! Remove the laser light batteries when the tool is to be stored without use for a few days or more. If left in position, the batteries might leak and damage the laser light assembly. Damage due to leaking batteries is not covered under warranty.

  • Page 10: Warranty

    WARRANTY One-Year Limited Warranty For warranty questions, call 1-800-222-5381 DIAGRAM & PARTS LIST...
  • Page 12 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
