RLH Industries RLH 5 Port User Manual

USER GUIDE
RLH 5 Port
Hardened Ethernet Switch
SLIMLINE DIN MOUNT

Introduction

The RLH 5 Port SlimLine Ethernet switch is a hardened,
DIN mountable switch that supports 10/100M Ethernet.
The switch is housed in a rugged aluminum alloy
enclosure that requires only 32mm of rack space. The
RLH 5 port Ethernet switch is an ideal solution for
industrial Ethernet applications that require temperature
hardened durability. It features convenient port status
LEDs, auto negotiation and auto MDI/MDI-X.

Key Features

• Ideal for critical, high voltage, remote, or un-manned
locations that must remain operating 24/7/365
• IEEE 802.3 10Base-T UTP and 100Base-TX
• RJ45 UTP ports with 10/100M auto-negotiation
• MDI-II/MDI-X auto detection
• Convenient port status LED indicators
• Environmentally hardened to operate in -40˚F to +185˚F
(-40˚C to +85˚C) environments
• Uses a local 12~36VDC power source
• Standard 35mm DIN rail mount
• Covered by our Exclusive Unconditional Lifetime Warranty
