OPERATING INSTRUCTIONS

Control Panel

ON/OFF: Press the ON/OFF button to start the appliance. NOTE: the default fan
speed is Medium and the fan mode is Normal. When switching OFF, the fan will
continue for approximately 5 minutes to dry the honeycomb filter. This is normal
and is designed to prolong the life of your cooler. If you have been using the
appliance as a heater, the fan will also continue to allow the heater element to
cool down. In all modes, NORMAL, NATURAL and SLEEP mode the LCD light will
flash until the cooling or drying procedure is complete. DO NOT switch OFF at
the power supply until the procedure has completed.
SPEED: Press to select the desired fan speed (LOW/MEDIUM/HIGH). The
sequence is as follows:- M – H – L – M. The corresponding LED will illuminate.
The fan speeds DO NOT work with the WARM function.
VANE: Press the vane button and the vertical louvers will oscillate to provide
airflow to a wide area. The corresponding LED will illuminate. The horizontal
louvers can be manually adjusted to direct the height of the air flow. This is
useful to provide cool air over a bed during hot summer nights. The vane button
can be pressed at any time to stop oscillation. This locks the vertical louvers in a
fixed position to direct air to your chosen direction.
TIMER: Set the time by pressing the timer button to select a desired time for the
appliance to switch OFF. The range can be set between 0.5 and 7.5 hours. The
corresponding LED will illuminate.
3
Remote control
sensor
