SERVICE MANUAL

Colour Television

The above models are classified as either green products (*1) or non-green products. Green product(s) are
indicated by an underlined serial number. This Service Manual describes replacement parts for green
product(s). When repairing any green product(s), use the parts described in this manual and lead-free solder
(*2).
For (*1) and (*2), see the next page.
Use this Service Manual in conjunction with the original Service Manual (File No. 020-200518) for 46HM95.
© TOSHIBA SINGAPORE PTE LTD
46HM95
FILE NO. 023-2006133GR
SUPPLEMENT
Pubished in Singapore Feb. 2005 Green

Advertisement

loading

  Related Manuals for Toshiba 46HM95

  Summary of Contents for Toshiba 46HM95

  • Page 1: Service Manual

    When repairing any green product(s), use the parts described in this manual and lead-free solder (*2). For (*1) and (*2), see the next page. Use this Service Manual in conjunction with the original Service Manual (File No. 020-200518) for 46HM95. Pubished in Singapore Feb. 2005 Green © TOSHIBA SINGAPORE PTE LTD...
  • Page 2: Green Product Procurement

    Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities.
  • Page 3: Chassis And Cabinet Replacement Parts List

    • The PC board assembly with mark is no longer available after the end of the production. • The green parts describes in "G" mark, listed to the left side of the Parts No. item. Model : 46HM95 Capacitors..... Ceramic Disk...
  • Page 4 Location Parts No. Description Location Parts No. Description C680 76073094 CAPACITOR, ELECTROLYTIC, 50V 1000UF M CA87 76109123 CAPACITOR, CERAMIC CHIP, 50V B 0.012UF K C681 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K CA88 76109333 CAPACITOR, CERAMIC CHIP, 25V B 0.033UF K C687 76796101 CAPACITOR, ELECTROLYTIC, 35V 100UF M CA91...
  • Page 5 Location Parts No. Description Location Parts No. Description CC27 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CE87 76073189 CAPACITOR, ELECTROLYTIC, 35V 1000UF M CC28 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M CE88 76676470 CAPACITOR, ELECTROLYTIC, 100V 47UF M CC30 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CE89 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J...
  • Page 6 Location Parts No. Description Location Parts No. Description CV41 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K ZC06 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 CV43 76105330 CAPACITOR, CERAMIC CHIP, 50V CH 33PF J ZC07 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 CV44 76105270 CAPACITOR, CERAMIC CHIP, 50V CH 27PF J ZC08...
  • Page 7 Location Parts No. Description Location Parts No. Description RC17 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RS27 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RC18 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RS28 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RC19 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RS37 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RC20...
  • Page 8 Location Parts No. Description Location Parts No. Description RA75 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R602 76011272 RESISTOR, CHIP, 1/20W 2.7K OHM J RC12 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RC02 76011220 RESISTOR, CHIP, 1/20W 22 OHM J RC16 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RC03...
  • Page 9 Location Parts No. Description Location Parts No. Description RB516 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RV37 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RB517 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RV40 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RB519 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RV51...
  • Page 10 Location Parts No. Description Location Parts No. Description LE86 23248432 COIL, CHOKE, TLN3499AH MJ60 23389360 FFC, P0.5-50P-L80(GOLD) P0.5-50P-L80(GLD) LE87 23248432 COIL, CHOKE, TLN3499AH T862 23217780 TRANSFORMER, CONVERTER TPW3570AS LE88 23248425 COIL, CHOKE, TLN3441AF TE62 23217781 TRANSFORMER, CONVERTER TPW3571AS LE88 23248445 COIL, CHOKE, TLN3441AH L8960 23103828 INDUCTOR, BEAD, TEM2121M LF11...
  • Page 11 Location Parts No. Description Location Parts No. Description D812 23357852 DIODE, ZENER, MTZJ9.1C DF25 23362214 DIODE, SCHOTTKY VRM30 IO3.0 RSX301L-30 TE25 D812 23357625 DIODE, ZENER, RD9.1ESA B3 DV161 23357854 DIODE, ZENER, MTZJ10B D813 23357512 DIODE, AL01Z DV162 23357854 DIODE, ZENER, MTZJ10B D815 23357748 DIODE, ZENER, MA8062-M DV163...
  • Page 12 Location Parts No. Description Location Parts No. Description QE95 23205446 TRANSISTOR, 2SC2412K, Q T146 Q8950 23205347 TRANSISTOR, KTC4075Y/P QE97 23205446 TRANSISTOR, 2SC2412K, Q T146 Q8951 23205347 TRANSISTOR, KTC4075Y/P QB81 23205446 TRANSISTOR, 2SC2412K, Q T146 Q8960 23205347 TRANSISTOR, KTC4075Y/P QB84 23205446 TRANSISTOR, 2SC2412K, Q T146 Q8961 23205347 TRANSISTOR, KTC4075Y/P QB509...
  • Page 13 23165495 TERMINAL, EARTH PHI3 MET31-0332 A184 23469392 INSULATOR, 05_LENS_GASKET 62HM195;C055045E B899 23165495 TERMINAL, EARTH PHI3 MET31-0332 A201 23533349 COVER, BEZEL PURCHASE ASM 46HM95;S1304E796 PJ22A 23713421 CONNECTOR, 0.5MM 50P FH12-50S-0.5SV A204 23532764 COVER, BACK COVER 46HM84;S1304F050 PJ60A 23713421 CONNECTOR, 0.5MM 50P FH12-50S-0.5SV...
  • Page 14 Location Parts No. Description Location Parts No. Description SK08 23587538 SERVICE KIT, S TO F CABLE S TO F CABLE SK04 23587528 SERVICE KIT, THERMO STAT THERMO STAT W661A 23351323 SPEAKER, 100X100 8-OHM 20W SPK-1471AM W662A 23351323 SPEAKER, 100X100 8-OHM 20W SPK-1471AM W661B 23351324 SPEAKER, TW 40X40 140-OHM 20W SPK-1472AM...
  • Page 15 46HM95 52HM95 - SUMMARY - 46HM95/52HM95 is the same as 62HM95 except for the parts tabled on back of this sheet. Use this service manual together with the service manual of 62HM95 (File No. 020-200510). TOSHIBA CORPORATION 2005 Published in Japan Jul. 2005 (YC)
  • Page 16: Replacement Parts List Differences

    REPLACEMENT PARTS LIST DIFFERENCES Location Parts No. Description Location Parts No. Description #1 : [46HM95] #2 : [52HM95] COILS & TRANSFORMERS M601B 23103840 FERRITE CORE, TFE1013 M811A 23103778 FERRITE CORE, TFE1008 M811B 23103778 FERRITE CORE, TFE1008 M906A 23103778 FERRITE CORE, TFE1008...
