Summary of Contents for TelecomSquare Emobile D25HW
-
Page 1: User Guide
JP-ET （Wi-Fi） 120220 Mobile Wi-Fi Router EMOBILE D25HW User Guide Battery Connection Time ：Up to 4 hrs Standby Time ：Up to 100 hrs Contents Page Read me first Overview and Function Accessing the Internet 5-11 • PC • iPhone / iPod touch / iPad... -
Page 2: About Connection
Read Me First 【About the rental agreement】 The user has read and agreed the TelecomSquare Rental Agreement, and shall pay the fee in full. 【Router is a precision instrument】 Please be careful for the handling. The user has to pay full compensation for the damage, arrangement of replacement and shipping charges in case of incorrect handling or usage. -
Page 3: Overview And Function
Overview and Function CONNECT ・Connect/disconnect to Internet (Manual mode) ・Press and hold to change Internet connection mode (automatic/manual） WiFi/WPS Press and hold to switch ON/OFF wireless connection. Connector Power Connect the AC adapter. Press and hold to switch ON/OFF WiFi enabled Internet Connection ・Displayed: Wi-Fi ・Displayed: Connected to... -
Page 4: Connection Speed
【Supported Connection Type】 IEEE802.11b/g 【Connection Speed】 ・You can send and receive emails, view email attachments, and browse Internet outside the office with download speed up to7.2Mbps and upload speed up to 5.8Mbps. ・We cannot assure the maximum speed. The maximum speed is best effort. ・The speed may vary depending on your location and/or the network status. -
Page 5: Accessing The Internet
Accessing the Internet Mode】 【Automatic ※The default setting is “Automatic” mode. It starts connecting to the internet automatically after powering on. 1. Press and hold the POWER button ( ) to power on the router. appears on the screen when the wireless connection is available. - Page 6 WiFi Connection (PC) The following is set-up procedures for Windows XP (SP3). Please contact the manufacturers of your devices or system administrators for further set-up information. 1. Open “START” menu, select “Connect To” → select “Wireless Network Connection.”...
- Page 7 2. Select Network name (SSID): D25HW – XXXXXXXXXXXX is various for different routers) XXXXXXXXXXXX from “Choose a wireless network,” click “Connect.” Network name (SSID) is written on the BACK of the router (P.4). Input “WEP KEY” twice in “Network Key,” click “Connect.” ※WEP KEY is written on the BACK of the router (P.4).
- Page 8 WiFi connection is established “Connected” is shown when Wi-Fi connection is established. Internet connection is OK.
- Page 9 Wi-Fi Connection （iPhone / iPod touch / iPad） The following is the set-up procedures for iPhone. The set-up procedures for iPod/iPad are almost the same. 1. From “Settings” screen, select “Wi-Fi,” switch “ON.” Select SSID: D25HW – XXXXXXXXXXXX (XXXXXXXXXXXXs is various for different routers) from “Wireless Network List.”...
- Page 10 3. WiFi connection is established. 「✔」 appears beside SSID when connection is established. 4. Internet connection is OK. Attention 【 】 Data Roaming You MUST switch OFF “Data Roaming” of your mobile phone, e.g. iPhone, when you use mobile WiFi router. You may be charged a large amount of international roaming charge by your mobile operator if you let the “Data Roaming”...
- Page 11 【 】 Send / Receive Mail Some mail services are unavailable. Available ● xxx @i.softbank.jp (special email address for Softbank iPhone’s users) ● Other PC email address (POP3; IMAP) Gmail, Yahoo email, etc. Unavailable ● (Multimedia Messaging Service) • S!mail of Softbank •...
-
Page 12: Troubleshooting
Troubleshooting My device cannot connect to the Internet via Wi-Fi. ◆ Is your device Wi-Fi enabled? Check whether Wi-Fi is enabled on your device. ◆ Did you enter the WEP key correctly? Check whether the WEP key is correctly entered and try establishing the connection. - Page 13 Forgot to return the phone at the airport Return to our office as the address below TelecomSquare Inc. 1F Narita Asahi Bldg. 2152 - 2 Fudogaoka, Narita, Chiba, JAPAN 286 - 0044...
