GrillKing 720-0719R Use And Care Manual

Liquid propane gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Liquid Propane Gas Grill
Use and Care Guide
Chair King item#:117200719R
Model # 720-0719R
Manunal version#19000507A0
WARNING
Do not store or use gasoline or
1.
other flammable liquids or
vapors in the vicinity of this or
any other appliance.
2. An LP cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance
.
Note to Consumer: Leave this Owner's Manual in a convenient place for future reference.
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-800-913-8999, 9 a.m. - 5 p.m., EST, Monday -
Friday, 9 a.m. – 6 p.m. EST. Saturday, 10 a.m. – 4 p.m. EST, Sunday. Please be
sure to have you serial number available. This number can be found on inside
the front door of your grill.
WARNING
Read this Owner's manual carefully and
be sure your gas grill is properly
assembled installed and maintained.
Failure to follow these instructions could
result in serious injury and/or property
damage. This gas grill is intended for
outdoor use only and is not intended to
be installed in or on recreational vehicles
or boats.
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0719R and is the answer not in the manual?

Questions and answers

Summary of Contents for GrillKing 720-0719R

  • Page 1 Liquid Propane Gas Grill Use and Care Guide Chair King item#:117200719R Model # 720-0719R • Parts • Assembly • Safety Rules • Use and Care • Troubleshooting Manunal version#19000507A0 WARNING WARNING Read this Owner’s manual carefully and Do not store or use gasoline or...

  • Page 2: Table Of Contents

    Table of Contents Precautions WARNING Safety Precautions---------------------------------2~4 Combustion by products produced when using Package Content List---------------------------------5 this product contain chemicals known to the Hardware Contents-----------------------------------7 State of California to cause cancer, birth defects, Preparation----------------------------------------------7 or other reproductive harm. Assembly Instructions--------------------------------8 Lighting Instructions---------------------------------17 WARNING Cleaning and Maintenance------------------------19...
  • Page 3 Precautions • Have your LP gas tank filled by a reputable A tank of approximately 12 inches in diameter by 18- propane gas dealer and visually inspected and re- 1/2 inches high is the maximum size LP gas tank to qualified at each filling.
  • Page 4 Burner Flame Check WARNING A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.

  • Page 5: Package Content List

    PACKAGE CONTENTS LIST A. Firebox--------1pc. B. Cart Leg, Front Left------1pc. C. Cart Leg, Back Left----1pc. D, Cart Leg Foot-----2pcs. E. Side panel, Left----1pc. F. Cart Brace, Left------1pc. G. Cart Leg, Front Right-----1pc. H. Cart Leg, Back Right-----1pc. I. Side panel, Right----1pc. J.
  • Page 6 S. Cart Beam, Front------1pc. T. Cart Beam, Back------1pc. U. Side Burner---------1pc. V. Side Burner Front Panel------1pc. W. Side Shelf---------------1pc. X. Side Shelf Front Panel--1pc. Y. Bezel---------------------------1pc Z.. Control Knob--------------1pc ZA.. 1.5 Volt “AA” Size Alkaline Battery----------1pc. ZB. Grease Tray -1pc. ZC.

  • Page 7: Hardware Contents

    Hardware Pack Contents Pack Description Required for assembly (pcs) 5/32-in. x 8-mm Round Head Screw 5/32-in. Lock Washer 1/4-in. x 10-mm Round Head Screw 1/4-in. Lock Washer Allen Key 1/4-in. x 65-mm Round Head Screw 1/4-in. Flat Washer Preparation Before beginning assembly, make sure all parts are present. Compare parts with package contents list and diagram above.

  • Page 8: Assembly Instructions

    Assembly Instructions Fig. 1 UNPACKING CAUTION: Obtain the aid of an assistant when handling large or heavy grill components. 1. Remove all packing material from around grill exterior. 2. Open Firebox lid and remove packing materials and components from inside Firebox. 3.
  • Page 9 Fig. 5 e). Use 4 CC Round Head Screws and 4 DD Lock Washers to attach Cart Brace, Right (J) to Cart Leg, Front Right (G) and Cart Leg, Back Right (H). Attach Cart Brace, Right (J) so that lat side will face cart interior and wide lip faces down.
  • Page 10 Fig. 9 5. Front Panel Assembly Use 2 AA Round Head Screws and 2 BB Lock Washer to attach the Front panel (O), to the Front Left Cart Leg (B). Do not attach Front Panel to Front Right Cart Leg (E) at this time.
  • Page 11 Fig.12 6. Tool Storage Slide Assembly Draw Tool Storage Front Panel forward, and insert two Tool Storage Slides (R) through the slots in tabs on Front Left and Front Right Cart Legs. Remove the Round Head Screw from each Cart Leg. Use these Screws to attach forward loophole ends of Slides to Cart Legs.
  • Page 12 8. Firebox Assembly Fig.14 NOTE: Obtain the aid of an assistant to lift the firebox. Be sure the hose and regulator hang outside the cart when placing Firebox. See Fig. 14. a). With the aid of an assistant, lift the Firebox and carefully carefully place it onto the grill cart see Fig.14.
  • Page 13 Fig. 19 10. Side Shelf Assembly a) Use 2 AA Round Head Screws and 2 BB Lock Washers to attach Shelf Front Panel (X) to Left Side Shelf (W). See Fig BB AA b) Align the holes on Side Shelf (W) with the holes on side of Front Left Cart Leg (B) and Rear Left Cart Leg (C), and attach using 4 AA Round Head Screws and 4 BB Lock Washers.
  • Page 14 Fig. 22 12. Side Burner Valve Installation a). Loosen but do not remove the two Side Burner attachment screws and washers beneath the Side Burner Bowl. In addition, remove the 2 bracket screws on the Side Burner Tube. See Fig. 22. b).
  • Page 15 13. Electronic Ignition Battery Installation Fig. 26 Unscrew the electronic ignition button and place the battery (ZA) into the housing with the positive terminal (+) facing outward. Replace the ignition button. See Fig. 26. 14. Install the Grease Tray and Grease Cup Install the Grease Tray (ZB) from the rear of the grill by sliding it onto glides beneath Grill.
  • Page 16 16. Connecting LP Gas Tank to LP Grill 1. From Rear of cart, place the foot ring of a 20-lb Fig. 29 Propane Tank into the hole in bottom panel (M). Make sure the tank valve is in OFF position. Use the tank bolt to secure the tank in a fixed position with tank valve facing out to side of Cart (Fig.

  • Page 17: Warning

    Checking for LP gas leaks 3.Be sure all gas connections are securely tightened. Never test for leaks with a flame. Prior to first use, at 4.Open the grill main lid. the beginning of each season, or every time your LP 5.Push and turn any main burner control knob to gas tank is changed, you must check for gas leaks.
  • Page 18 If Grill Still Fails To Light WARNING 1. Check gas supply and connections for leaks. Check Never lean over the grill cooking area while that all wire connections are secure. lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the 2.

  • Page 19: Cleaning And Maintenance

    Cleaning and Maintenance Cleaning Exterior Stainless Steel Surfaces To ensure a proper working unit the following proper care and maintenance is suggested. •Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Machine Cleaning Cooking Grids oils used in manufacturing process of stainless steel We suggest you wash your cooking grids in a mild soap can also cause this tanning color.

  • Page 20: Troubleshooting

    3. Inspect each burner for damage (cracks or holes) Regardless of which burner cleaning procedure you and if such damage is found, order and install a new use, we recommend you also complete the following burner. After installation check to ensure that gas steps to help prolong burner life.

  • Page 21: Failure To Comply With These Instructions Could

    Cooking Instructions Indirect Cooking To cook indirectly, the food should be placed on the left or right side of your grill with the burner lit WARNING on the opposite side. Do not leave the grill unattended. Your grill will get very hot. Never lean over Flare-ups the cooking area while using your grill.

  • Page 22: Cooking Chart

    Grill Cooking Chart FOOD Weight or thickness Temperature Time Special instructions and tips Slice or chop vegetables and dot with butter or Vegetables Medium 8 to 20 minutes margarine. Wrap tightly in heavy duty foil. Grill turning occassionally. Wrap individually in heavy duty foil. Cook Potatoes Whole Medium...

  • Page 23: Parts Diagram

    Model 720-0719R Parts diagram...

  • Page 24: Parts List

    Model 720-0719R Parts List KEY# PARTS DESCRIPTION QUANTITY KEY# PARTS DESCRIPTION QUANTITY 719R-001 Main Lid 719R-030 Tool Storage Slide Screw 719R-002 Temperature Gauge 719R-031 Tool Storage Slide 719R-003 Main Lid Screw 719R-032 Tool Storage Front Panel 719R-004 Logo 719R-033 Tool Storage Handle...

  • Page 25: Warranty

    LIMITED WARRANTY (Model # 720-0719R) Nexgrill warrants to the original consumer-purchaser only that this product (Model #720-0719R) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase. The manufacturer reserves the right to require photographic evidence of damage, or that defective parts be returned, postage and or freight pre-paid by the consumer, for review and examination.
