IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.
CONTENTS Instructions for the User Instructions for the Installer Important Safety Information Technical Specification Operation Before using Installation Control panel Positioning To start the Appliance Rear Spacers Setting the temperature Electrical Connection Use of an air circulation slider control Door Reversal Fresh food refrigeration Positioning the door shelves Positioning the inner shelves...
OPERATION Before using Remove all securing tapes. Wash inside the Do not use soap or detergent as the smell may appliance with lukewarm water and bicarbonate of linger. Dry thoroughly. soda (5 ml to 0.5 litre of water). Control panel A - Pilot light B - Thermostat control knob To Start the Appliance...
Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation.
The freezer compartment Thawing Frozen food can be thawed in the fridge or at room The four-star freezer compartment is suitable for temperature depending on the time available. Small storage of commercially frozen food and for freezing food items may even be cooked from frozen; in this fresh foods.
Normal Operating Sounds The advanced design of today’s frost free appliances mean you hear unfamilar noises during everyday operation. The diagram below describes some of the noises you may hear. These are quite normal and mean your appliance is operating correctly The thermostat control will click when starting or stopping the compressor.
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried Changing the light bulb out, DISCONNECT the appliance from the ELECTRICITY supply. If it becomes necessary to replace the lamp, press on the rear hook and at the same time slide the cover in Internal cleaning the direction indicated by the arrow.
SOMETHING NOT WORKING Before contacting your local Service Force Centre, check the following points: Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Symptom Solution No power to the appliance...
CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi-Electrolux appliance or for further information on Zanussi-Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi-electrolux.co.uk Customer Care Department...
We, Zanussi-Electrolux, undertake that if within 12 months of the date of the purchase this ZANUSSI-ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •...
TECHNICAL SPECIFICATIONS DIMENSIONS Height Width Depth 62,5 cm POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 130 W AVERAGE DAILY UNITS ELECTRICITY * 0.879 kWh GROSS CAPACITY Fridge 170 l Freezer 90 l NET CAPACITY Fridge 165 l Freezer...
INSTALLATION Warning Depending upon the position which you choose for IF YOU ARE DISCARDING AN OLD APPLIANCE your appliance, you may wish to reverse the way in THAT HAS A LOCK OR CATCH ON THE DOOR, which the door opens. To do this, refer to instructions YOU MUST ENSURE THAT IT IS MADE on “Door reversal directions”...
The plug moulded onto the lead incorporates a fuse. For replacement, use a 13amp BSI362 fuse. Only Electrical connections ASTA or BSI approved fuses should be used. Any electrical work required to install this appliance The plug must not be used if the fuse cover/carrier is should be carried out by a qualified electrician or lost.
Door reversal directions 1. Disconnect from the electricity supply. 2. Remove all loose items, including food, store food in a cool place. 3. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inches) of packing;...
