IP VIDEO CAMERA Setup Guide
O
VERVIEW
Use this guide to set up the IRIS402 Marine Network Camera on the Humminbird® control head network. We recommend that you read
this guide completely before starting the network setup.
Compatibility
Preparation
Configuration Supplies
Installation Supplies
Customer Service: To purchase the Ethernet adapter cable, AS EC CHART cable, Ethernet Switch, extension cables, and
additional accessories, contact Humminbird Customer Service by visiting our Web site at humminbird.com or by calling
1-800-633-1468.
NOTE: Product specifications and features are subject to change without notice.
The ONIX™ and ION™ control heads are compatible with the IRIS402 Marine Network
Camera. The ONIX control head displays video from one camera source. The ION
control head allows you to display video from four camera sources. Visit our Web site
at humminbird.com for the latest accessories and updated compatibility information
as additional cameras may be added to the network in the future.
Before the video camera is installed on the boat, it must be configured using a PC
with Internet access. We recommend using your home or office computer network
because a DHCP server is required for the configuration. Also, review the IRIS402
installation guide for the operating system, hardware installation, and power
requirements.
In addition to the IRIS402 Marine Network Camera, you will need the following supplies:
PC with Internet access (DHCP server required)
Networked router
Ethernet power injector for each camera
RJ45 cable for each Ethernet power injector
Power source (see the IRIS402 installation guide for hardware and voltage
requirements)
See Install the Camera(s) on your Boat to determine the installation method you will
use. Also, refer to your IRIS402 installation guide for hardware and installation
requirements. In addition to the IRIS402 Marine Network Camera, you will need the
following supplies:
Humminbird Ethernet adapter cable for each camera
OR
Ethernet power injector for each camera
Humminbird AS EC CHART cable for each Ethernet power injector
Optional Humminbird Accessories: extension cables, Ethernet switches
1
532318-1_A
Advertisement
Summary of Contents for Humminbird IP Video Camera
- Page 1 IP VIDEO CAMERA Setup Guide VERVIEW Use this guide to set up the IRIS402 Marine Network Camera on the Humminbird® control head network. We recommend that you read this guide completely before starting the network setup. The ONIX™ and ION™ control heads are compatible with the IRIS402 Marine Network Camera.
- Page 2 Use the IRIS Discovery Tool to assign an IP address to the installed camera(s). The Discovery Tool can be downloaded from your Humminbird online account or from the FAQ section of our Web site at humminbird.com. 1. From your PC, go to our Web site at humminbird.com.
- Page 3 532318-1_A IP VIDEO CAMERA Setup Guide | Set up the Camera(s) 1. Double-click the IRIS Discovery Tool.exe file on your PC desktop to open it. When you open the IRIS Discovery Tool, the connected cameras will be listed in the dialog box.
- Page 4 532318-1_A IP VIDEO CAMERA Setup Guide 4. Select the IP field, and enter the IP address for the selected camera as shown in the IP Address table. Entering the IP Address and Gateway for Camera 1 Camera Number IP Address IP Address: enter the IP address for each camera.
- Page 5 532318-1_A IP VIDEO CAMERA Setup Guide | Configure the Stream Settings Use the instructions in this section to configure the stream settings for the selected camera. You will set up each camera individually. 1. Open your Internet Explorer (or other) browser on your PC.
- Page 6 532318-1_A IP VIDEO CAMERA Setup Guide 6. Click the drop-down menus to set the following streaming settings: Resolution: 1280 x 720 Frame Rate: 15 fps Quality Level: Standard 7. Click Apply. 8. Proceed to the next section. Do not close the configuration tool.
- Page 7 | Install the Camera(s) on your Boat You can connect the camera(s) to the Humminbird control head network using an Ethernet power injector or using the Humminbird Ethernet adapter cable. Refer to the section that applies to your installation configuration.
- Page 8 IP VIDEO CAMERA Setup Guide Connecting through the Ethernet Adapter Cable 1. Turn off the Humminbird control head network and main power switch. 2. Insert the IRIS RJ45 Ethernet cable connector into the Ethernet port on the camera. Hand tighten the screw nut.
- Page 9 678 Humminbird Lane Eufaula, AL 36027 USA Humminbird®, ION™, ONIX™, and X-Press™ Menu are trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc. IRIS is a registered trademark of Iris Innovations Limited. © 2014 Johnson Outdoors Marine Electronics, Inc. All rights reserved.
