Table of Contents Pages 1. Introduction 2. Precautions 3. Compatibility Notes 4. Dipswitch Settings 5. Installation 6. iPod Operation 7. HD Radio Operation (if equipped) Selecting AUX Input Selecting Factory Satellite (if equipped) Troubleshooting Warranty Info...
Page 3
Neo Gateway & Optional Add-ons Factory Radio Not Included iPod Neo Gateway Harness Not Included Neo Gateway 11Ft. iPod Cable 3Ft. HD Radio Cable HD Radio Tuner (sold separately)
1. Introduction Thank you for purchasing the ® Neo Gateway. The Neo Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your iPod performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Neo Gateway.
3. Compatibility Notes This section will inform you of the specific requirements for your factory radio to be compatible with the Neo Gateway. These notes will inform you of any issues or circumstances that can affect the compatibility of our product with your radio, audio system, or accessories.
Radio tuner. Connect the factory antenna cable into the antenna connection on the HD Radio tuner (HDRT). 6. Plug in the male connectors on the GM5 harness into the 24 & 12-pin port on the back of the radio. Next, connect the factory 24 & 12-pin harness (if present) into the female connectors on the GM5 harness.
6. iPod Operation Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “BAND” button to switch to FM, AM and then again to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “iPod” is displayed.
Page 8
Browse by Artist Press Preset 3 to enter the browse menu. ”PL: LIST” will appear on your display. Turn the rotary tune knob until ARTIST is displayed. Press Preset 3 to select browse by Artist. The list of Artists on your iPod will be displayed one at a time in alphabetical order.
Page 9
Browse by Album Press Preset 3 to enter the browse menu. ”PL: LIST” will appear on your display. Turn the rotary tune knob until ALBUM is displayed, Press Preset 3 to select browse by Album. The Albums on your iPod will be displayed one at a time in alphabetical order.
Page 10
The Albums from the selected Artist will be displayed one at a time in alphabetical order. “AL” will be displayed in front of the name of the album to indicate you are searching for an album. Turn the rotary tune knob to cycle through the albums. Once the desired album is displayed, Press Preset 3 to select the desired Album.
7. HD Radio Operation Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “BAND” button to switch to FM, AM and then again to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “HD Radio”...
8. Selecting AUX Input Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “BAND” button to switch to FM, AM and then again to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “AUX 1”...
10. Troubleshooting Symptom Cause Remedy Radio shows iPod iPod cable is not Verify the docking cable is connected not connected connected to iPod or to the Neo Gateway, and the iPod Gateway. I can not correctly The iPod firmware Update iPod firmware for free at http:// control the iPod may be out of date.
Within the first 12 months from date of purchase, subject to the conditions above, will repair or replace the product at their discretion, if it is defective in material or workmanship providing it is returned to an Authorized Neo Car Audio dealer, with PROOF OF PURCHASE from an authorized dealer.
