Summary of Contents for Broadcast Tools SS 2.1/Terminal III
- Page 1 Manual Revised 07/06/11 Due to the dynamic nature of product design, the information contained in this document is subject to change without notice. Broadcast Tools, Inc., assumes no responsibility for errors and/or omissions contained in this document. Revisions of this information or new editions may be issued to incorporate such changes.
-
Page 2: Table Of Contents
SS 2.1 Term III Installation and Operation Manual Table of Contents Section Title Page # Introduction ..........3 Safety Information . -
Page 3: Introduction
SS 2.1 Term III Installation and Operation Manual INTRODUCTION CAUTION! Thank you for your purchase of a Broadcast Tools® SS 2.1/Terminal III Stereo Broadcast Tools® Audio Switcher/Router (referred to as the SS 2.1/Term III throughout this Products, as with any manual). -
Page 4: Product Description
SS 2.1 Term III Installation and Operation Manual PRODUCT DESCRIPTION The SS 2.1/Term III passively switches or routes a variety of electrical signals to a destination. The SS 2.1/Term III selects any one of 2 stereo inputs to a single stereo output. -
Page 5: Front Panel Description
SS 2.1 Term III Installation and Operation Manual FRONT PANEL DESCRIPTION Source and Mute Switches: Each switch represents an input to be routed to the switcher’s output. The switches are highly reliable switches, which will give the user years of dependable service. Each switch has an associated LED indicator, which will illuminate when that par- ticular source is routed to the output. -
Page 6: Inspection
SS 2.1 Term III Installation and Operation Manual Note: To select an input at power-up with SW5-5 ON, hold down the push-but- CAUTION! ton for the desired input channel or mute until the front panel LED’s flash. Installation of the SS 2.1 Term III in high Operation SW5-6... - Page 7 STEP 4: MOUNTING Mount the unit on a rack shelf, such as the Broadcast Tools RA-1, allowing adequate airflow for cooling. The RA-1 is furnished with filler panels to cover open spaces.
-
Page 8: Serial Operation
SS 2.1 Term III Installation and Operation Manual STEP 6: SERIAL OPERATION Connecting the RS-232 serial port of the SS 2.1/Term III is accomplished by using the supplied reversed modular cable and 9-pin “S9” female D-sub adapter between the SS 2.1/Term III and controlling PC. Select the desired address for each unit. Never duplicate addresses. - Page 9 SS 2.1 Term III Installation and Operation Manual Jumpers: JP2: Installed = Front panel enable switch defeated Removed = Front panel ENABLE switch active. This switch must be held closed to operate any of the other front panel switches. NOTE: This switch is NOT associated with any of the remote control functions.
- Page 10 SS 2.1 Term III Installation and Operation Manual * SAGE ENDEC INSTALLATION GUIDELINES The pin out of the adapter is shown below. RJ-11 DB-9 SS 2.1 Term III Adapter D-Sub (Point of view) RS-232 Receive RS-232 Transmit Modular Jack Pin Ground Numbers Dip Switch Setup: Follow the tables below for setup options:...
-
Page 11: Specifications
SS 2.1 Term III Installation and Operation Manual SPECIFICATIONS Inputs/Outputs: Any input level and impedance can be used. Inputs may be balanced or unbalanced. Output levels, impedance, distor- tion, noise and balancing will match that of the selected input. Switching Method: Passive. -
Page 12: Warranty
If Broadcast Tools is notified, in writing, of a failure of any item manufactured by Broadcast Tools to conform to the foregoing Limited Warranty within one (1) year following the date of the Buyer’s acquisition of the item, and if the item is returned to Broadcast Tools in accordance with Broadcast Tools’... - Page 13 SS 2.1 Term III Installation and Operation Manual APPENDIX...
- Page 14 SS 2.1 Term III Installation and Operation Manual APPENDIX...
- Page 15 SS 2.1 Term III Installation and Operation Manual APPENDIX e-mail: support@broadcasttools.com voice: 360.854.9559 fax: 866.783.1742...
- Page 16 SS 2.1 Term III Installation and Operation Manual APPENDIX e-mail: support@broadcasttools.com voice: 360.854.9559 fax: 866.783.1742...
