Page 1: User Manual
9.7'' LCD FIELD MONITOR USER MANUAL UMEN-260314-V1.0... -
Page 2: Table Of Contents
User manual SUMMARY PRODUCT DESCRIPTION ........................3 INSTALLATION OF SUNSHADE COVER ..................... 5 DV BATTERY MOUNT PLATE ......................6 SETTING MENU ..........................8 SPECIFICATIONS ..........................10 ACCESORIES ........................... 10 TROUBLE SHOOTING ........................11 WARRANTY AND CONTACTS ......................11 www.newhank.com... -
Page 3: Product Description
11. Knob SAT/ADJ: Press the knob to select main MENU options; rotate knob to confirm the selection and adjust parameter values; Default as Saturation function. 12. Knob TINT: Default as Tint function; 13. Knob CONTRAST: Default as Contrast function. www.newhank.com... - Page 4 23. Power cable interface (connecting to the battery plate); 24. Speaker; 25. TALLY signal input; 26. USB output port (DC 5V/0.5A) 27. 4-pin XLR DC power input. Pin number Signal ① ②③ ……... ④ +12V under SDI mode 26 (USB 5V/0.5A output power). Ps: Unavailable www.newhank.com...
-
Page 5: Installation Of Sunshade Cover
Pushing to close / open sunshade from assigned round area when assembly / disassembly. （i.e. assembly instruction ② / disassembly instruction ①); otherwise assembly / disassembly failed, and even damaged. Assembly instructions Push to close Disassembly instructions Push to open www.newhank.com... -
Page 6: Dv Battery Mount Plate
Panasonic battery DU06/VBD140/SANYO DZhs301sw/Hitachi DZ-HS303SW/BZ-BP14S/DZ3200/BP07W. Model QM91D for battery of SONY DV: DSCR1/F/S/MVCCD/E/HC15E/HC1E/AE1u/DCRTRV828/E/CCD-TRV11 6/DCR-DVD/PS105K/300K/10P/1E series. Model F970 for battery of SONY DV: DCR-TRV series, DCR-TRV E series, VX2100E PD P series, GV-A700, GV-D800 FD/CCD-SC/TR3/FX1E/HVR-AIC, HDR-FX1000E, HVR-Z1C, HVR-V1C, FX7E F330. www.newhank.com... - Page 7 User manual Model LP-E6 for battery of Canon DSLR: 5D Mark II/EOS7D/EOS60D V-mount battery plate (optional): Please refer to GP-L130AB type battery specifications. Anton Bauer mount battery plate (optional): Please refer to GP-L130B type battery specifications. www.newhank.com...
-
Page 8: Setting Menu
OFF，MONO，Red, Green and Blue Aspect Ratio Full Screen and 16:9 Pixel-to-Pixel ON/OFF Camera 480P (5DII Mode) / 1080I (5DIII Mode) H/V delay OFF,H&V Delay, V Delay and H Delay Underscan ON/OFF ITEMS OPTIONS Center Marker ON/OFF Screen Markers OFF,95%,93%,90%,88%,85% and80% www.newhank.com... - Page 9 ·Camera ·Pixel-to-Pixel ·PIP ·Peaking ·False Color ·Exposure ·Histogram. Functions of R1-R4 buttons can also be customized: ·Contrast ·Brightness ·Saturation ·Tint ·Volume ·Sharpness Note: Off, camera, X2, X4 and X8 options can be set when zoom function customized as shortcut key. www.newhank.com...
-
Page 10: Specifications
Weight 1068g / 1388g (with cover) 6. ACCESORIES 1x Flexible folding sun shade cover 1x Battery plate bracket 2x Battery plate (F-970/QM91D/DU21/LP-E6) 1x HDMI type A –A 1x DC 12V power adapter (XLR connector) 1x TALLY connector 1x Manual www.newhank.com... -
Page 11: Trouble Shooting
During the warranty period, the unit will be repaired free of charge. Return shipping are the responsibility of the customer. Return shipping have to be made through your local distributor/dealer. For any question during the installation, contact our after sales service on the following address: info@newhank.com www.newhank.com...
