Summary of Contents for IntraServer Technology ITI-90-100250
- Page 1 ® CompactPCI Multi-Function Adapters Installation and User’s Guide Order Number ITI-90-100250 Version 1.2 (Second Publication) LSI Logic Copyright 2000...
- Page 2 The information in this document is subject to change without notice and should not be construed as a commitment by LSI Logic/IntraServer Technology, Inc. LSI Logic/IntraServer Technology, Inc. assumes no responsibility for any errors that may appear in this document. Version Date Version 1.1...
- Page 3 No responsibility is assumed for the use or reliability of software or equipment that is not supplied by IntraServer Technology, Inc. or its affiliated companies.
- Page 4 FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 5: Fcc Declaration Of Conformity
FCC Declaration of Conformity The IntraServer Technology, Inc. CompactPCI Ethernet adapter, model numbers ITI-8241, ITI-8240, ITI-8200, ITI-8040 and ITI-8001 comply with the requirements of FCC part 15, class A as defined under paragraph 2.909 of these rules. This declaration covers products identified with ITI-8241, ITI-8240, ITI-8200, ITI-8040 and ITI-8001 on the product label. -
Page 6: Table Of Contents
TABLE OF CONTENTS ...6 INTRODUCTION...9 ITI-8000 S ERIES DAPTERS OFTWARE OVERED BY OCUMENTATION RGANIZATION ADAPTER CONFIGURATION...13 I/O C ...13 ONNECTORS SCSI...13 Ethernet...13 Video...14 ITI-8241C-S H ANDLE ITI-8241C-R H ANDLE ITI-8241C-S M ODULE Table 4: Configuration Headers and Jumpers...18 ITI-8241C-R Rear I/O Transition Module...19 ITI-8241C-S A NSTALLING THE Configuring SCSI for Rear I/O ...20... - Page 7 Ethernet 10/100 Auto-Negotiation...43 Verifying the Installation...44 Diagnostic Testing...45 Verify Connectivity by Monitoring Network Activity...47 SOFTWARE INSTALLATION ...48 NSTALLATION FOR (ITI-8200 S )...48 ERIES Introduction ...49 Features ...49 System Requirements...49 Verifying Correct Installation ...50 Identifying the SCSI disks ...51 ITHPS and ITSPS Device Drivers ...53 Installing ITHPS Ultra2 SCSI Drivers...53 Existing System Installation...53 Floppy Disk Install ...53...
-
Page 8: Product Warranty
...77 ICENSE GREEMENT FOR OFTWARE PRODUCT WARRANTY...81 ’ ...83 EADER OMMENTS Page 8 of 83... -
Page 9: Introduction
________________________1 IntraServer’s ITI-8000 Series Ultra2/Ultra3 SCSI, Quad Fast Ethernet and Video adapters for CompactPCI Differential (LVD) Ultra2 and Ultra3 SCSI technology with multiport Fast Ethernet and Video. IntraServer ITI-8000 Series adapters provide maximum integration of the most commonly required server functions, leaving the maximum number of free CompactPCI IntraServer provides state of the art software drivers, which take full advantage of the embedded RISC SCRIPTS multiport SCSI controller to... -
Page 10: Included In Thi Guide
ITI-8000 Series Adapters Included in This Guide This guide covers the installation and operation of IntraServer’s ITI-8000 ® Series CompactPCI Combination adapters as follows: IntraServer Part ITI-8241C-S ITI-8240C-S ITI-8200C-S ITI-8040C-S ITI-8001C-S Table 1: Hardware Covered by this Guide The following variations are available for the adapters above. The variations can be combined when applicable. -
Page 11: Thi Guide
Software Covered by This Guide All IntraServer’s ITI-8000 Series CompactPCI adapters are supported by the Solaris operating system on SPARC™ based systems. Information regarding software installation is included in the software driver section of this guide. Support is currently available for the following operating systems: Operating System Sun Solaris Version 2.6 Sun Solaris Version 7.0... -
Page 12: Documentation Organization
Documentation Organization This manual is organized into the following sections: Adapter Configuration and Installation BIOS and Firmware Configuration Testing the Installation Software Driver Installation and Configuration Page 12 of 83... -
Page 13: I/O C Onnectors Scsi
________________________2 Adapter Configuration ® IntraServer CompactPCI Combination adapters will have a different connector configuration depending on which variation you have purchased. This guide will cover the ITI-8241C-S, two Ultra2/LVD SCSI port, four Fast Ethernet and Video, fully configured module. For all other variations of the adapter, simply skip those sections that do not apply to your adapter. -
Page 14: Video
handle is qfe0. See Figure 1 for location of the ports, and Appendix A for connector pin-out. Note: Your ports will be named with the next four available qfe numbers if there are existing qfe ports in your system. Video A 15-pin “D”... -
Page 15: Iti-8241C-S Handle Connections
ITI-8241C-S Handle Connections Use the following diagram as a guide when connecting your external devices to IntraServer’s ITI-8241C-S adapter. Ethernet Port 1 [qfe1] Ethernet Port 3 [qfe3] Link/Activity Port 1 Link/Activity Port 3 Ultra2 SCSI Port A Figure 1: ITI-8241C-S I/O Connector Configuration Ethernet Port 0 [qfe0] Ethernet Port 2 [qfe2] Link/Activity Port 0... -
Page 16: Iti-8241C-R Handle Connections
ITI-8241C-R Handle Connections Use the following diagram as a guide when connecting your external devices to IntraServer’s ITI-8241C-R rear I/O module. Ethernet Port 3 [qfe3] Ethernet Port 1 [qfe1] Link/Activity Port 1 Link/Activity Port 3 Ultra2 SCSI Port B Figure 2: ITI-8241C-R Rear I/O Connector Configuration Ethernet Port 2 [qfe2] Ethernet Port 0 [qfe0] Link/Activity Port 0... -
Page 17: Iti-8241C-S Module Configuration
ITI-8241C-S Module Configuration The following diagram can be used to locate the major components and option jumpers on the ITI-8241C-S adapter. J 11 Figure 3: ITI-8241C-S Configuration Jumper and Header Location J 6,7,8,9 J 10 HDR 5 HDR 4 Page 17 of 83 HDR 1,6,3,7 HDR 1002... -
Page 18: Table 4: Configuration Headers And Jumpers
Header Number Function HDR 1 Bus A Internal Termination Invert HDR 3 Bus B Internal Termination Invert HDR 4 Video Disable HDR 5 Video Interrupt Disable HDR 6 Bus A External Termination Invert HDR 7 Bus B External Termination Invert HDR 1002 Hot Swap Register Disable Ethernet Port 0 Front/Rear Select... -
Page 19: Iti-8241C-R Rear I/O Transition Module
ITI-8241C-R Rear I/O Transition Module Figure 4: IntraServer ITI-8241C-R Rear I/O Transition Module Page 19 of 83... -
Page 20: Installing The Iti-8241C-S Adapter
Installing the ITI-8241C-S Adapter The ITI-8241C-S Combination host adapter is plug and play compatible with Sun Solaris SPARC™ systems. All functions of the ITI-8241C-S adapter are accessible from the front of the adapter. With the addition of the optional ITI-8241C-R rear I/O module, all functions can also be brought to the rear of the system. -
Page 21: Configuring The Video For Rear I/O
Configuring the Video for Rear I/O To configure the ITI-8241C-S Video to exit the rear of the system cabinet via the ITI-8241C-R rear I/O module, use the following procedure: § Locate J10 and J11. (See Figure 2 for jumper locations) §... -
Page 22: Configuring Ethernet For Rear I/O
Configuring Ethernet for Rear I/O To configure the ITI-8241C-S Ethernet to exit the rear of the system cabinet via the ITI-8241C-R rear I/O module, use the following procedure: § Locate J6, J7, J8 and J9. (See Figure 2 for jumper locations) §... - Page 23 The following procedure should be used to install all IntraServer ® CompactPCI adapters: Turn OFF the power to the computer system, and to all peripherals directly connected to the system (monitor, printer, external SCSI enclosures, etc.) Unplug the system from the AC power line Use an anti-static strap or precautions to avoid static discharge to your computer system or the IntraServer CompactPCI adapter...
-
Page 24: Configuring The Scsi Bus
Configuring the SCSI Bus Some basic SCSI principles must be applied to correctly configure the SCSI bus on your system. Termination Most difficulties with the SCSI bus can be traced to improper termination and cabling. The SCSI bus must be terminated at both ends, and only at the ends. Configure the termination on your IntraServer CompactPCI the configuration information in the preceding chapter. - Page 25 LVD signal levels. The LVD light will light to indicate the bus is running in ULTRA2 LVD (80MB/sec) mode. If the LVD/SE bus on an ITI-8000 Series module senses ANY Single Ended (SE Only) devices on the bus, it will automatically set to SE signal levels and run in ULTRA (40MB/sec) mode.
-
Page 26: Scsi Ids
SCSI IDs Each device and host adapter on the SCSI bus must have a unique SCSI ID. It is recommended that the host adapter be left at its default ID of 7. Should it be necessary for the host adapter ID to be changed, use the OBP setenv command to change the scsi-initiator-id from 7 to the desired value. -
Page 27: Cabling Scsi Devices
All IntraServer CompactPCI SCSI channel. Devices can be connected internally, externally or a combination of internally and externally. For FAST SCSI operation, it is recommended that the total bus (cable) length from end to end be kept to 3 meters. For Ultra2 SCSI running in Low Voltage Differential (LVD) mode, the cable must be kept within 12 meters for multidrop connections or 25 meters point to point. -
Page 28: Iti-8000 Series Lvd/Se Scsi Cable Selection Guide
ITI-8000 Series LVD/SE SCSI Cable Selection Guide Cable Description Internal 68-pin ribbon, LVD differential high density, 5 position (1 adapter & 4 devices) with built in LVD/SE Terminator External 68-pin high density to 68-pin micro External Adapter Cable, 68- pin micro to 68 position high density receptacle. -
Page 29: Connecting Internal Scsi Devices
Connecting Internal SCSI Devices Internal SCSI devices (disks inside the host enclosure) can be connected to the ITI-8241C-R rear I/O adapter using a multi-conductor 68 position ribbon cable for 16-bit (WIDE) devices. There is one 68 position connector for each of the two SCSI buses. - Page 30 LVD bus segment. The adapter will terminate the other end of the bus automatically. Page 30 of 83...
-
Page 31: Attaching Se (Non-Ultra2/Lvd) Devices
Attaching SE (non-Ultra2/LVD) Devices The IntraServer internal cable (50-401030) can also be used to attach internal Single Ended (SE) disks to the ITI-8241C-R rear I/O module. Note that placing any non-LVD drives on a bus will cause the entire bus to run in Single Ended mode, and reduce the maximum I/O throughput from 80MB/sec to 40MB/sec. -
Page 32: Hard Disk Activity Light
Hard Disk Activity Light IntraServer’s ITI-8000 Series adapters have a built in activity LED, which indicates when the SCSI bus is busy. The LED will flash to indicate activity on the bus. Connecting External SCSI Devices Optional cables are available from IntraServer for all external devices. See the cable selection Table 5 in this guide to determine the correct cable for your application. -
Page 33: Example Scsi Configurations
Example SCSI Configurations IntraServer’s ITI-8000 Series adapters greatly increase the configuration flexibility for SCSI while allowing increased performance two to four times over previous generation products. cables up to 12 meters, while operating at 80MB/sec. To maximize the performance of the ITI-8000 Series adapter, the following general rules must be followed. -
Page 34: Cabling Internal Devices
Cabling Internal Devices Be certain to use the IntraServer LVD differential cable and the LVD/SE 68- pin connector to connect all your internal LVD peripherals. The cable has a built in terminator at the drive end. terminate the controller end. Ultra2 SCSI LVD/SE Internal Cable Ultra2 SCSI LVD/SE... -
Page 35: Cabling External Devices
Cabling External Devices Be certain to use high quality differential cable for all your external LVD/SE connections. When running in LVD mode (LVD LED indicator ON), your total LVD bus must be kept to 12 meters for multi-drop connections. If the bus is being used in SE mode (LVD LED indicator OFF), the bus must be kept to 1.5 meters. -
Page 36: Figure 11: Dual Rear Scsi Cabling In Side-By-Side Layout - One Disk Per
The configuration example figures in this section show how the shared disk drives, the cables, and the controller cards are physically located in Node 0 and Node 1. shows the recommended termination scheme and SCSI ID Table 6 settings for one mirrored drive configuration. can also be applied Table 6 to the second mirrored drive configuration. -
Page 37: Figure 12: Dual Rear Scsi Cabling In Side-By-Side Layout - Two Disks Per
Figure 12: Dual Rear SCSI Cabling in Side-by-Side Layout - two disks per node using SCA adapter Page 37 of 83... -
Page 38: Figure 13: Dual Rear Scsi Cabling In Side-By-Side Layout - One Disk Per Node Using Internal Scsi Cable With Terminator
Figure 13: Dual Rear SCSI Cabling in Side-by-Side Layout - one disk per node using internal SCSI cable with terminator Page 38 of 83... -
Page 39: Figure 14: Dual Rear Scsi Cabling In Side-By-Side Layout - Two Disks Per Node Using Internal Scsi Cable With Terminator
Figure 14: Dual Rear SCSI Cabling in Side-by-Side Layout - two disks per node using internal SCSI cable with terminator Page 39 of 83... -
Page 40: Table 6: Suncluster™ Cabling And Termination Details
Device Node0 SCA-Adapter Node0 Internal Cable Node0 ITI-8241C-R Node0 External Cable Node0 (One End) External Cable Node1 (Other end) ITI-8241C-R Node1 Internal Cable Node1 SCA-Adapter Node1 Node1 Table 6: SUNCluster™ Cabling and Termination Details Additional configurations are possible, additional diagrams may be added in a future manual revision. Description Shared Disk Drive 1 mounted on the removable caddy. -
Page 41: Installing The Ethernet Function
Installing the Ethernet Function The IntraServer ITI-8241C-S adapter contains four fully-buffered twisted- pair Ethernet ports (RJ-45), providing four 10BASE-T/100BASE-TX channels on one CompactPCI Features Fully complies with the ANSI/IEEE std. 802.3 CSMA/CD physical layer specification Four switchable 10BASE-T/100BASE-TX Ethernet channels with auto-negotiation. -
Page 42: Hardware And Software Requirements For Ethernet
Hardware and Software Requirements for Ethernet Before installing the adapter, the system must meet the following hardware and software requirements: Table 7: Hardware and Software Requirements Requirements Supported Systems systems Supported Operating Environments OpenBoot PROM (OBP) Note – For up to date technical information visit IntraServer’s web site at http://www.intraserver.com Checking the OpenBoot PROM Revision Level... -
Page 43: Port
Installing the Ethernet Ports This chapter covers how to install the Ethernet portion of the ITI-8241C-S ® CompactPCI Combination adapter in your system and how to verify that the Ethernet ports have been installed correctly. Refer to section “Installing the IntraServer CompactPCI Host Adapter” to install the combination adapter in your CompactPCI Ethernet 10/100 Auto-Negotiation The qfe Ethernet interface used on the IntraServer ITI-8241C-S adapter... -
Page 44: Verifying The Installation
Verifying the Installation After you have installed the ITI-8241C-S combination adapter, but before you boot the system, perform the following tasks to verify the installation. Power on the system and when the banner appears, press the Stop-A keys to interrupt the boot process and to get to the ok prompt. Use the show-devs command to list the system devices. -
Page 45: Diagnostic Testing
Diagnostic Testing The following tests are available to help identify problems when the system containing the IntraServer ITI-8241C-S adapter does not boot. The FCode selftest is added to the device tree during the probing phase of the OpenBoot™ PROM start-up sequence. You can invoke the FCode selftest diagnostics by using the OpenBoot™... - Page 46 The following tests are run when the test command is executed and the adapter is connected to a network. qfe register MAC Internal Loopback 100MBit PHY Loopback 100MBit TP Loopback 10MBit XCVR Loopback Note: To test other channels of the adapter, you will need to execute the test command separately on each channel.
-
Page 47: Verify Connectivity By Monitoring Network Activity
Verify Connectivity by Monitoring Network Activity Perform the following task to verify that the system recognizes the Ethernet connection. Make sure that you are connected to an active network. To monitor network activity of incoming network packets, type the following at the ok prompt, including quotation marks and spaces: ok setenv diag-switch? true ok apply watch-net <full path name of the qfe interface>... -
Page 48: Software Installation
________________________6 Custom, high performance, Ultra2 SCSI device drivers for Sun Solaris SPARC™ based platforms, including Versions 2.6 and 7.0 are available from IntraServer, and are included with your adapter. Detailed instructions for software installation for Sun Solaris are included in this section. -
Page 49: Introduction
Introduction The IntraServer driver, ITHPS, allows the Solaris operating system to interface with SCSI devices connected to IntraServer 8200 series Ultra2 controllers with support for Low Voltage Differential (LVD) devices. This driver takes advantage of new hardware features in the 8200 series controllers to minimize CPU utilization, including a single interrupt per I/O. -
Page 50: Verifying Correct Installation
Verifying Correct Installation Use this procedure to verify installation of your ITI-8000 Series Ultra2 SCSI adapter before booting your system: Power on the system. When the banner is displayed, press the Stop-A keys to interrupt the boot process and stop at the ok prompt. Use the show-devs command to list the system devices. -
Page 51: Identifying The Scsi Disks
Identifying the SCSI disks The probe-scsi-all command is used to identify the SCSI devices on your IntraServer adapter. ok probe-scsi-all /pci@1f,0/pci@1/pci@1/IntraServer,Ultra2-scsi@0,1 Target 0 Unit 0 Disk Target 1 Unit 0 Disk /pci@1f,0/pci@1/pci@1/IntraServer,Ultra2-scsi@0 Target 0 Unit 0 Disk Target 1 Unit 0 Disk If the SCSI disks on your IntraServer adapter are not identified by your system, check the following: Does each disk have a unique SCSI ID? - Page 52 IntraServer adapters can be identified at the ok prompt using the following procedure: select the adapter entry: cd /pci@1f,0/pci@1/pci@1/IntraServer,Ultra2-scsi@0,1 use .properties to show the adapter properties .properties assigned-addresses 81036810 00000000 00001000 00000000 00000100 82036814 00000000 00100000 00000000 00000400 8203681c 00000000 00102000 00000000 00002000 82036830 00000000 00140000 00000000 00040000 compatible ithps...
-
Page 53: Ithps And Itsps Device Drivers
ITHPS and ITSPS Device Drivers The IntraServer ITHPS and ITSPS drivers are designed to Sun Microsystems SCSA specifications' for device drivers. These drivers allows connection of SCSI devices including disk drives, CD-ROMs, and tape drives for PCI- based machines. To support a new SCSI device, the Solaris 2.6/7.0 architecture requires that the device complies to the SCSI standard. -
Page 54: Distribution File Install
Distribution File Install If you received the drivers in an itis_install.tar.Z file: Uncompress and un-tar the itis_install.tar.Z file by typing the following commands in order to create a directory named install: uncompress itis_install.tar.Z tar -xvf itis_install.tar cd install Execute the install.sh shell script to add the ITHPS and ITSPS drivers to the operating system: /install.sh The ITHPS and ITSPS device drivers are now installed. -
Page 55: Installing The Ithps/Itsps Drivers On The Boot/Install Server
The basic steps to set up a boot/install server are as follows: Insert your Solaris distribution CD in your boot/install server’s CDROM drive. Change your directory to the Tools area on your distribution CD: cd /cdrom/cdrom0/Solaris_2.6/Tools Use the setup_install_server script to copy the boot and installation files to your boot/install server: ./setup_install_server /export/home/install Installing the ITHPS/ITSPS Drivers on the... -
Page 56: Booting The Client Using Ithps/Itsps Drivers
Use the add_install_client script to add the client machine ./add_install_client -i ipaddr -e ethernetid client_name platform_group Where: ipaddr is the tcp/ip address of the client ethernetid is the ethernet hardware (mac) address of the client client_name is the client’s system name platform_group is the client’s vendor defined hardware group Example: ./add_install_client -i 192.168.103.124 –e 00:08:26:02:25:34 sunsys sun4u... - Page 57 Notes: The message “major number maximum based on server, not client” can safely be ignored. Your SUN machine will prompt you to allow power saving automatic shutdown. You must answer no to this question if you are using the IntraServer adapter to support your boot disk If you change the disk drive configuration of your machine, it may be necessary to issue the command: touch /reconfigure...
-
Page 58: Configuring The Driver Software
Configuring the Driver Software Beginning with the Solaris 2.6 Hardware: 5/98 release the Solaris qfe software driver that is used by the ITI-8241C-S is bundled with the Solaris operating system. Note: For information on how to obtain the latest patches and patch revisions, visit the SunSolve website at http://sunsolve.sun.com, SunService or you local reseller. -
Page 59: Booting From The Network Using Solaris
intra # cat /etc/hostname.qfe3 intra-4 Create an appropriate entry in the /etc/hosts file for each active qfe channel. intra # cat /etc/hosts … 127.0.0.1 localhost 192.168.120.10 192.168.121.10 192.168.122.10 192.168.123.10 192.168.124.10 Reboot your system Booting from the Network Using Solaris You can use the qfe driver on your ITI-8241C-S adapter to boot over the network using the following example: Find the hme device from the ok prompt: ok show-devs... -
Page 60: Customizing The Installation
Customizing the Installation Network Hubs that do not send Link Pulses Certain 10BASE-T hubs are not compliant with the IEEE 802.3 Ethernet standards for link pulses. To connect your system to these hubs that do not send link pulses, you need to disable your system from looking for link pulses, as in the following example: Find the qfe device from the ok prompt: ok show-devs... -
Page 61: Increasing Tcp/Ip Performance
Use the ndd (1M) utility to temporarily change a parameter. This change is lost when you reboot the system. Refer to the Platform Notes: The qfe Fast Ethernet Device Driver document for more information on configuring driver parameters. This document is also available on the Solaris™... -
Page 62: Qfe Local-Mac-Address
/pci@1f,0/pci@1/pci@2/IntraServer,qfe@0,1 Type: ok nvstore ok setenv use-nvramrc? true Reboot your system. Refer to the Platform Notes: The qfe Fast Ethernet Device Driver document for more information on the qfe device driver and forcing network speed. This document is also available on the Solaris™ AnswerBook. qfe local-mac-address Each of the network interfaces of the ITI-8241C-S Four Port Ethernet PCI adapter has been assigned a unique MAC (Media Access Control) address,... -
Page 63: Increasing Performance On Enterprise Servers
Increasing Performance on Enterprise Servers If you deploy four ITI-8241C-S Four-Port FastEthernet adapters in an Enterprise Server you may experience slow performance and response times during peak periods of high network traffic. This poor performance is usually caused by applications that use data buffer and socket buffer sizes greater than 8Kbytes. -
Page 64: Troubleshooting
Troubleshooting The following are some potential error messages that may be preceded by a warning message displayed by the operating system. descriptions below; the ITHPS<n> (or ITSPS(n) in case of the ITSPS driver) signifies that <n> can be replaced by some number assigned to it by the operating system. - Page 65 ITHPS<n>: ddi_dma_buf_bind_handle: DDI_DMA_INUSE impossible ITHPS<n>: ddi_dma_buf_bind_handle: xxh unknown/impossible ITHPS<n>: ddi_dma_unbind_handle: failed The operating system failed to respond to the named routine in a known manner. This is a fatal error that is not recoverable. Please report this error to technical support. ITHPS<n>: No KeyROM found.
- Page 66 The driver was unable to communicate with the SCSI device driver that is part of the operating system. You may need to update your driver. ITHPS<n>: Failed to allocate memory The driver was unable to allocate the memory needed during initialization.
-
Page 67: Glossary Of Terms
________________________7 The following terms are used throughout this guide. Term Meaning 10/100 Both 10 and 100Mbps on the same port. 100BaseT Physical layer spec. for 100Mbps Ethernet over various wiring specs. 10BaseT IEEE 802.3 physical layer spec. for 10Mbps Ethernet over 2 pairs of UTP wire BIOS Basic Input/Output System CSMA/CD... - Page 68 Input/Output Industry Standard Architecture Logical Unit Number Low Voltage Differential Network Interface Card, e.g. ITI-8241C-S Packet Unit of information packaged in a predetermined structure for communications using Ethernet protocols. Peripheral Component Interconnect POST Power On Self Test RJ-45 The 8-conductor version of an RJ-11 (telephone, but wider).
-
Page 69: Table 8: Glossary Of Terms
Wide 16-Bit SCSI SCSI Table 8: Glossary of Terms Page 69 of 83... -
Page 70: Appendixa Connector Specifications
Appendix A Connector Specifications VGA Video Connector The VGA interface on the ITI-8241C-S uses the industry standard 15-pin “D” connector, and is wired as follows: Figure 15: Video Connector Connection Signal Green Blue Ground DDC Ground Red Ground Green Ground Blue Ground Table 9: Video Connector Pinout Connection... -
Page 71: Ethernet Connector
Ethernet Connector The 8-pin RJ-45 connector for 10/100 Mb/sec Ethernet is wired as shown: 87654321 Figure 16: 8-Pin MJ Connector (Front) With the connection pins assigned as shown: Pin Number Table 10: 8-Pin MJ Connector Pin Assignments Connection from the ITI-8241C-S adapter to a network hub must be made as shown: Adapter Pin TX (+) -
Page 72: Network Cabling Requirements
Table 11: Adapter to Network Hub Wiring Connection from the ITI-8241C-S adapter to another network adapter (point to point) must be made as shown: Adapter 1 Pin TX (+) TX (-) RX (+) RX (-) Table 12: Adapter to Adapter (point to point) Wiring Network Cabling Requirements In order for your network to operate properly, you must use a category of network cabling that is appropriate for the data rate of the channel. -
Page 73: Appendix B: Block Diagram
Appendix B: Block Diagram Video Connector Graphics Memory Graphics 64-bit PCI-PCI Bridge 64-bit Figure 17: ITI-8241C-S Block Diagram Dual External SCSI Connector SCSI bus SCSI bus Dual Port SCSI Page 73 of 83 Quad Ethernet Connector Ethernet Ethernet Port 2 Port 0 Ethernet Ethernet... -
Page 74: Appendix C: Rear I/O Backplane Connections
Appendix C: Rear I/O Backplane Connections All I/O is accessible via the rear connectors of the module, on J3 and J5. J3 brings the Video and SCSI Channel A to the backplane, and J5 brings SCSI Channel B, and the four Ethernet channels to the backplane. Optional rear I/O module ITI-8241C-R uses J3 and J5 to bring SCSI, Video and Ethernet to the rear of the system enclosure. -
Page 75: Table 14: Backplane Connector J5 Pin-Out
Compact PCI BPORT0_RX+ BPORT0_RX- BPORT1_RX+ BPORT1_RX- BPORT2_RX+ BPORT2_RX- BPORT3_RX+ BPORT3_RX- B_TERMPWR B_TERMPWR B_DIFFSENS LVDB_SD0- LVDB_SD0+ LVDB_SD1- LVDB_SD1+ LVDB_SD4- LVDB_SD4+ LVDB_SD3- LVDB_SD3+ LVDB_SD6- LVDB_SD6+ LVDB_SD7- LVDB_SD7+ LVDB_SATN- LVDB_SATN+ LVDB_SBSY- LVDB_SBSY+ LVDB_SACK- LVDB_SACK+ LVDB_SC_D- LVDB_SC_D+ LVDB_SI_O- LVDB_SI_O+ LVDB_SD9- LVDB_SD9+ LVDB_SD10- LVDB_SD10+ Table 14: Backplane Connector J5 Pin-out Note: Connector row ‘F’... -
Page 76: List Of Figures
List of Figures Figure 1: ITI-8241C-S I/O Connector Configuration...15 Figure 2: ITI-8241C-R Rear I/O Connector Configuration...16 Figure 3: ITI-8241C-S Configuration Jumper and Header Location...17 Figure 4: IntraServer ITI-8241C-R Rear I/O Transition Module...19 Figure 5: Video Configured for Front I/O ...21 Figure 6: Video Configured for Rear I/O...21 Figure 7: Ethernet Configured for Front I/O ...22 Figure 8: Ethernet Configured for Rear I/O ...22... -
Page 77: End User License Agreement For Software
(“EULA”) is a legal agreement between you (either an individual or a single entity) licensee of the IntraServer ITIpci SCSI Software being licensed by IntraServer Technology, Inc. (“ITI”) for the software (“SOFTWARE PRODUCT” or “SOFTWARE”) provided with the ITIpci Host Adapter (“Host Adapter”). You may not use the Software except in conjunction with the Host Adapter. -
Page 78: Grant Of License
transferring any aspects of such rights to you or any third party. Except as specifically permitted in this Agreement, you may not copy the software, any printed materials accompanying the software or any “on-line” or electronic documentation. 1. GRANT OF LICENSE: This EULA grants you the following non-exclusive rights: Software: Network Services:... - Page 79 2. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS: Limitation Reverse Modifications and Derivatives: You may not reverse engineer, decompile, disassemble, or modify, in whole or in part, the SOFTWARE PRODUCT, or create a derivative work using the SOFTWARE PRODUCT except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.
-
Page 80: Product Support
Technical Data and Computer Software clause DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the Commercial Computer Software – Restricted Rights at 48 CFR 52.227-19 as applicable. The Manufacturer is IntraServer Technology, Inc., Seven October Hill Road, Holliston, MA, USA 01746. 7. EXPORT LAWS AND REGULATIONS: The end user agrees to comply with the export laws and regulations of the United States and other governing jurisdictions. -
Page 81: Limited Software Warranty
PRODUCT WARRANTY LIMITED SOFTWARE WARRANTY IntraServer Technology, Inc. (“ITI”) warrants to only the original licensee that the Software, when properly installed in conjunction with the Host Adapter, will perform substantially in accordance with ITI’s specifications contained in ITI’s documentation provided with the Software (“ITI’s Documentation”) for a period of 60 days from the date of the original... - Page 82 return shipping date of the repaired or replaced product, or (ii) the period of time remaining on the original three-year warranty. Before returning any product, contact ITI’s Technical Support (for telephone numbers and addresses, see the Technical Support section of this document). If ITI’s Technical Support verifies that the product is defective, the Return Authorization Department will issue an RMA number to place on the package containing the Host Adapter.
-
Page 83: Reader's Comments
Reader’s Comments Mail to: IntraServer Technology, Inc. Seven October Hill Road Holliston, MA 01746 Your comments and suggestions help us improve the quality of our publications. I rate this manual on: Accuracy (product works as manual says) Completeness (enough information)
