Summary of Contents for Conceptronic CLLCHATCAM

  • Page 1 User Manual Chatcam with Microphone CLLCHATCAM C08-209 V5.0...
  • Page 2: Table Of Contents

    CONTENTS Chapter 1: Introduction ..........1 Product Overview Main Features Package Contents Chapter 2: Installation ..........3 Hardware installation Basic webcam usage Driver installation Chapter 3: Using the webcam ........5 Resolution configuration Extra features Video Proc Amp...
  • Page 3: Chapter 1: Introduction

    Chapter 1: Introduction Product Overview Thank you for choosing CLLCHATCAM Chatcam with Microphone. This USB Chatcam is compatible with most messenger-programs like MSN/Live Messenger, Skype etc. This webcam has a VGA (640x480) quality and includes 6 LED lights which controlled by LDR, a built-in microphone and an adjustable lens.
  • Page 4: Main Features

    Main Features • Compatible with all messenger & chat applications • Built-in microphone • 6 LED lights controlled by LDR • Interpolated 30MP • VGA webcam Package Contents • Chatcam with Microphone • Product CD-ROM • Multi Language Quick Installation Guide...
  • Page 5: Chapter 2: Installation

    Chapter 2: Installation Hardware installation The Conceptronic Chatcam is an UVC (Universal Video Class) webcam, meaning that you can plug the Chatcam in a free USB port of a computer with UVC support (like Windows XP SP2, Windows Vista, Windows 7 and Linux 9.04), without the need to install any drivers.
  • Page 6: Driver Installation

    Driver installation If you want to use the extra features of the webcam, you need to install the drivers from the included product CD-ROM. Before you can install the drivers, you need to connect the webcam to your computer, as described in Hardware installation. A.
  • Page 7: Chapter 3: Using The Webcam

    Chapter 3: Using the webcam When the drivers and software are installed, you can use the installed webcam software to access the extra functions of the webcam. Start the webcam software by double clicking on the “Camera Capture” shortcut on your desktop, or use the shortcut in the start menu: “Start”...
  • Page 8: Resolution Configuration

    Resolution configuration Through the menu“Options”-->“Setting”, you are able to change the default resolution settings for the webcam: Note: If you select a higher resolution, the frame rate will drop. To have a smooth webcam stream, lower the resolution. Extra features The webcam has extra features, like “General Effects”, "...
  • Page 10 In the “Face Page” page, you can also select an image effect, or a photo frame, to adjust your webcam image. This “Face Page” just combine “General Effects” and " Special Effects ".
  • Page 11: Video Proc Amp

    In the “Video Proc Amp” page, you can change the image settings for the webcam. 1. Slide the “Brightness”,“Contrast”, “Hue”, “Saturation”,“Sharpness”, or“Gamma” sliders to adjust the image settings. 2. Select“Default”to load the webcam default settings. When you have changed your settings, click “Apply”. Enjoy the use of your Conceptronic Chatcam!
