1
LCD Controller Module
Used for initial network configuration,
restarting or shutting down the appliance
and obtaining IPS version information
5
Management Ports
Management port 1 is used
to communicate with Proventia
Manager and Proventia
SiteProtector™ central
management system
Management port 2 is used
exclusively for sending RSKill
(TCP Reset) responses
Technical Support - http://www.iss.net/support
Model GX5108
2
Protected Ports
Used for either inline intrusion prevention (IPS mode) or passive intrusion
detection (IDS mode)
Inline prevention uses a pair of ports per segment
Passive detection uses a single port per segment
IDE
PWR
1
2
6
Power Supplies
Welcome
You're only minutes away from the best network security available.
3
Serial Console Port
Used for terminal-based (optional)
setup and recovery
7
Power Button
4
USB Ports
Used to communicate with optional external bypass unit
8
Fan Assemblies
