Phenom 900-131MO Operating Instructions Manual

Portable extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PORTABLE EXTRACTOR
MODELS:
900-131MO
10070540
900-131HMO
10070530
R
86038630 05/25/11
PRV NO. 98841
Read these instructions before using the machine
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 900-131MO and is the answer not in the manual?

Questions and answers

Summary of Contents for Phenom 900-131MO

  • Page 1 PORTABLE EXTRACTOR Operating Instructions MODELS: 900-131MO 10070540 900-131HMO 10070530 Read these instructions before using the machine 86038630 05/25/11 PRV NO. 98841...

  • Page 2: Warranty Registration

    Thank you for purchasing a C400 product. Warranty registration is quick and easy. Your registration will allow us to serve you better over the lifetime of the product. To register your product go to: www.century400.com/support/warranty/register.php For customer assistance: 1-800-776-2436 PHENOM 86038630 05/25/11...

  • Page 3: Table Of Contents

    Pre-Run Machine Inspection......3-3 Equipment Set-up........3-3 Emptying & Cleaning Tanks.......3-3 MAINTENANCE Daily Maintenance ........4-1 Periodic Maintenance ........4-1 Monthly Maintenance........4-1 Semi-annually ..........4-1 Lubrication ............4-1 Storage ............4-1 Vacuum Motor Replacement ......4-2 Solution Pump Replacement ......4-2 Pump Replacement Kit .........4-3 Machine Troubleshooting......4-4 PHENOM 86038630 02/01/07...

  • Page 4: How To Use This Manual

    NOTE: If a service or option kit is installed on your machine, be sure to keep the KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. PHENOM 86038630 05/25/11...

  • Page 5: Important Safety Instructions

    This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices for more than normal housekeeping purposes. Maintenance and repairs must be done by qualified personnel. If foam or liquid comes out of machine, switch off immediately. SAVE THESE INSTRUCTIONS PHENOM 86038630 02/01/07...

  • Page 6: Hazard Intensity Level

    Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. PHENOM 86038630 02/01/07...

  • Page 7: Safety Label Location

    NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. -WARNING- LABEL WARNING 86242230 PRV NO. 500009 LABEL HEATER MATE WARNING TAG 86200000 PRV NO. 170-31 WITH HEAT ONLY LABEL CIRCUIT INTERRUPTER 86200570 PRV NO. 170-41 PHENOM 86038630 02/01/07...

  • Page 8: Grounding Instructions

    The green colored rigid ear, lug, or wire extending from the adaptor must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adaptor is used, it must be held in place by a metal screw. PHENOM 86038630 02/01/07...

  • Page 9: Technical Specifications

    Weight-Full Solution 105 lbs (230 kg) Height 35 inches (88.90 cm) Height-(Handle Folded Down) 28.5 inches (72.39 cm) Length 25 inches (63.50 cm) Width 15.5 inches (39.37 cm) Power cord 22 feet (6.71 m) LENGTH WIDTH HEIGHT HEIGHT PHENOM 86038630 02/01/07...

  • Page 10: Controls

    CONTROLS PUMP Vacuum Switch Pump Switch PHENOM 86038630 02/01/07...

  • Page 11: Machine Operation

    5. Once the vacuum tank has been emptied, with clean hot water. Mix in a non-foaming you may once again proceed with cleaning cleaning concentrate for use in hot water extraction machines, following the manufacture’s instructions printed on container. PHENOM 86038630 02/01/07...

  • Page 12: Maintenance

    Protect this machine from freezing while in storage. HEAT MODELS ONLY: Be sure to thoroughly drain water out of heater lines prior to storage in colder climates. This heater will freeze and possibly crack voiding your warranty. PHENOM 86038630 02/01/07...

  • Page 13: Vacuum Motor Replacement

    3/8" (9.5mm) long. 8 [9.5mm] Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) long. PHENOM 86038630 02/01/07...

  • Page 14: Pump Replacement Kit

    PRV NO. 84166 PRV NO.53245 VALVE ASM 8.619-139.0 MOTOR PRV NO.65204 PUMP HEAD PUMP REPLACEMENT PARTS FOR SHURFLO 100 PSI (250-64A) Pump Head Replacement Valve Asm Diaphragm 8.625-104.0 8.265-883.0 8.623-510.0 PRV NO. 65187 PRV NO. 84161 PRV NO. 29206 PHENOM 86038630 02/01/07...

  • Page 15: Troubleshooting

    Light carpet with no brown Go over carpet with browning prevent only prevention Solution hose connection Check for positive connection Solution not flowing Faulty pump Repair or replace properly Faulty floor tool valve Repair or replace Faulty pump switch Repair PHENOM 86038630 02/01/07...

  • Page 16: Pump Group (No Heat)

    PUMP GROUP (NO HEAT) PHENOM 86038630 02/01/07...
  • Page 17 SHURFLO 100 PSI PUMP DEMAND PUMP, 115V 100 PSI BYPASS W/SW 86251110 65219 (FLOJET) 86010630 87013 WASHER, 1/4 ID X 5/8 OD SS 86273780 70015 SCR, 1/4-20 X 3/4 HHCS SS NP 86281250 39311 HOSE, 3/8ID SGLBRD RBR X 14” PHENOM 86038630 02/01/07...

  • Page 18: Pump And Heater Group

    PUMP AND HEATER GROUP PHENOM 86038630 09/05/08...

  • Page 19: Pump And Heater Group

    TEE 1/4 FEMALE 86280760 151-47B HOSE, 1/4 NYLOBRAID X 6” 86200280 250-12 HOSEBARB, 3/8 MPT X 1/4 90D 86090230 87015 WASHER, 9/16 ID X 1.06 OD SS 86312660 BASE, PUMP MOTOR 86199960 110-22 GROMMET 6 GAL. PORT PHENOM 86038630 09/05/08...

  • Page 20: Recovery Tank Group

    RECOVERY TANK GROUP PHENOM 86038630 02/01/07...
  • Page 21 WASHER 1/4 X 5/8 BONDED NEOPRN 86201290 280-02 RIVIT AL. 3/16 X 1/2 CLOSED 86090750 065-40 BAFFLE 86200290 260-33 HOSEBARB, 1.5 MPT X 1.5 86004000 35255 GASKET, TANK LID 86003680 34380 FLOAT, SHUT OFF 86090320 87257 WASHER, HOSEBARB PHENOM 86038630 02/01/07...

  • Page 22: Solution Tank Group (No Heat)

    SOLUTION TANK GROUP (NO HEAT) PARTS INSIDE TANK CONNECT TO PUMP ASM PHENOM 86038630 02/01/07...
  • Page 23 040-12 CASTER 2 1/2” THR’D 3/8-16 86010720 87086 WASHER, M10 X 30 PLTD 86091100 065-41A WHEEL SUPPORT PLATE 86200640 500351 LABEL, MAIN PHENOM 86091140 335-08 SWITCH PLATE 86200550 170-22B LABEL W/O HEAT 86256960 72142 SWITCH, SPST 15A EURO ROCKER 86274510...

  • Page 24: Solution Tank Group (W/ Heat)

    SOLUTION TANK GROUP (W/ HEAT) PARTS INSIDE TANK CONNECT TO PUMP INLET PHENOM 86038630 02/01/07...
  • Page 25 86199460 040-12 CASTER 2 1/2” THR’D 3/8-16 86010720 87086 WASHER, M10 X 30 PLTD 86091100 065-41A WHEEL SUPPORT PLATE 86200640 500351 LABEL, PHENOM MAIN 86091140 335-08 SWITCH PLATE 86233480 22046 CLIP, NEON LAMP 86200540 170-22A LABEL SWITCH W/ HEAT 86201310...

  • Page 26: Vacuum Motor Group

    VACUUM MOTOR GROUP 5-11 PHENOM 86038630 02/01/07...

  • Page 27: Vacuum Motor Group

    86258420 53130 VAC MOTOR, 120V 5.7 3ST W/O TB 86135320 140687 BRUSH SET, 120V VAC WINDSOR SERVICE ONLY 86135300 140676 BRUSH SET, 120V 3ST VAC AMETEK SERVICE ONLY 86003720 35011 GASKET, 3/8T 5.7 VAC FAN SEAL 5-12 PHENOM 86038630 02/01/07...

  • Page 28: Wiring Diagram No Heat

    WIRING DIAGRAM NO HEAT 5-13 PHENOM 86038630 02/01/07...

  • Page 29: Wiring Diagram W/ Heat

    WIRING DIAGRAM W/ HEAT 5-14 PHENOM 86038630 02/01/07...

  • Page 30: Suggested Spare Parts

    SWITCH, SPST 15A EURO ROCKER 86202160 320-05 VELCRO STRAPS 86003720 35011 GASKET, 3/8T 5.7 VAC FAN SEAL 86200510 140-12 KNOB 1/4-20 X 3/4 S/S CUPPOINT 86135320 140687 BRUSH SET, 120V VAC WINDSOR 86135300 140676 BRUSH SET, 120V 3ST VAC AMETEK 5-15 PHENOM 86038630 02/01/07...
