Sylvania W6313CC Owner's Manual

Sylvania W6313CC Owner's Manual

13-inch color tv/vcr
Hide thumbs Also See for Sylvania W6313CC:
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
13-INCH COLOR TV/VCR
W6313CC
This Owner's Manual is made of
recycled paper.
®
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
®
energy efficiency. E
S
is
NERGY
TAR
a U.S. registered mark.
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
If you need additional assistance for set-up or operating
after reading owner's manual, please call
TOLL FREE : 1-800-968-3429
Please read before using this equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sylvania W6313CC and is the answer not in the manual?

Questions and answers

Related Manuals for Sylvania Sylvania W6313CC

Summary of Contents for Sylvania Sylvania W6313CC

  • Page 1 OWNER’S MANUAL 13-INCH COLOR TV/VCR W6313CC This Owner’s Manual is made of recycled paper. INSTRUCCIONES EN ESPAÑOL INCLUIDAS. ® As an E NERGY Partner, our company has determined that this product meets If you need additional assistance for set-up or operating the E ®...

  • Page 2: C Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THIS SYMBOL INDICATES THAT DAN- CAUTION GEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT RISK OF ELECTRIC SHOCK WITHIN THIS UNIT. DO NOT OPEN THIS SYMBOL INDICATES THAT THERE CAUTION: TO REDUCE THE RISK OF ELECTRIC...
  • Page 3 F IGURE A EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE ANTE NNA L EAD I N W I R E GROUND C L A M P A NTENNA DI SCHARG E UN I T (NEC SECTION 8 10 -2 0) EL ECT RI C SE RV I CE EQ U I PM EN T...

  • Page 4: C Precautions

    PRECAUTIONS PRECAUTIONS LOCATION IMPORTANT COPYRIGHT INFORMATION Unauthorized recording or use of broadcast televi- For safe operation and satisfactory performance of sion programming, video tape, film or other copy- your TV/VCR, keep the following in mind when righted material may violate applicable copyright selecting a place for its installation: laws.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS STILL PICTURE ..... . .19 C IMPORTANT SAFEGUARDS ... . .2 NOISE CANCEL (in the Still mode) .

  • Page 6: C Features

    FEATURES • • Infrared remote control Zero Return– The tape returns to counter of • 0:00:00 by rewinding or fast forwarding. Bilingual on screen menu display selectable in • “Freeze” the picture at any time, for close English or Spanish Still–...

  • Page 7: Operating Controls And Functions

    OPERATING CONTROLS AND FUNCTIONS - TV/VCR FRONT PANEL - POWER VOLUME CHANNEL STOP/EJECT PLAY F.FWD REC/OTR EARPHONE VIDEO AUDIO 2 3 4 5 6 7 8 1011 12 13 - REMOTE CONTROL - Connect to the video output VIDEO input jack– jack of your video camera or another VCR.
  • Page 8 - REAR VIEW - ANT. When selecting cable channels Press to rewind the tape, or to view +100 button– REW button– which are higher than 99, press this button first, the picture rapidly in reverse during playback then press the last two digits. (To select channel mode.

  • Page 9: C Preparation For Use

    PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS From Cable System or Satellite Dish VHF/UHF Antenna Satellite Box or Rod Antenna (Not supplied) Cable Box OU T (Supplied) (Not supplied) VHF Antenna (Not supplied) UHF Antenna From (Not supplied) Cable System VHF/UHF Combiner (Not supplied) ANT.

  • Page 10: External Input Mode

    TO RECORD A SCRAMBLED/UNSCRAMBLED INSTALLING THE BATTERIES CHANNEL 1) Set the TV/VCR channel selector to the output 1)Open the battery compartment cover by pressing channel of the Cable Converter Box or Satellite the cover on the remote unit in the direction of the Box.

  • Page 11: Clock Set Up (Auto / Manual)

    Select “SETTING CLOCK” – M E N U – TO SELECT A DESIRED CHANNEL Press the MENU button on the TIMER PROGRAMMING PICTURE CONTROL B SETTING CLOCK remote control. You can select the desired channel by using the CHANNEL SET UP USER’S SET UP V-CHIP SET UP Press the PLAY/K or STOP/L but-...

  • Page 12: Channel Set Up Again

    NOTE: When unplugging the AC cord or if there is a power Select “SETTING CLOCK” – M E N U – failure for more than 3 seconds, you may have to TIMER PROGRAMMING Press the MENU button on the PICTURE CONTROL reset the clock.

  • Page 13: Selecting The Language

    Select “CHANNEL SET UP” Select “ENGLISH” or “ESPAÑOL” Press the MENU button on the Select “ENGLISH” or “ESPAÑOL”= Spanish using – M E N U – remote control. the F.FWD/B or REW/s button. TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK Press the PLAY/K or STOP/L but- B CHANNEL SET UP USER’S SET UP ton to point to “CHANNEL SET...

  • Page 14: C Tv Operation

    TV OPERATION WATCHING A TV PROGRAM PICTURE CONTROL The TV/VCR’s picture controls – BRIGHT, CON- TRAST, COLOR, TINT and SHARPNESS – are Turn on the TV/VCR preset to factory specifications. Although they are Press the POWER button to turn on the TV/VCR. usually the best, you may need to make some further adjustments for a natural looking image.

  • Page 15: Closed Caption System

    TO CANCEL THE CLOSED CAPTION CLOSED CAPTION SYSTEM SYSTEM You can view specially labeled (cc) TV programs, Repeat steps [1] and [2], select [OFF] using the movies, news, pre-recorded tapes with either a dia- F.FWD/B or REW/s button. Press the MENU but- logue caption or text display.
  • Page 16 Select your desired item Exit the V-Chip setting mode Press the PLAY/K or STOP/L but- Press the MENU button on the remote control to B TV–Y [VIEW] ton to point to your desired item. return to original mode. TV–Y7 ( [VIEW] TV–G [VIEW]...

  • Page 17: Fm Mode

    NOTES: FM MODE • The radio frequency indication repeats to appear This function enables you to receive FM radio broad- and disappear. casting. • You can not record the FM radio wave broadcast- ing. Set the FM mode • If you receive a weak radio signal, you may change Press the TV/FM button on the the FM Antenna mode to INT(internal) or remote control.

  • Page 18: Search

    ZERO RETURN Select “ALL” or “BLANK” Press the PLAY/K or STOP/L This function allows you to search easily a beginning – USER’S SET UP – button to point to “REPEAT point that you want to review by rewinding or fast PLAY”.

  • Page 19: Still Picture

    TRACKING ADJUSTMENT Begin Time Search • Tracking adjustment will be set automatically By pressing the REW/s or F.FWD/B button, the (Digital Tracking function) when you start play- TV/VCR will rewind or fast forward to the specified back. point. • However when playing pre-recorded tapes or tapes The time counts down as the searching progresses.

  • Page 20: C Recording

    RECORDING TWO DIFFERENT TAPE SPEEDS ERASE PREVENTION Before recording, select the tape speed from : SP mode You can prevent accidental (Standard Play) or SLP mode (Super Long Play). erasing of recording by The table below shows the maximum recording/play- breaking off the tab on the back time using T60, T120 or T160 tapes in each mode.

  • Page 21: Timer Recording

    In the example below, the timer is being set to record: • When the REC/OTR button is pressed 18 times, DATE: July 5th, 2002 the TV/VCR returns to the Normal Recording SETTING TIME: from 7:30PM to 8:50PM mode. • CHANNEL: CH61 To stop the OTR operation, press the STOP button on the TV/VCR or on the remote control.

  • Page 22: Timer Program Extension

    Set the channel number Set end minute – TIMER PROGRAMMING – CH DATE BEGIN END – TIMER PROGRAMMING – Press the PLAY/K or STOP/L but- Press the PLAY/K or STOP/L but- -/- - - - - -:- - -:- - - - CH DATE BEGIN END -/- - - - - -:- -...

  • Page 23: Hints For Automatic Timer Recording

    TO CORRECT A PROGRAM AUTO RETURN • While setting a program; press the REW/s but- With this feature, after timer recording is finished, ton to go back one step and enter the correct num- the beginning of the recorded program(s) can be bers using the PLAY/K or STOP/L button.

  • Page 24: Sleep Timer

    SLEEP TIMER Select “WAKE UP TIMER” Press the WAKE-UP/SLEEP button The Sleep Timer function turns off the TV/VCR on the remote control once, and without using the POWER button after a desired confirm “ON/OFF” is pointed. WAKE UP B ON/OFF [ON] period of time.

  • Page 25: C On Screen Display

    ON SCREEN DISPLAY To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: WHEN THE CLOSED CAPTION MODE IS OFF: <Off mode>...

  • Page 26: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM CORRECTIVE ACTION •...

  • Page 27: C Specifications

    SPECIFICATIONS GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS CRT : 13 inch in-line gun, 90˚ Video input level : 0.5~2.0Vp-p deflection tube Audio input level : -15dBs Television system : NTSC-M Video S/N ratio : More than 46dB Closed caption system :§15.119/FCC Audio S/N ratio : More than 43dB Video Heads : Rotary two-head...

  • Page 28: Controles De Operación Ysus Funciones

    CONTROLES DE OPERACIÓN Y SUS FUNCIONES NOTA: No recomendamos utilizar mandos a distancia universales. No todas las funciones pueden ser controladas mediante un mando a distancia universal. Si decide utilizar un mando a distancia universal con esta unidad, tenga en cuenta que con el número de código dado tal vez no se pueda controlar la unidad.

  • Page 29: Panel Trasero

    - PANEL TRASERO - ANT. • Púlselo para introducir dígitos cuando establezca un 16 Botón de menú (MENU)– Púlselo para visualizar el programa. menúprincipal en la pantalla del televisor. (Por ejemplo: Para ajustar el reloj o establecer un pro- 17 Botón del visualizador (DISPLAY)– Visualiza el grama de temporizador) contador o el número del canal actual y la hora actual en la pantalla del televisor.

  • Page 30: Conexiones De Antena/Cable

    CONEXIONES DE ANTENA/CABLE Desde el cable coaxial o caja de emisiones vía Caja de CATV satélite de 75 ohm del o caja de emi- Antena combinada de sistema de Cable siones vía satélite Antena de varilla UHF/VHF VHF/UHF (no incluído) (incluído) (no incluído) OU T...

  • Page 31: Preparación De Canales Por Primera Vez

    PREPARACIÓN DE CANALES POR AJUSTE DEL RELOJ PRIMERA VEZ Cerciórese... 1) Enchufe el cable de alimentación del • La alimentación del televisor/videograbadora deberá televisor/videograbadora en una toma de CA estándar. estar conectada. NOTA: Si aparezcan algunos digitos en el rincón de la En el ejemplo de abajo, el reloj va a ajustarse así: pantalla, pulse el botón POWER sin desenchufar el cable FECHA: 7 de mayo de 2002...

  • Page 32: Limited Warranty

    LIMITED WARRANTY FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
