Summary of Contents for Seller MA-3116
- Page 1 16x16 3G/HD/SD-SDI Matrix User Manual rev: 120704 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the MA-3116 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
USB or RS-232 control must be connected either one at a time. Connecting both types of cables may cause command confusion. PACKAGE CONTENTS ● 1x MA-3116 ● 1x UL AC C13 power cord ● 1x BNC Terminator Plug ● 1x IR receiver ●... -
Page 4: Specifications
SPECIFICATIONS Model Name MA-3116 Technical Role of usage True 16x16 matrix Video bandwidth 2.97 & 2.97/1.001Gbps [3G] 1080p@50/59.94/60 (4:2:2) Video support [HD] 720p50/59.94/60, 1080p24/30, 1035i50/59.94/60, 1080i50/59.94/60 [SD] NTSC@59.94Hz, PAL@50Hz Audio support [3G] up to 100m(300ft) / [HD-SDI] up to 150m (500ft) / [SD-SDI] up to 300m... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel 1. Power: Power control 2. Fifteen Segment LED Indicators: Output/Input display 3. Front panel push buttons: To select input and output source 4. IR sensor 5. IR: IR receiver Rear Panel 6. RS-232: RS-232 control port 7. -
Page 6: Connection Diagram
[ Firmware update only can be done via RS-232 port and connection to PC set at COM1 ] 1. Power off the MA-3116. Execute the firmware update program on your PC via COM1 port connection to the RS-232 port of the MA-3116. -
Page 7: Hardware Installation
1. Connect all sources to SDI Inputs on the 16x16 SDI matrix 2. Connect all outputs to SDI Receiver 3. Connect the AC power supply to the 16x16 SDI matrix 4. Power on the 16x16 SDI matrix MA-3116 CHANNEL CONTROL Source Side Method A: Push-in Button 1.Use the switch button on output port to select which port to be changed. -
Page 8: Display Side
Display Side Method A: Software Control through RS-232 RS-232 COM select Port switch button Power control Software Control Menu 1. GUI Control: a. Select COM and click “connect” button to connect to the device. If the connection is successful, then the button will turn green. - Page 9 Popup menu Popup menu Popup menu...
-
Page 10: Popup Menu
2. Popup menu: Right click the mouse will show up a popup menu. It supports “one by one mapping”, “saving mapping” and “preset mapping” functions. 3. Terminal control: Baud rate: 9600 Data length: 8bit Parity check: No Stop bit: 1 Command Set: COMMAND ACTION... -
Page 11: Limited Warranty
1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, the SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surge.
