Owner's Manual
DVD Recorder with Video Cassette Recorder
POWER
Supplied Accessory
• Remote control
• RF cable
(NB108UD)
with two AA batteries
If you need additional operating assistance after reading this owner's manual or to
Before you use this unit , you need to complete connections. Refer to
"Connections" on pages 13-15.
To record a program easily, refer to "Easy DVD recording" on pages 16-17
after connections are completed.
(You CANNOT record on any copyright protected DVD disc with this unit.)
REW
F.FWD STOP/EJECT
PLAY
VCR
RECORD
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
• Audio/Video cables
(WPZ0901TM002)
(WPZ0102TM015 or
WPZ0102LTE01)
order replacement accessories, please call
TOLL FREE : 1-800-605-8453
or visit our web site at http://www.funai-corp.com
SR90VE
OPEN/CLOSE
DUBBING
STOP
PLAY
OUTPUT SELECT
CHANNEL
VCR
DVD
RECORD
• Owner's Manual
(1VMN20208)
Owner's Manual
S-VIDEO
VIDEO
L - AUDIO - R
DVD
• Quick Use Guide
(1VMN20003)
