Samsung Techwin. Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
overview imporTAnT SAfeTy inSTruCTionS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
overview wArninG TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
Page 5
Class construction An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a protective earthing connection. Battery Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. Disconnection Device Disconnect the main plug from the apparatus, if it’s defected.
Page 6
overview Please read the following recommend safety precautions carefully. Do not Place this apparatus on an uneven surface. Do not install on a surface where it is exposed to direct sunlight, near heating equipment or heavy cold area. Do not place this apparatus near. Do not attempt to service this apparatus yourself.
Page 7
Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
overview ConTenTS overview Important Safety Instructions Product Features Recomended PC Specifications What’s Included At a Glance iNstallatioN & Installation CoNNeCtioN Connecting with other Device Network CoNNeCtioN Connecting the Camera Directly aNd setup to Local Area Networking Connecting the Camera Directly to a DHCP Based DSL/Cable Modem Connecting the Camera Directly...
web viewer Connecting to the Camera Login Installing Silverlight Runtime Using the Live Screen Camera setup Using the Camera Menu Camera Menu Setup setup sCreeN Setup Video Setup Network Setup Event Setup System Setup appeNdix Specification Product Overview Troubleshooting Open Source Announcement GPL/LGPL Software License English _...
overview proDuCT feATureS HD video Quality Supports up to 1.3 mega pixels of HD video quality. H.264/mpeG-4/mJpeG multi-Streaming This network camera supports the H.264/MPEG-4/MJPEG codec and can display videos in different resolutions and qualities simultaneously with different Codecs. However, MPEG4 video can not be played on a web page.
wHAT’S inCLuDeD Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description User Manual, Installer S/W DVD, CMS S/W DVD Quick Guide Used to test the camera connection to a Cable for the testing monitor portable display device L Wrench Used to remove/fix the dome cover...
overview AT A GLAnCe Appearance Item Description Network Port Used to connect a PoE or LAN cable. Black : Wire for earth-grounding. Power Cable Red : Used for connection to the DC 12V adapter. Dome Cover Dome cover for the lens and unit protection. Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol.
Page 13
inside Item Description Fixing Hole Used for securing the camera to the wall or ceiling. ON : When the system operates normally System Indicator OFF : If the system does not operate properly Resets the camera settings to the default. Press and hold it for about 5 seconds to turn off the system indicator and restart the system.
installation & connection inSTALLATion precautions before installation Ensure you read out the following instructions before installing the camera: Select an installation site (ceiling or wall) that can endure at least 5 times of the camera weight. Stuck-in or peeled-off cables can cause damage to the product or a fire. ...
Page 15
installing the camera on the ceiling or a wall Select a location where you want to install the camera. Insert the provided screw into the camera hole and turn it clockwise. Fixing Hole Close the dome cover and turn it clockwise using the L-wrench.
Page 16
installation & connection Adjusting the monitoring direction for the camera Lens Cover Adjusting the monitoring direction ❖ You can adjust the camera direction only when the camera is fixed on the ceiling. Then, turning the camera to the left or right is referred to as “Panning”, while tilting the angle is “Tilting”.
ConneCTinG wiTH oTHer DeviCe Ethernet Monitor Out Power Monitor Connecting to the monitor Connect the video out port of the camera to the video input port of the monitor. In the initial installation of the camera, you can connect the camera to the monitor for checking the connection status.
network connection and setup You can set up the network settings according to your network configurations. ConneCTinG THe CAmerA DireCTLy To LoCAL AreA neTworKinG Connecting to the camera from a local pC in the LAn Launch an Internet browser on the local PC. Enter the IP address of the camera in the address bar of the browser.
ConneCTinG THe CAmerA DireCTLy To A DHCp BASeD DSL/CABLe moDem INTERNET DSL/Cable Modem Camera External Remote PC DDNS Server (Data Center, KOREA) Use the cross LAN cable to connect the network cable directly to your PC. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.
network connection and setup ConneCTinG THe CAmerA DireCTLy To A pppoe moDem INTERNET PPPoE Modem Camera External Remote PC DDNS Server (Data Center, KOREA) Use the cross LAN cable to connect the network cable directly to your PC. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.
ConneCTinG THe CAmerA To An ip rouTer wiTH THe pppoe/CABLe moDem This is for a small network environment such as homes, SOHO and ordinary shops. Camera INTERNET PPPoE or PPPoE or IP Router Camera Cable Modem Cable Modem External Remote PC Local PC DDNS Server (Data Center, KOREA)
network connection and setup BuTTonS uSeD in ip inSTALLer Item Description Model name of the connected camera. Device Name Click the column to sort the list by model name. However, search will be stopped if clicked during the search. Displays either <Static> or <Dynamic> for the current network connection Mode status.
Item Description DDNS URL address enabling access from the external Internet. However, this will be replaced with the <IP Address> of the camera if DDNS registration has failed. IPv4 Scans for cameras with the IPv4 setting. IPv6 Scans for cameras with the IPv6 setting. Scans for cameras that are currently connected to the network.
Page 24
network connection and setup In the <Address> pane, provide the necessary information. MAC (Ethernet) Address : The MAC (Ethernet) address of the applicable camera will be set automatically so you don't need to input it manually. if using an ip router IP Address : Enter an address falling in ...
Click [oK]. Manual network setup will be completed. When the manual setup including IP is completed, the camera will restart. if the ip router has more than one camera connected Configure the IP related settings and the Port related settings distinctly with each other. Category Camera #1 Camera #2...
network connection and setup Enter the password. This is the login password for the “admin” user who accesses the camera. The default password is “4321”. Click [oK]. Auto network setup will be completed. The camera will automatically complete the network setting and restart. DynAmiC ip SeTup Dynamic ip environment Setup Example of the Dynamic IP environment...
porT rAnGe forwArD (porT mAppinG) SeTup If you have installed an IP router with a camera connected, you must set the port range forwarding on the IP router so that a remote PC can access the camera in it. manual port range forwarding From the Setup menu of the IP router, select <Applications &...
Page 28
network connection and setup Setting up port range forward for several network cameras When several network camera connect to one IP router device, you should forward the TCP 943 port of the router to the TCP 943 port of a connected camera. If you don't set properly the TCP 943 port of the router, you cannot get any video stream from the web page of the camera.
ConneCTinG To THe CAmerA from A SHAreD LoCAL pC Run the IP Installer. It will scan for connected cameras and display a list of them. Double-click a camera to access. The Internet browser starts and connects to the camera. Access to the camera can also be gained by typing the camera's IP address in the address bar of the Internet browser.
web viewer ConneCTinG To THe CAmerA normally, you would Launch the Internet browser. Type the IP address of the camera in the address bar. ex) • IP address (IPv4) : 192.168.1.100 http://192.168.1.100 - the Login dialog should appear. • IP address (IPv6) : 2001:230:abcd: ffff:0000:0000:ffff:1111 ...
Page 31
IP when you try to access the device. To add the IP address to the <DDnS> server, visit www.samsungipolis.com and register your device, and set the DDNS option to <Samsung DDnS> before providing the host name for the DDNS server.
web viewer This network camera uses Microsoft Silverlight for displaying the video. inSTALLinG SiLverLiGHT runTime If your PC has not installed Silverlight Runtime or has just installed an old runtime version, you will be redirected to the Silverlight Runtime installation page automatically when accessing the web viewer.
Page 33
When done, click <Close>. Close and restart the web browser, and try to access the Web Viewer. When Siverlight Runtime is properly installed, you will see the Live screen. For normal installation, set the Block Popup setting as follows: Internet Explorer Tools Block Popup ...
web viewer uSinG THe Live SCreen Item Description Monitoring Move to the monitoring screen. Setup Move to the Setup screen. Viewer Screen Displays the Live video on the screen. Reset Event Reset the event settings to the default. Used to retrieve and customize the Camera Setup menu. Camera Menu For selecting and saving each menu item, refer to “Using the Camera Menu”.
Item Description You can select a profile type in <Video Profile> under the <Video> setup menu. For IE 6.0 users, press the Browse button next to the <Video Profile> dialog Video Format and select a profile type again if the selected profile is not played. If the “Invalid codec”...
CAmerA menu SeTup You can change the camera settings according to the environment where the camera is located. SSDr (Samsung Super Dynamic range) Setup In a scene where the difference between bright and dark is severe, you can increase the brightness of the dark area alone to regulate the overall brightness.
Page 37
Configure the <SSDr> and <D-rAnGe> settings as necessary. ssdr setup SSDR : Adjust the level of the dynamic ssdr range. d-raNGe Narrow returN D-RANGE : Select the amplitude area of the dynamic range. When completed, select <reTurn> to return to the previous screen.
Page 38
camera setup Custom Backlight Setup You can specify a desired area on the video manually and set the area to be displayed more clearly. ▲/▼ ◄/► enTer ▲/▼/◄/► enTer Move to <BACKLiGHT>. maiN setup Select <BLC>. ssdr wHite bal baCkliGHt...
Page 39
HLC (Highlight Compensation) Setup When a strong light such as streetlamp or headlight faces forward to the camera, you can mask that exposed area in order to protect it from being saturated. ▲/▼ ◄/► enTer ▲/▼ ◄/► enTer Select <BACKLiGHT>.
Page 40
camera setup exposure Setup You can adjust the exposure level of the camera. ▲/▼ enTer ▲/▼/◄/► enTer ▲/▼/◄/► enTer Move to <eXpoSure> and select a setting value. maiN setup ssdr wHite bal baCkliGHt exposure speCial exit Select each item and set it appropriately.
Page 41
SENS-UP : Automatically senses the darkness level at night or in a low contrast seNs-up limit setup scene and extends the accumulation time limit accordingly for a bright and sharp image. returN If you set the shutter mode to MANUAL/ FLICKERLESS, SENS-UP mode will be deactivated.
Page 42
camera setup Use alphanumeric characters in the list and enter a desired title in the bottom Camera title setup input line. a b C d e F G H i J k l m You can enter up to 15 characters for the title. N o p Q r s t u v w x Y Z a b c d e f g h i j k l m n o p q r s t u v w x y z...
image Adjustment You can configure the sharpness, gamma level, and color settings of an image to your preference. ▲/▼ ◄/► enTer ▲/▼ ◄/► enTer Select <SpeCiAL>. maiN setup ssdr wHite bal baCkliGHt exposure speCial exit Select <imAGe ADJ>.
setup screen SeTup You can configure the video, network, event and system settings of the camera in the network. In the Live screen, click [Setup ( The Setup screen appears. viDeo SeTup video profile From the Setup menu, select the <video ( )>...
To add a video profile You can add as many codecs as necessary so that a variety of profiles can be applied according to the recording condition. Select a profile number. Provide the name and select a codec. Specify the conditions under which the codec will be applied. Specify the details of the selected codec including resolution and frame rate.
Page 46
setup screen video Setup From the Setup menu, select the <video ( )> tab. Click <video setup>. Select a <video source> mode. Flip mode : Turn upside down the image that is captured by the camera. Mirror mode : Flip horizontal the ...
neTworK SeTup interface From the Setup menu, select the <network ( )> tab. Click <interface>. Set the <interface> and <ipv6 setup> as necessary. IP type : Select an IP connection type. Manual : Specify the IP address, Subnet Mask, Gateway, DNS1, and DNS2.
Page 48
HTTP port : HTTP port used to access the camera via the web browser. The default is 80(TCP). VNP port : Set a port used to transfer video signals with the Samsung protocols. RTSP port : Used to transfer videos in the RTSP mode; the default is 554.
DDnS To register your product with the Samsung DDnS Visit the iPOLiS web site(www. samsungipolis.com) and sign in with a registered account. From the top menu bar, select <DDnS ServiCe>-<my DDnS>. Click [proDuCT reGiSTrATion]. Enter the product domain.
Page 50
To connect to the Samsung DDnS in camera setup From the DDNS setup page, set <DDnS> to <Samsung DDnS>. Provide the <Host name> that you registered product domain with the DDNS site. Click [Apply ( When the connection is successfully made, you will see the message of <(Success)>...
Page 51
You can select a secure connection system or install the public certificate for this purpose. From the Setup menu, select the <network ( )> tab. Click <SSL>. Select a secure connection system. To access the camera using HTTPS mode, you have to type the IP address for the camera in the form of “https://<Camera_IP>”.
setup screen evenT SeTup fTp/e-mail You can configure the FTP/E-mail server settings so that you can transfer the images stored in the camera to your PC if an event occurs. From the Setup menu, select the <event ( )> tab. Click <fTp / e-mail>.
Subject : Enter a subject for your email. Body : Provide the text for the massage. Attach the event images to the email that you are preparing. When done, click [Apply ( video analysis From the Setup menu, select the <event ( )>...
Page 54
setup screen To use the iv analysis function according to the virtual line based rule Set <iv analysis function> to <enable>. Set the event rule to <virtual line based rules>. Click a desired point in the video and drag it to the end point. Then, the popup window appears.
Click [oK]. To cancel the specified area, right-click on the area and select [Delete] in the context menu. When done, click [Apply ( To use the iv analysis function according to the whole area based rule Set <iv analysis function> to <enable>.
setup screen Specify the <Transfer interval>. Specify the activation conditions. FTP sending : Specify the use of the FTP transfer if an event occurs. When done, click [Apply ( SySTem SeTup product information From the Setup menu, select the <System ( )>...
Date & Time From the Setup menu, select the <System ( )> tab. Click <Date & Time>. Specify the time and date that will be applied to the camera. Current system time : Displays the current time settings of your system. Timezone : Specify the local time ...
Page 58
setup screen Video : You can select a video profile in the Liver viewer screen. Controls : You can control camera menu. When done, click [Apply ( upgrade/reboot From the Setup menu, select the <System ( )> tab. Click [upgrade / reboot]. Select a desired item and set it appropriately.
Page 59
To save the current settings and restore the backup settings Click [Backup]. The Save As dialog should appear. Specify the backup path with a proper file name, and click [Save]. The backup file will be saved to the specified path in the format of “.bin”. To restore the backup settings, click [restore].
Page 60
setup screen You can check the system log or event log. From the Setup menu, select the <System ( )> tab. Click <Log>. Select a log type. Syslog : You can check the system logs where any system changes are recorded including the time information.
Page 61
appendix SpeCifiCATion Description Items Imaging Device 1/3" 1.3M PS CMOS Total Pixels 1,384(H) x 1,076(V) Effective Pixels 1,329(H) x 1,049(V) Scanning System Progressive Synchronization Video Frequency Horizontal Resolution Min. Illumination Color : 1.0 Lux (F1.8, 50IRE), 0.016 Lux (Sens up 60X) S / N Ratio 50dB Video Out...
Page 62
Day & Night Backlight Compensation Off / BLC / HLC Wide Dynamic Range Operational Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On) Digital Noise Reduction SSNRIII (2D+3D Noise Filter) (Off / On) Digital Image Stabilization Motion Detection Privacy Masking...
Page 63
Description Items Gain Control Off / Low / Medium / High / Manual White Balance ATW / AWC / Manual / Indoor / Outdoor Electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 30,000sec) Digital Zoom Flip / Mirror Off / On Profile Operational...
Page 64
appendix Description Items H.264/MPEG4 : Compression Level, Target Bitrate Level Video Quality Adjustment Control MJPEG : Quality Level Control H.264/MPEG4 : CBR or VBR Bitrate Control Method MJPEG : VBR Streaming Capability Multiple Streaming (Up to 10 Profiles) Audio I/O Audio Compression Format Audio Communication IPv4, IPv6...
Page 65
Description Items Operating Temperature / -10°C ~ +50°C (+14°F ~ +122°F) / ~ 90% RH Humidity Environmental Ingress Protection IP66 Grade (Waterproof) Input Voltage / Current 12V DC, PoE(IEEE802.3af) Electrical Power Consumption Max. 6W Color / Material Body : Ivory / Aluminum Mechanical Dimensions (WxHxD) W125.2 x H52 x D115.2mm...
TrouBLeSHooTinG PROBLEM SOLUTION Check to make sure that the camera’s Network settings are appropriate. Check to make sure that all network cables have been connected properly. If connected using DHCP, verify that the camera is able to acquire ...
Page 68
appendix PROBLEM SOLUTION No JPEG file is transferred via Verify the settings in the following sequence: e-mail on occurrence of intelligent A. Check <Data & Time> settings. video analysis event of camera B. The <IV analysis function> should be set to <Enable>. even when the <IV analysis C.
Page 69
Its advanced feature-set (FastCGI, CGI, Auth, Output-Compression, URL-Rewriting and many more) make lighttpd the perfect webserver- software for every server that suffers load problems. For more additional information, send email to help.cctv@samsung.com. Copyright (C) 2004, Kneschke, incremental All rights reserved.
Page 70
Copyright (c) 1998-2001 university College London All rights reserved. Redistribution and use in source and binary forms, with or without modification, is permitted provided that the following conditions are met : 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
GPL/LGPL. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
Page 72
original authors' reputations. you receive it, in any medium, provided that you conspicuously and appropriately Finally, any free program is threatened publish on each copy an appropriate constantly by software patents. We wish copyright notice and disclaimer of to avoid the danger that redistributors of a warranty;...
Page 73
based on the Program is not required performing source distribution, a to print an announcement.) complete machinereadable copy of the corresponding source code, These requirements apply to the modified to be distributed under the terms work as a whole. If identifiable sections of Sections 1 and 2 above on a of that work are not derived from medium customarily used for software...
Page 74
However, parties who have received then the only way you could satisfy both copies, or rights, from you under this it and this License would be to refrain License will not have their licenses entirely from distribution of the Program. terminated so long as such parties If any portion of this section is held invalid remain in full compliance.
a version number of this License which TO IN WRITING WILL ANY applies to it and "any later version", you COPYRIGHT HOLDER, OR ANY have the option of following the terms and OTHER PARTY WHO MAY MODIFY conditions either of that version or of any AND/OR REDISTRIBUTE DAMAGES, later version published by the Free Software INCLUDING ANY GENERAL, SPECIAL,...
Page 76
WARRANTY ; without even the implied program is a subroutine library, you may warranty of MERCHANTABILITY or consider it more useful to permit linking FITNESS FOR A PARTICULAR PURPOSE. proprietary applications with the library. If this is what you want to do, use the Gnu See the GNU General Public License for Lesser General public License instead of more details.
Page 77
or asking you to surrender the rights. development and use of software on Therefore, you have certain responsibilities general-purpose computers, but in those if you distribute copies of the software, or if that do, we wish to avoid the special danger you modify it: responsibilities to respect the that patents applied to a free program freedom of others.
Page 78
An interactive user interface displays performing those activities but which are not “Appropriate Legal Notices” to the extent part of the work. For example, Corresponding that it includes a convenient and prominently Source includes interface definition files visible feature that (1) displays an appropriate associated with source files for the work, copyright notice, and (2) tells the user that and the source code for shared libraries and...
Page 79
3. protecting users' Legal rights from c) You must license the entire work, as a Anti-Circumvention Law. whole, under this License to anyone who comes into possession of a copy. This No covered work shall be deemed part of an License will therefore apply, along with effective technological measure under any any applicable section 7 additional terms,...
Page 80
model, to give anyone who possesses A “User Product” is either (1) a “consumer the object code either (1) a copy of the product”, which means any tangible personal Corresponding Source for all the software property which is normally used for personal, in the product that is covered by this family, or household purposes, or (2) anything License, on a durable physical medium...
Page 81
or installed by the recipient, or for the User works containing it; or Product in which it has been modified or c) Prohibiting misrepresentation of the origin installed. Access to a network may be of that material, or requiring that modified denied when the modification itself materially versions of such material be marked in and adversely affects the operation of the...
Page 82
or modify it is void, and will automatically from the original licensors, to run, modify terminate your rights under this License and propagate that work, subject to this (including any patent licenses granted under License. You are not responsible for enforcing the third paragraph of section 11).
Page 83
Each contributor grants you a non-exclusive, prohibits the exercise of, or is conditioned worldwide, royalty-free patent license under on the non-exercise of one or more of the the contributor's essential patent claims, to rights that are specifically granted under this make, use, sell, offer for sale, import and License.
Page 84
work, and to convey the resulting work. TO, THE IMPLIED WARRANTIES OF The terms of this License will continue to MERCHANTABILITY AND FITNESS FOR A apply to the part which is the covered work, PARTICULAR PURPOSE. THE ENTIRE RISK but the special requirements of the GNU AS TO THE QUALITY AND PERFORMANCE Affero General Public License, section 13, OF THE PROGRAM IS WITH YOU.
Page 85
USA Everyone is permitted to copy and we gave you. You must make sure that distribute verbatim copies of this license they, too, receive or can get the source document, but changing it is not allowed. code. If you link other code with the library, you must provide complete object files to [This is the first released version of the Lesser the recipients, so that they can relink them...
Page 86
Public License therefore permits such a “work that uses the library”. The former linking only if the entire combination fits contains code derived from the library, its criteria of freedom. The Lesser General whereas the latter must be combined with Public License permits more lax criteria for the library in order to run.
Page 87
is covered only if its contents constitute a well-defined independent of the application. work based on the Library (independent of Therefore, Subsection 2d requires that any the use of the Library in a tool for writing it). application-supplied function or table used Whether that is true depends on what the by this function must be optional: if the Library does and what the program that...
Page 88
it is irreversible for that copy, so the ordinary though the source code is not. Whether this GNU General Public License applies to all is true is especially significant if the work subsequent copies and derivative works can be linked without the Library, or if the made from that copy.
Page 89
1 and 2 above); and, if the work is either source or binary form) with the major an executable linked with the Library, components (compiler, kernel, and so with the complete machine readable “ on) of the operating system on which the work that uses the Library”, as object executable runs, unless that component code and/or source code, so that the...
Page 90
it. However, nothing else grants you is intended to apply, and the section permission to modify or distribute the as a whole is intended to apply in other Library or its derivative works. These circumstances. actions are prohibited by law if you do It is not the purpose of this section to not accept this License.
Page 91
later version published by the Free Software PERMITTED ABOVE, BE LIABLE TO Foundation. If the Library does not specify YOU FOR DAMAGES, INCLUDING a license version number, you may choose ANY GENERAL, SPECIAL, any version ever published by the Free INCIDENTAL OR CONSEQUENTIAL Software Foundation.
WARRANTY; without even the implied use in the OpenSSL Toolkit. (http://www. warranty of MERCHANTABILITY or openssl.org/)” FITNESS FOR A PARTICULAR PURPOSE. 4. The names “OpenSSL Toolkit” and See the GNU Lesser General Public “OpenSSL Project” must not be used to License for more details.
Page 93
original SSLeay License 4. If you include any Windows specific code (or a derivative thereof) from the apps Copyright (C) 1995-1998 Eric Young (eay@ directory (application code) you must cryptsoft. com) All rights reserved. This include an acknowledgement: “This package is an SSL implementation written product includes software written by Tim by Eric Young (eay@cryptsoft.
Page 94
TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 1480 Charles Willard St, Carson, CA 90746, UNITED STATES Samsung House, 1000 Hillswood Drive, Hillswood Business Tol Free : +1-877-213-1222 FAX : +1-310-632-2195 Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS www.samsungcctvusa.com TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 www.samsungtechwin.com...
