Specification
Model
A60
Pick up Element
1/3" SONY Super HAD CCDII
Effective Picture Elements
NTSC:768(H)×494(V) PAL:752(H)x582(V)
(H×V)
Horizontal Resolution
650 TV Line
0.001 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio
More than 52dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
NTSC: 1/60s~1/100,000s, PAL:
Auto Electronic Shutter
1/50s~1/100,000s
Gama Characteristic
0.45
IR Distance
20 Meters (with ￠5X24 PCS Infrared LED)
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
DC12V(+/-10%)/350mA
Lens
Board Lens 3.6mm /F2.0
Dimension (mm)
￠94 x 69(H)
Weight (g)
400
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
IP66
IP Rating
Packing List
No
Name
1.
Vandalproof IR Dome Colour Camera
2.
User Guide
The unit comes with a unique warranty reference sticker that will be
void if the camera is disturbed. Please NOTE that in order to retain the
cameras warranty you must not dismantle the camera.
IMPORTANT
from water, dust and ingress you use the screws and SEALS provided
that have been carefully selected to protect the unit.
Distributor -
Model
Number
A60
1
A60
1
We advice that in order to protect the camera
A60
VANDALPROOF IR DOME CAMERA 650TVL
PLEASE NOTE -
Before connecting the
camera up to a power source, please
read the instruction Manual provided.
USER MANUAL
Advertisement
Table of Contents
Summary of Contents for Ultra PRO-ONE A60
-
Page 1: Packing List
Specification Model Pick up Element 1/3" SONY Super HAD CCDII Effective Picture Elements NTSC:768(H)×494(V) PAL:752(H)x582(V) (H×V) Horizontal Resolution 650 TV Line 0.001 Lux/F1.2 Minimum Illumination 0Lux (with IR LED ON) S/N Ratio More than 52dB Scanning System 2:1 interface VANDALPROOF IR DOME CAMERA 650TVL Synchronous System Internal, Negative sync. - Page 2 Connecting Properties Introduction Congratulations on purchasing your new A60 Vandal Image Sensor (CCD) Dome camera Designed and Manufactured by ULTRA PRO- ONE. The unit adopts the latest SONY technical image sensor Adopt SONY 1/3" CCD Sensor. Monitor Video and drivers. The most attractive characteristics are small and...
