HME ion BP COM6100 Operating Instructions Manual

SETUP

Power On/Off

To turn the power on
Press and release the power (PWR) button.
A voice message in the headset will say
"Belt-pac #, Battery Full/Half/Low, Lane 1"
and two red power lights will come on for a
few seconds and then one red light will go off
and the other will change to green and remain
on steady near the A1 button for Lane 1.
To turn the power off
Press and hold the PWR button for approximately
3 seconds. A voice message in the headset will say
"Belt-pac off," and the power light will go off.

Configure Belt-Pac

Start with power OFF and then press and hold any of the following button combinations while turning the
power ON. Immediately release all buttons after pressing the PWR button. Each of these settings has an
associated voice prompt. Listen to the voice prompt to confirm the setting.
Hands Free (HF) On/Off ─ Press and hold B and the Up ▲ arrow
• • • •
while you press the PWR button to turn the belt-pac on in the HF
mode. With the power off again, press and hold B and the Down
▼ arrow while you press the PWR button to turn off the HF mode.
Auto HF (AHF) ─ Press and hold A1 or A2 and the Up ▲ arrow
• • • •
while you press the PWR button to turn the belt-pac on in the
Auto HF mode. When you turn the unit off, the AHF mode will
not be saved.
"B" Channel HF (BHF) ─ Press and hold B and A2 while you
• • • •
press the PWR button to turn the belt-pac on in the BHF mode.
Press and release the B button, and channel B will stay open to
allow hands-free communication with other crew members. If a
customer arrives, B-channel will automatically be interrupted to
allow communication with the customer on channel A1 or A2.
Language selection ─ To change between English and the
• • • •
other language, press and hold A1 and the Down ▼ arrow
while you press the PWR button to turn the belt-pac on.
Doing this again changes back to the first language.
Play status ─ Press A2 and the Down ▼ arrow while you press the PWR button to turn the belt-pac on.
• • • •
An example of the status you will hear is: "Belt-pac #, Battery Full/Half/Low, English/Espanol, Hands-
Free A On/Off (or Hands-Free B On/Off), firmware version #, Lane #."
If you have any problems with your Communicator –
In the USA, call or Fax HME Technical Support at the numbers below.
Outside the USA, call your local HME representative for assistance.
HM ELECTRONICS, INC.
COM6100 COMMUNICATOR COM6100 COM6100 COM6100
OPERATING INSTRUCTIONS
─
─
14110 Stowe Drive, Poway, CA 92064 USA • Phone: 1-800-848-4468 Fax: (858) 552-0172
ion BP
COMMUNICATOR COMMUNICATOR COMMUNICATOR
Figure 1. ion BP belt-pac and headset
Volume-Up Power
button button
Channel "A1" Channel "B"
button
button
Figure 2. Belt-pac controls
®
Volume-Down
button
Channel "A2"
button
HME# 400G666
Rev A 5/16/11
