Summary of Contents for AC Ryan VEOLO2
-
Page 1: User Manual
S M A R T A N D R O I D H U B AC RYAN VEOLO2 User Manual... -
Page 2: Table Of Contents
User Information Table of contents 1 User Information 2 Product Overview Product appearance Accessories 3 Getting Started Power on/off Pairing the VEO Navigator Using the VEO Navigator Setting the language Joining a network Setting date & time Connecting to your computer 4 Basics Home screen Using apps... -
Page 3: User Information
User Information 1 User Information 1.1 Caution This player is designed and manufactured with safety in mind. In order to safely and effec- tively use this player, please read the following before usage. 1.1.1 Usage cautions User should not modify this player. If commercial hard disk is being used, the environmental temperature should be within +5 ~ +35 degree celsius. - Page 4 User Information 1.1.6 Others When using this player, please do not let the player come into contact with water or other liquid, if water is accidentally spilled on the player, please use a dry cloth to absorb the spill- age. Electronic products are vulnerable, when using please avoid the following: •...
-
Page 5: Product Overview
User Information 2 Product Overview Product appearance Complies with IDA Standards DA105678 Accessories Part Quantity A.C.Ryan VEOLO2 VEO Navigator (Remote control) User manual AV-Out Cable HDMI Cable Micro USB Cable AC/DC adaptor... -
Page 6: Getting Started
User Information 3 Getting Started Power on/off This player does not require a power button. To power on the unit, connect the AC adaptor jack to the player’s DC-In socket and plug in the AC adaptor to the power outlet. The player will boot up when power is supplied. -
Page 7: Pairing The Veo Navigator
Before you can use the player you will need to pair the remote control first. This step is only required to be done once. For more information or help regarding this step, please contact AC Ryan support via email at techsupport@acryan.com Power on your Hold the VEO Navigator within player. -
Page 8: Using The Veo Navigator
User Information Using the VEO Navigator The VEO Navigator is designed to be light-weight and ergonomically easy to hold and use. Based on RF 2.4GHz technology, the VEO Navigator can be used without having to be pointed direct line-of-sight with the player. Please take a moment to familiarise yourself with the remote control. -
Page 9: Setting The Language
User Information Setting the language You can change the system language to your desired preference. To do this, click on the settings icon on the home screen, then at the left pane scroll down to the ‘PERSONAL’ header, and click on ‘Language & input’, and at the right pane click on ‘Language’. Select your preferred language and click on the selection. -
Page 10: Setting Date & Time
User Information Once you join a Wi-Fi network, it automatically remembers and connects whenever the network is in range. If more than one used network is in range, then it will join the last connected one. Setting date & time The player can automatically obtain the date &... -
Page 11: Connecting To Your Computer
User Information Connecting to your computer Connecting to your computer allows you to copy files between your computer and the local memory or Micro SD Card. Connect to your computer with the USB cable. Go to the Home Screen, click on the notification icon on the bottom-right corner of the screen and then click on ‘USB connected’... -
Page 12: Basics
User Information 4 Basics Home screen The home screen is the main user interface of the player. In the home screen, all default icons are placed in a single row which can be repositioned by long clicking on any of the icons and then dragging it to the new position. The home screen has empty spaces which can be placed with your desired apps shortcuts, or widgets shortcuts. - Page 13 User Information The home screen contains various frequently used functions and shortcuts that makes it convenient for the user to use and control. Please spend a moment of your time to familiar- ise with the home screen. My apps: This is where all installed apps and widgets can be found. Clear memory: Free up system memory by ending unused apps running in the background.
-
Page 14: Using Apps
User Information Using apps Click on the ‘My apps’ icon to display all of your installed apps and widgets. Clicking once on any of the app icon will then launch its application. To exit the application, press the ‘Menu’ button of the remote control to find any exit option or a common way among Android apps will be to press the ‘Return’... - Page 15 User Information To remove any of the apps shortcuts in the categories or on the home screen, click and hold on to the desired app until you see a ‘X Remove’ overlay appearing at the top of the screen. Drag the app and drop it off here and the app shortcut will be deleted. Note: Deleting the app shortcut does not delete the actual app itself.
-
Page 16: Typing Using The Veo Navigator
User Information Typing using the VEO Navigator The VEO Navigator comes with a full qwerty keyboard that allows the user to conveniently type in any input entries environment, like keying in a website URL, typing in keyword searches, or during an instant messaging session, etc. Simply flip over to the keyboard side and start typing by pressing on the remote control keys. -
Page 17: Internet Browser
User Information Internet browser In this section we will describe some of the functions and usage of the default Android operating system’s internet browser. Users can also install various kind of browser that are available on the Google PlayStore. Unless the default browser app has been replaced by the user, launch the stock browser application by clicking once on the ‘Web browser’... -
Page 18: File Explorer
User Information File explorer The file explorer allows you to view files that are on your internal flash memory, micro SD card and other USB storage devices if they are attached. Launch the stock file explorer application by clicking once on the ‘File explorer’ icon on the home screen, or clicking once on the ‘File explorer’... -
Page 19: Settings
User Information Settings You can customise your personalised preferences via the settings menu. The settings can be accessed by clicking once on the ‘Settings’ icon on the home screen, or clicking once on the ‘Settings’ icon in the ‘My apps’ section. Below is a brief decription of the various settings you can find in this menu. - Page 20 User Information PERSONAL Sets password to prevent unauthorised usage or to allow 3rd party apps installation that are not downloaded from Google PlayStore. Allows you to select the desired system menu language and keyboard language to use as default if you have more than one software key- board app installed.
-
Page 21: Specifications
User Information 5 Specifications I/O Interface • Mini HDMI port • Composite A/V output • S/PDIF Optical output • Micro USB Slave port • 2x USB2.0 Host port • MicroSD card slot (Supports up to 32GB SDHC) • 10/100mbps Ethernet port • DC-In 5V System configuration • Android 4.1.1 Jelly Bean • Quad-Core 1.6GHz ARM Cortex-A9 Processor • 1GB DDR3 • 8GB NAND Flash • Mali400-MP4 3D Graphics Processor • Quad-Core GPU (500MHz per Core) • Supports OpenGL ES 1.1/2.0 and OpenVG 1.1 Wireless and connectivity • Built-in 802.11 b/g/n wireless adapter • High-gain external Wi-Fi antenna VEO Navigator (Remote control) • RF 2.4GHz wireless connectivity • Air-mouse with power saving features • Wireless QWERTY keyboard • G-sensor for tilting motion • Micro USB charging port • Built-in rechargeable Lithium battery... -
Page 22: Warranty
User Information Container supported • AVI / DAT / M2TS / MKV / MOV / MP4 / MPG / RM / RMVB / TP / TRP / TS / VOB / WMV • 3GPP / AAC / APE / FLAC / MP3 / M4A / OGA / OGG / WAV / WMA • BMP / GIF / JPG/JPEG / PNG Video and Audio codec supported • AVS / H.263 / H.264 / MPEG-1/2/4 / MVC / RV / Sorenson Spark / VP6 / VC-1 / VP8 • AAC / APE / FLAC / MP2 / MP3 / OGG Vorbis / WMA Standard (DRM, and Advanced Profile not supported) / Real Audio Note: The specifications and design of this product are subject to change without notice. 6 Warranty This packaging does not come with a warranty card. Please register your product warranty within 7 days of purchase on our website www.acryan.com under the Support tab, and click on the Product Registration link.
