Contec IPC-BX/M630 Series User Manual

Ipc series box-pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

IPC Series
BOX-PC
IPC-BX/M630(PCI) Series
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading

Related Manuals for Contec IPC-BX/M630 Series

Summary of Contents for Contec IPC-BX/M630 Series

  • Page 1 IPC Series BOX-PC IPC-BX/M630(PCI) Series User's Manual CONTEC CO.,LTD.

  • Page 2: Trademarks

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 3: Table Of Contents

    Table of Contents Copyright ................. i Trademarks ..............i Table of Contents ............ii Introduction ............1 Features ..............2 Compatible Operating Systems ......... 2 Limited One-Year Warranty........2 How to Obtain Service..........3 Liability............... 3 Handling Precautions..........4 About the Manual............6 Overview ............7 Specifications ..............
  • Page 4 I/O Device Configuration Window......37 Security Window ............39 Power Window............40 PC-Health Window ........... 41 Boot Window ............. 42 Exit Window .............. 43 Each Component Function ......45 Component Identification ......... 45 Line in Interface ............48 Line out Interface ............. 48 MIC input Interface ..........
  • Page 5 User’s Manual...

  • Page 6: Introduction

    1. Introduction 1. Introduction The IPC-BX/M630(PCI) is an IBM PC/AT compatible, box computer designed for industrial use based on a low-power-consumption CPU of the Low Voltage Intel(R) Pentium(R) III Processor, to operate as a completely nature-cooled (fanless) system. The box computer provides a variety of interfaces including the USB, 100BASE-TX, and RS-232C ports, capable of serving for a wide range of applications as a compact platform based on a general-purpose PC OS.

  • Page 7: Features

    - Windows NT Embedded 4.0 Limited One-Year Warranty CONTEC Interface boards are warranted by CONTEC CO., LTD. to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser.

  • Page 8: How To Obtain Service

    Please obtain a Return Merchandise Authorization Number (RMA) from the CONTEC group office where you purchased before returning any product. * No product will be accepted by CONTEC group without the RMA number. Liability The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be liable for any incidental or consequential damages due to such defect or consequences that arise from inexperienced usage, misuse, or malfunction of this device.

  • Page 9: Handling Precautions

    1. Introduction Handling Precautions Take the following precautions when handling this product. WARNING - Always check that the power supply is turned off before connecting or disconnecting power cables. - Do not modify the product. - Always turn off the power before inserting or removing circuit boards or cables. - This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other applications that require a very high level of reliability.
  • Page 10 - CONTEC reserves the right to refuse to service a product modified by the user. - In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact the sales representative you purchased the product from or the CONTEC Information Center.

  • Page 11: About The Manual

    1. Introduction - Image diagram Ferrite core FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.

  • Page 12: Overview

    2. Overview 2. Overview Specifications Table 2.1. Functional Specifications < 1 / 2 > Model IPC-BX/M630(PCI)C IPC-BX/M630(PCI)CP IPC-BX/M630(PCI)C4P Low Voltage Intel(R) Pentium(R) III Processor, FSB133MHz Chip set Intel(R) 815E L2 Cache 512KB Main Memory 256 MB standard *1 / Max. 256MB (3.3V 144pin SO-DIMM PC133 Socket × 2) memory BIOS ROM 128KB E0000H - FFFFFH (Phoenix)
  • Page 13 *1 A 256 MB memory module is plugged in one socket. *2 The interface can connect the PC to a CONTEC Panel Link input type display (using an optional cable) or an ordinary analog RGB input display (using the bundled DVI-analog RGB adapter).
  • Page 14 2. Overview Table 2.2. Installation Environment Requirements Parameter Requirement description Allowable instantaneous Less than 20ms Power supply One minute each for 3.0 kVAC (input-output), 2.0 kVAC (input-FG), power outage specifications and 0.5 kVAC (output-FG) Dielectric strength 50MΩ (DC500V) 0 - 50°C(SDD in use) Operating temperature 5 - 45°C(HDD in use) 5 - 45°C(FDD in use)

  • Page 15: System Configuration

    2. Overview System Configuration 2.5inch hard (silicon) disk drive Main memory 144pin SO-DIMM Printer IPC-BX/M630(PCI)CP Buil Panel Link compliant I/F LCD *Using an optional DVI-Panel Link conversion cable LINE IN General-purpose analog input LINE OUT display *Using the bundled DVI-analog RGB adapter Mouse Option CD-ROM...

  • Page 16: Physical Dimensions

    2. Overview Physical Dimensions IPC-BX/M630(PCI)C 4-φ5 [mm] Figure 2.2. IPC-BX/M630(PCI)C User’s Manual...
  • Page 17 2. Overview IPC-BX/M630(PCI)CP 4-φ5 [mm] Figure 2.3. IPC-BX/M630(PCI)CP User’s Manual...
  • Page 18 2. Overview IPC-BX/M630(PCI)C4P 4-φ5 [mm] Figure 2.4. IPC-BX/M630(PCI)C4P User’s Manual...
  • Page 19 2. Overview User’s Manual...

  • Page 20: Hardware Setup

    3. Hardware Setup 3. Hardware Setup Before Using the BOX-PC for the First Time Follow the next steps to set up the BOX-PC: STEP1 Install the hard disk and expansion main memory (DIMM) and set jumper switches. By referring to the information in this chapter, set the BOX-PC. STEP2 Connect cables.

  • Page 21: Hardware Setup

    3. Hardware Setup Hardware Setup Removing the Top Cover and HDD Bracket - Before you start, be sure that the power is turned off. - Remove only those screws that are explained. Do not move any other screw. Remove the top cover. Figure 3.1.
  • Page 22 3. Hardware Setup Remove the hard disk bracket. Figure 3.2. Removing the HDD Bracket User’s Manual...

  • Page 23: Locations And Settings Of Internal Connectors And Jumpers

    3. Hardware Setup Locations and Settings of Internal Connectors and Jumpers When you remove the top cover and hard disk bracket, the connectors, jumpers, and switches are laid out as shown in the figure below: Figure 3.3. Locations and Settings of Jumpers, Connectors, and Switches inside the Top Cover User’s Manual...
  • Page 24 3. Hardware Setup Table 3.1. Jumper List Function Factory setting Reference Page Remarks Clear CMOS. 1 - 2 shorted ---- Short 2-3 to clear CMOS. Sets RS-485 termination 2 - 3 shorted Select the use of serial ports C 1 - 8 OFF and D.

  • Page 25: Installing The Hard Disk

    3. Hardware Setup Installing the Hard Disk Connect the provided HDD cable to the hard disk (silicon disk). Note! Connect the HDD cable in alignment with pins from the left end of the connector on the HDD side. Four master/slave setting pins are left unconnected on the right side. Be aware that connecting the power with the connector misaligned will damage the cable.

  • Page 26: Installing The Main Memory (Dimm)

    Obtain the following special option products. - Package type :144pin Small Outline DIMM - Specifications :3.3V, PC133/CL3 - Capacity :256MB - Type :SDRAM - Optional memories * :PC-MSD256-144V * Operation is not guaranteed if memory parts other than CONTEC option products are used. User’s Manual...
  • Page 27 3. Hardware Setup Main Memory (DIMM) Installation Procedure The mounted SO-DIMM sockets vary depending on the type of the circuit board used. <Board type with single sockets on its front and back> This type of circuit board has single sockets on its front and back. The socket on the back is equipped with standard memory.
  • Page 28 3. Hardware Setup <Board type with a double socket on its front> This product has a double socket on the front of its circuit board. Standard memory is installed in the lower socket. To add more memory, install it to the upper socket. SO-DIMM Disconnection Procedure Open the levers on both sides slightly to the left and right.

  • Page 29: Fastening The Power Cable

    3. Hardware Setup Fastening the Power Cable Removing the Screw on the Metal Brace to Keep the AC Cord in Place In order to install the metal brace, temporarily remove the machine screw on the front left end. Remove this screw. Figure 3.7.

  • Page 30: Installing The Serial 3, 4 Bracket

    3. Hardware Setup SERIAL Installing the 3, 4 Bracket To use the serial ports for SERIAL 3 and 4 in place of RAS and PRINTER, replace the bracket as follows: Be sure the power is turned off. Remove the top cover. Figure 3.10.
  • Page 31 3. Hardware Setup Attach the SERIAL 3/4 bracket. Tighten the two screws on the interface side to fasten the bracket. Figure 3.12. Installing the Bracket Plug the SERIAL 3 and 4 cable connectors into CN16 (SERIAL4) and CN19 (SERIAL3) as illustrated below, respectively. Figure 3.13.

  • Page 32: Installation Requirements

    3. Hardware Setup Replace the top cover. Figure 3.15. Replacing the Top Cover Installation Requirements The BOX-PC can be installed in any orientation (1) - (3). Avoid orientation (4) - (6) since it might not adequately dissipate heat. Similarly, to maintain the ambient temperature within the range specified in the specifications, ensure a clearance between the unit and surrounding equipment of at least 100mm for the top and rear and 50mm for the bottom and sides.
  • Page 33 3. Hardware Setup Installation Orientation Floor Connectors Ceiling Connectors Figure 3.16. Installation Orientation User’s Manual...
  • Page 34 3. Hardware Setup Distances between the BOX-PC and Its Vicinity 50mm or more (side) 50mm or more (side) 100mm or more (above) 50mm or more (back) Connectors Figure 3.17. Distances between the BOX-PC and Its Vicinity User’s Manual...
  • Page 35 3. Hardware Setup User’s Manual...

  • Page 36: Bios Setup

    Press the <F2> key at the keyboard. Phoenix BIOS 4.0 Release 6.0 Copyright 1985-2001 Phoenix Technologies Ltd. All Rights Reserved Copyright 2001, CONTEC CO., Ltd. IPC-BX/M630(PCW), IPC-Px/x630(PCW) series BIOS Ver. x.xx. CPU = Pentium III(R) Tualatin 512K-LP(133MHz/1.150) processor 800MHz Memory Speed = PC133...

  • Page 37: Main Menu

    4. BIOS Setup Main Menu PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help System Time: [00:55:20] System Date: [09/05/2002] <Tab>, <Shift-Tab>, or <Enter> selects field Legacy Diskette A: [1.44/1.25 MB "] Primary Master [No device] Primary Slave [No device] Secondary Master...
  • Page 38 4. BIOS Setup Primary Slave : Set the type of HDD(SDD) to be used as the second drive. Selecting this field changes the screen to the submenu for manually setting drive configuration data such as the number of cylinders. This field is set to [Auto] by default.

  • Page 39: Boot Features Window

    4. BIOS Setup Boot Features Window PhoenixBIOS Setup Utility Main Boot Features Item Specific Help Floppy check : [Disabled] Keyboard check : [Disabled] ↓ Select Item Help Change Values Setup Defaults ←→ Select Menu Esc Exit Enter Select Sub-Menu F10 Save and Exit Figure 4.3.

  • Page 40: Advanced Window

    4. BIOS Setup Advanced Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Reset Configuration Data: [No] Installed O/S: [Other] Select 'Yes' if you PCI IRQ want to clear the PCI/PMP ISA UMB Region Exclusion Extended System PCI/PMP ISA DMA Resource Exclusion Configuration...

  • Page 41: User's Manual

    4. BIOS Setup I/O Device Configuration: Start I/O Device Configuration as shown above. You can configure serial and parallel ports. ( See I/O Device Configuration Window.) ISA Bridge: This item is not available. Legacy USB Support : Emulates the USB keyboard, mouse, and FDD as legacy devices.

  • Page 42: I/O Device Configuration Window

    4. BIOS Setup I/O Device Configuration Window PhoenixBIOS Setup Utility Advanced I/O Device Configuration Item Specific Help Serial Port A : [Enabled] Configure port Base I/O address : [3F8] using options: Interrupt : [IRQ 4] Serial port B : [Enabled] [Disabled] Base I/O address : [2F8]...
  • Page 43 4. BIOS Setup Fields available with Parallel port set to [Enabled] Base I/O address Set to base I/O address. Interrupt Set to IRQ. Mode Set to parallel port's operating mode. DMA channel This is the DMA channel setting used when ECP is selected during parallel-port mode setting.

  • Page 44: Security Window

    4. BIOS Setup Security Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Set Supervisor Password : [Enter] Set User Password : [Enter] Supervisor Password controls access to the Supervisor Password Is : Clear setup utility. User Password Is : Clear Password on boot :...

  • Page 45: Power Window

    4. BIOS Setup Power Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Enable ACPI : [No] ACPI Supend Mode : [Disabled] Select 'Yes' if you want to clear the APM Capabilities : [Disabled] Extended System Configuration Power Saving : [Disabled]...

  • Page 46: Pc-Health Window

    4. BIOS Setup PC-Health Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Hardware Monitor Setup Thermal1_0 (System1): +32°C / +89°F Thermal1_1 (CPU): +56°C / +132°F FAN_0 : 0 RPM FAN_1 : 0 RPM +5V : +4.97V +3.3V : +3.28V...

  • Page 47: Boot Window

    4. BIOS Setup Boot Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help *Removable Devies Keys used to view or configure devices : *Hard Drive <Enter> expands or CD-ROM Drive collapses devices with Network Boot a + or - <Ctrl + Enter>...

  • Page 48: Exit Window

    4. BIOS Setup Exit Window PhoenixBIOS Setup Utility Main Advanced Security Power PC..Health Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to Discard Changes CMOS. Save Changes Model : IPC-BX/M630(PCI), IPC-Px/x630(PCI) System BIOS : Vx.xx_xxx...
  • Page 49 4. BIOS Setup User’s Manual...

  • Page 50: Each Component Function

    5. Each Component Function 5. Each Component Function Component Identification IPC-BX/M630(PCI)C MOUSE HDD LED PRINTER SERIAL1 SERIAL2 TOP COVER POWER SW LINE IN LINE OUT AC INLET POWER LED PCMCIA RESET KEYBOARD (Ethernet) Slot1,2 IPC-BX/M630(PCI)CP Expansion slot(PCI) x 2 TOP COVER HDD LED PRINTER SERIAL1...
  • Page 51 5. Each Component Function IPC-BX/M630(PCI)C4P Expansion slot(PCI) x 4 TOP COVER HDD LED PRINTER SERIAL1 SERIAL2 MOUSE POWER SW LINE IN LINE OUT AC INLET POWER LED PCMCIA RESET KEYBOARD (Ethernet) Slot1,2 Figure 5.1. Component Identification < 1 / 2 > Side view IPC-BX/M630(PCI)C IPC-BX/M630(PCI)CP, C4P...
  • Page 52 5. Each Component Function Table 5.1. Component Functions Component Function LINE IN Line in ( φ 3.5 PHONE JACK) LINE OUT Line out ( φ 3.5 PHONE JACK) Microphone input ( φ 3.5 PHONE JACK) Keyboard connector (MINI-DIN, 6pin) MOUSE PS/2 mouse connector (MINI-DIN, 6pin) SERIAL1 Serial port 1 connector (9pin, male D-SUB)

  • Page 53: Line In Interface

    The audio driver is required to use the line input, line output, and microphone input interfaces. Visit the CONTEC web site to download the audio driver (IPC-SLIB-01) for the OS running on your BOX-PC. For the download, see Chapter 7 “List of Options".

  • Page 54: Keyboard Interface

    5. Each Component Function Keyboard Interface The BOX-PC is equipped with a keyboard connector named KB (MINI-DIN 6P). Table 5.2. Keyboard Connector Connector type Equivalent to the MD-DS12300-14S-14 (JST) Signal Pin No. Pin No. Signal +KBD DATA +KBD CLK N.C. N.C.

  • Page 55: Serial Port Interface

    5. Each Component Function Serial Port Interface Serial port A and B(RS-232C Ports) The BOX-PC is equipped with two RS-232C-compliant serial port connectors (SERIAL1: Serial port A and SERIAL2: Serial port B). You can use BIOS Setup (described in Chapter 3) to configure an I/O address, interrupt and unused state for each of the ports independently.
  • Page 56 One channel of serial port is provided for use as a touch panel connector (for a CONTEC flat panel display) or RS232C port (with the SERIAL3-4 bracket mounted). You can use BIOS Setup (described in Chapter 3) to configure an I/O address, interrupt and unused state for this port.
  • Page 57 5. Each Component Function Output connector with the RAS-PRINTER bracket mounted (factory default) Table 5.8. Output connector with the RAS-PRINTER bracket mounted (factory default) (RAS Connector) Pin No. Signal Meaning TX + Transmitted data + TX - Transmitted data - RX + Received data + RX -...
  • Page 58 5. Each Component Function Control of Transmitted Data in Half-Duplex Mode In half-duplex mode, the transmission buffer needs to be controlled in order to prevent collision of transmitted data. The BOX-PC uses RTS and controls the buffer with modem control register's bit 1. Transmission and reception gate control by the register setting of port address 4006h and 4007h is allowed only for the RS-422/485 (Serial port D).
  • Page 59 5. Each Component Function Table 5.10. Function of Each Register < 1 / 4 > I/O address Description 03F8H THR: Transmitter Holding Register [DLAB=0] bit0 bit7 Register dedicated to write transmitted data to 03F8H RBR: Reciever Buffer Register [DLAB=O] bit0 bit7 Register dedicated to read received data from 03F8H...
  • Page 60 5. Each Component Function Table 5.10. Function of Each Register < 2 / 4 > I/O address Description 03FAH IIR : Interrupt Identification Register Interrupt details 1: Do not generate interrupts 0: Generate interrupts bit2 bit1 bit0 Priority Description Interrupts are not generated. Generated by overrun, parity, framing error or break 1 (high) interrupt.
  • Page 61 5. Each Component Function Table 5.10. Function of Each Register < 3 / 4 > I/O address Description 03FCH MCR: Modem Control Register Loop IRQ RTS DTR 0 : Inactive [HIGH] 1 : Active [LOW] RTS 0 : Inactive [HIGH] 1 : Active [LOW] Interrupt control bit...
  • Page 62 5. Each Component Function Table 5.10. Function of Each Register < 4 / 4 > I/O address Description 03FEH MSR : Modem Status Register DSR CTS DDCD TERI DDSR DCTS Delta CTS Delta DSR Since these statuses are Trailing edge RI not used with Delta data carrier detect RS-485, data...

  • Page 63: Floppy Disk Interface

    5. Each Component Function Floppy Disk Interface The BOX-PC is equipped with a FD controller to allow one FD drive to be connected to the FD connector named FD on the front end. Use the FD drive that is available as a dedicated option.

  • Page 64: Usb Ports

    5. Each Component Function USB Ports The BOX-PC is equipped with two USB interface channels. Table 5.13. USB Connector Signal Signal Pin No. Pin No. USB0 Vcc USB1 Vcc USB0 -Data USB1 -Data USB0 +Data USB1 +Data USB0 GND USB1 GND User’s Manual...

  • Page 65: Ethernet

    : Normal connection indicator : Full-duplex mode indicator 100M : 100M-operation indicator LAN drivers Visit the CONTEC web site to download the LAN driver (IPC-SLIB-01) for the OS running on your BOX-PC. For the download, see Chapter 7 “List of Options". User’s Manual...

  • Page 66: Pc Card Slots

    5. Each Component Function PC Card Slots PCMCIA compliant, CardBus compatible card slots are provided. [TYPE II x 2 (TYPE III x 1) size] Slot 1 Slot 2 Figure 5.3. Slot Numbers and Locations Note! A type III card should be inserted into slot 2. Attaching the Metal Brace to Keep the Card in Place Insert the front end.

  • Page 67: Dvi Interface

    A DVI interface is provided. You can use it to connect a CRT (even a DB-15 connector is acceptable by using the bundled DVI-analog RGB adapter) or a CONTEC Panel Link display. The connector is named DVI (DVI-I 29-pin connector).
  • Page 68 5. Each Component Function Table 5.17. DVI-Analog RGB conversion adapter Connector DVI-I 29pin 15.00 6.20 30.00 5.80 [mm] Analog RGB signals Pin No. Signal Pin No. Signal GREEN BLUE N.C. N.C. DDC DATA HSYNC VSYNC DDC CLK User’s Manual...
  • Page 69 Set to the same values as were set during installation of the touch-panel driver software. Visit the CONTEC web site to download the Touch Panel driver (IPC-SLIB-01) for the OS running on your BOX-PC. For the download, see Chapter 7 “List of Options".

  • Page 70: Printer Port Interface

    5. Each Component Function Printer Port Interface A printer port is provided for use with the RAS-PRINTER bracket mounted. You can use BIOS Setup to configure an operation mode, I/O address, interrupt, DMA channel and unused state for this port. The connector is named PRINTER.

  • Page 71: Ras Functions

    5. Each Component Function RAS Functions A RAS port is provided for use with the RAS-PRINTER bracket mounted. This port offers watchdog timer, remote reset, and general-purpose I/O RAS functions. Table 5.20. RAS Connector Connector type 15pin D-SUB(FEMALE) (DALC-J15SAF-20L9) JAE Pin No.

  • Page 72: Watchdog Timer

    5. Each Component Function Watchdog Timer The watchdog timer is started by output of A5 to I/O port address 4002h. A second output of A5 to the same port within the specified expiration time once again triggers the watchdog timer. If a time-out occurs, a reset or an interrupt is generated according to the 4004h port setting or an alarm is output according to the 4004h port setting.
  • Page 73 5. Each Component Function How to Use the Watchdog Timer BIOS setting Power ON Set event Output data to ports 4001h and 4004h to set the output control counter clock. Read port 4002h, stop the WDT, and turn off alarm Instruct output.
  • Page 74 5. Each Component Function * 4001h (bit4-6): Alarm out output control WD_S1 WD_S0 PO2_M RESET PIM2 PIM1 PIM0 R/W (default: XXXX0000b) Figure 5.6. Alarm Out Output Control Port (4001h) PO2_M : PO PO2/WDT pin output setting Set the RAS connector's PO2/WDT(12) signal to PO2 (general-purpose output).
  • Page 75 5. Each Component Function * 4003h: WDT counter Figure 5.8. WDT Counter Port (4003h) Writes watchdog timer count data. Write watchdog timer counter expiration time data. → 1sec → 8sec → 15sec → 30sec * 4004h : Event output control RESET R/W (Default: XXXX0000b) Figure 5.9.
  • Page 76 5. Each Component Function * 4005h : RAS status port (Default: XXXXXXX0b) Figure 5.10. RAS Status Port (4005h) RAS status port WDT: WDT status This is the WDT status bit. This bit is cleared when the WDT stops (read port 4002h). The WDT is either stopped or counting.

  • Page 77: General-Purpose I/O And Remote Reset

    5. Each Component Function General-purpose I/O and Remote Reset The BOX-PC is equipped with three general-purpose isolated signals each for input and output. The input signals can also be used for interrupt input or remote reset input. Specifications [ Input ] - Input specifications : Current-driven input by Optocoupler isolation.
  • Page 78 5. Each Component Function I/O Addresses and Instructions * 4000h: General-purpose I/O PIO2 PIO1 PIO0 Figure 5.12. General-purpose Input Port (4000h) Read data from PI0, PI1 and PI2. Set data to be output to PO0, PO1 and PO2. * 4001h (bit0-3): PI2/IRQ(14) event input control WD_S1 WD_S0 PO2_M...
  • Page 79 5. Each Component Function * 4006h: Index address setting Figure 5.14. Index Address Setting Port (4006h) Index address setting When specifying the RS-485 setting with port 4007h, output 00h to this port before you specify the setting. (* Index addresses other than 00h are used by the system. Do not set addresses except for 00h.) * 4007h: Control of RS-485 transmission and reception RE_GATE TE_GATE TE_SEL...
  • Page 80 5. Each Component Function 0 : Controlled by RTS TE_SEL 1 : Controlled by TE_GATE 0 : Transmission prohibited 1 : Transmission permitted RX-(11) 0 : Transmission permitted TE_GATE RX+ (3) 1 : Transmission prohibited TX-(10) TX+ (2) 0 : Receiving permitted RE_GATE 47kΩ...
  • Page 81 5. Each Component Function (External circuit) Load (PO 0 - 2) External power 510Ω PC817 (Max. 30VDC) 2N3904 4.7kΩ (NCOM) RAS connector Figure 5.19. Output Circuit User’s Manual...

  • Page 82: Reset Switch

    5. Each Component Function To use the RAS-PRINTER bracket, set bits 6 and 6 in the S1 jumper to OFF (factory default). To use the SERIAL3-4 bracket, set bits 5 and 6 in the S1 jumper to ON instead. Do not modify the settings of S1 bits 1 - 4, 7 and 8 since they are used by the system. Figure 5.20.

  • Page 83: Ide Interface

    5. Each Component Function IDE Interface Connector for the Internal Drive (Primary IDE Connector) The BOX-PC is equipped with an E-IDE controller to allow a 2.5inch IDE hard disk to be connected to connector CN1 on the board. Table 5.27. Primary IDE Connector (CN6) Connector in use 44-socket header type (2mm pitch) Pin No.
  • Page 84 5. Each Component Function Secondary IDE Connector-CN2 Use the dedicated option cable to connect the option CD-ROM drive. The cable is not intended to connect devices (such as hard disks) other than CONTEC option products. Table 5.28. Secondary IDE Connector (CN2) Connector in use 40pin, half-pitch type (1.27mm pitch)

  • Page 85: Expansion Slots (Cp And C4P Model)

    5. Each Component Function Expansion Slots (CP and C4P Model) The CP model has two PCI bus expansion slots to hold PCI bus boards. The C4P model has four PCI bus expansion slots. Board Dimensions Allowed 240mm(Max.) Figure 5.21. Expansion Board Dimensions Note! A board that uses the back of the board edge connector (the shaded area in the figure) may not be mounted.

  • Page 86: Board Installation Procedure

    5. Each Component Function Board Installation Procedure 1. IPC-BX/M600(PCI)CP Be sure the power is turned off. Remove the top cover. Figure 5.22. Removing the Top Cover Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. Figure 5.23.
  • Page 87 5. Each Component Function Insert the board into the slot and fasten it with screws. Figure 5.24. Installation of an Expansion Board Note! Make sure carefully that the board has been secured in the slot. Install the PCB brace. It can hold down a board if its height is at least 68mm. Figure 5.25.
  • Page 88 5. Each Component Function Replace the expansion slot cover. Figure 5.26. Replacing the Top Cover User’s Manual...
  • Page 89 5. Each Component Function 2. IPC-BX/M600(PCI)C4P Be sure the power is turned off. Remove the top cover. Figure 5.27. Removing the Top Cover Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. PCB brace Figure 5.28.
  • Page 90 5. Each Component Function Insert the board into the slot and fasten it with screws. Figure 5.29. Installation of an Expansion Board Note! Make sure carefully that the board has been secured in the slot. Install the PCB brace. It can hold down a board if its height is at least 68mm. Figure 5.30.
  • Page 91 5. Each Component Function Replace the expansion slot cover. Figure 5.31. Replacing the Top Cover User’s Manual...

  • Page 92: Appendix

    6. Appendix 6. Appendix Memory Map FFFFFFF Expansion memory area 0100000 00FFFFF Main BIOS (128KB) 00E0000 00DFFFF Expansion ROM area (Free to the user) 00D0000 00CFFFF Reserved for BIOS 00CC000 00CBFFF VGA BIOS (48KB) 00C0000 00BFFFF Video RAM area (128KB) 00A0000 009FFFF (640KB)

  • Page 93: I/O Port Addresses

    6. Appendix I/O Port Addresses Table 6.1. I/O Port Addresses < 1 / 2 > ADDRESS(HEX) Description Remark 000-00F DMA controller 1 (slave) ch0 - 3 (8-bit transfer) 010-01F Reserved for system 020-03F Interrupt controller 1 (master) 040-05F Timer 060-06F Keyboard controller 070-07F RTC, NMI mask...

  • Page 94: Interrupt Level List

    6. Appendix Table 6.1. I/O Port Addresses < 2 / 2 > ADDRESS(HEX) Description Remark CF0-CFF Reserved for system 4000-4007 RAS functions 4008-400F Reserved for system 46E8 Reserved for system 83D0-B3D3 Reserved for system Interrupt Level List Table 6.2. Hardware Interrupt Levels (Factory Settings) Type 8259 Priority...
  • Page 95 6. Appendix User’s Manual...

  • Page 96: List Of Options

    7. List of Options 7. List of Options Memory for extension for extension (144pin SO-DIMM) - PC-MSD256-144V 256MB SD memory module Silicon disk drive for extension (IDE 2.5inch) [PCI Board Type] For IPC-BX/M630(PCI)CP,C4P - PC-RSD1000-PCI 1GB silicon disk drive - PC-RSD2000-PCI 2GB silicon disk drive - PC-RSD4000-PCI 4GB silicon disk drive...
  • Page 97 7. List of Options Floppy disk unit - PC-FDD25BH 3.5inch floppy disk drive (comes with a cable) Terminal block for connecting the RAS connector - IPC-PSD-20 Terminal block for connecting the RAS connector TFT color liquid-crystal display < Analog RGB types> - FPD-H21XT-AC (15inch 1024 x 768 dots, Panel...
  • Page 98 (http://www.contec.com/download) on the CONTEC web site. If you need IPC-SLIB-01 (CD-ROM version), it is available as a separately priced option. *3 Please Purchase an optional cable for connection [IPC-CDC-03]. * Check the CONTEC’s Web site for the latest information on these options. User’s Manual...
  • Page 99 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [10032008] [02202003] Management No. A-46-644 [10032008_rev9] Parts No.
