P-11
User Instruction Manual & Warranty
SUPPLIER: THIS MANUAL MUST BE GIVEN TO THE RIDER OF THIS WHEELCHAIR.
RIDER: BEFORE USING THIS WHEELCHAIR READ THIS ENTIRE MANUAL AND SAVE FOR FUTURE REFERENCE.
P-11
Mode d'emploi et garantie
FOURNISSEUR: CE MANUEL DOIT ÊTRE REMIS À L'UTILISATEUR / UTILISATRICE DE CE FAUTEUIL ROULANT.
UTILISATEUR / UTILISATRICE : AVANT D'UTILISER CE FAUTEUIL ROULANT, LISEZ ENTIÈREMENT CE MANUEL ET CON-
SERVEZ LE POUR LE CONSULTER ULTÉRIEUREMENT.
P-11
Manual de Instrucciones y Garantía para el Usuario
DISTRIBUIDOR: ESTE MANUAL DEBE SER ENTREGADO AL PASAJERO DE ESTA SILLA DE RUEDAS.
PASAJERO: ANTES DE USAR ESTA SILLA DE RUEDAS, LEA ESTE MANUAL EN SU TOTALIDAD Y GUÁRDELO
PARA FUTURA REFERENCIA.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quickie P-11

Summary of Contents for Quickie P-11

  • Page 1 P-11 User Instruction Manual & Warranty SUPPLIER: THIS MANUAL MUST BE GIVEN TO THE RIDER OF THIS WHEELCHAIR. RIDER: BEFORE USING THIS WHEELCHAIR READ THIS ENTIRE MANUAL AND SAVE FOR FUTURE REFERENCE. P-11 Mode d’emploi et garantie FOURNISSEUR: CE MANUEL DOIT ÊTRE REMIS À L’UTILISATEUR / UTILISATRICE DE CE FAUTEUIL ROULANT.

  • Page 2: Introduction

    I. INTRODUCTION SUNRISE LISTENS Thank you for choosing a Quickie wheelchair. We want to hear your questions or comments about this manual, the safety and reliability of your chair, and the service you receive from your Sunrise supplier. Please feel free to write or call us at the address and telephone num-...

  • Page 3: Table Of Contents

    I I . T a b l e o f C o n t e n t s E n g l i s h II. TABLE OF CONTENTS I. INTRODUCTION ................II. TABLE OF CONTENTS ............... III. YOUR CHAIR AND ITS PARTS............IV.
  • Page 4 I I . T a b l e o f C o n t e n t s E n g l i s h J. Seating Systems................K.Upholstery Fabric ................. L. Suspension.................. M.Wiring ..................VIII. SET UP, ADJUSTMENT & USE ............Notes ....................

  • Page 5: Your Chair And Its Parts

    5. Rear stabilizing caster 4" 6. Single plate foot platform 7. Semi-recline seat 8. 8" Drive wheels 9. Caster fork (front) 10. Caster fork (rear) 11. Shroud QUICKIE P-11 Weight Colors Armrest 51 lbs (base) Red, Blue, Champagne, Black Flip-back, height-adjustable 14" arm pad...

  • Page 6: Notice- Read Before Use

    I V . N o t i c e – R e a d B e f o r e U s e E n g l i s h IV. NOTICE– READ BEFORE USE A. CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS Sunrise provides a choice of many power wheelchair styles, sizes and adjustments to meet the needs of the rider.

  • Page 7: Emi (Electromagnetic Interference)

    V . E M I ( E l e c t r o m a g n e t i c I n t e r f e r e n c e ) E n g l i s h V.

  • Page 8: D.distance From The Source

    20 V/m immunity level will protect the power wheelchair user from the more common sources of radio waves. 3. The Quickie P-11 with the following configuration was tested and found to be immune to at least 20 V/m: Quickie P-11 power wheelchair with a right-hand mounted Penny & Giles VSI integral controller, contour seat, flip-back armrests, solid flip-up footplate and battery pack.

  • Page 9: General Warnings

    V I . G e n e r a l W a r n i n g s E n g l i s h VI. GENERAL WARNINGS Heed all warnings in this section. If you fail to do so a fall, tip-over or loss of control may occur and cause severe injury to you or others.

  • Page 10: Emi

    Red lights indicate batteries are in immediate need of charging. G. CHANGES & ADJUSTMENTS Never use non-Quickie parts or make changes to your chair unless authorized by Sunrise. (Doing so will void the Warranty and may create a safety hazard).

  • Page 11: Terrain

    V I . G e n e r a l W a r n i n g s E n g l i s h 2. Proceed slowly and use extra care if you must operate your chair on a wet or slick surface.

  • Page 12: N.transfers

    V I . G e n e r a l W a r n i n g s E n g l i s h To Reduce The Risk Of A Fall Or Tip-Over: 1. Consult your supplier for information on modifications authorized by Sunrise before you modify or adjust this chair.

  • Page 13: Dressing Or Changing Clothes

    V I . G e n e r a l W a r n i n g s E n g l i s h 3. Turn off all power to your chair. If you fail to do so, you may touch the joystick and cause your chair to move when you do not expect it.

  • Page 14: T To Reduce The Risk Of Falls, Tip-Over Or Loss Of Control

    V I . G e n e r a l W a r n i n g s E n g l i s h T. TO REDUCE THE RISK OF A FALL, TIP-OVER OR LOSS OF CONTROL 1. Never use your chair on a slope unless you are sure you can do so without losing traction.

  • Page 15: Stairs

    V I . G e n e r a l W a r n i n g s E n g l i s h 2. To prevent a fall or tip-over, use wheelchair access ramps or have someone help you. 3.

  • Page 16: Warnings: Components & Options

    C. CUSHIONS 1. Quickie Comfort seats are designed for comfort, not specifically for the relief of pressure. 2. If you suffer from pressure sores, or if you are at risk that they will occur, you may need a special seat system or a device to control your posture.

  • Page 17: Motor Locks

    V I I . W a r n i n g s : C o m p o n e n t s & O p t i o n s E n g l i s h F. MOTOR LOCKS 1.

  • Page 18: K.upholstery Fabric

    V I I . W a r n i n g s : C o m p o n e n t s & O p t i o n s E n g l i s h K. UPHOLSTERY FABRIC 1.

  • Page 19: Set Up, Adjustment & Use

    Quickie QTRONIX Programmer have your supplier reprogram your wheelchair as need- ed. Or, you can order a Quickie QTRONIX Pad for your own use, from your supplier. NOTE– Repeat this procedure until the chair performs to your specifications.

  • Page 20: A.battery Case Removal

    V I I I . S e t - u p , A d j u s t m e n t & U s e E n g l i s h A. BATTERY CASE REMOVAL (FIGURES 1 & 2) To remove the batteries for transporting or servicing: 1.

  • Page 21: D.armrests Adjustment

    V I I I . S e t - u p , A d j u s t m e n t & U s e E n g l i s h D. ARMRESTS ADJUSTMENT 1. Width Adjustment (Figure 6) a.

  • Page 22: H.shroud And Cover Removal

    V I I I . S e t - u p , A d j u s t m e n t & U s e E n g l i s h H. SHROUD AND COVER REMOVAL 1. Shroud Removal (Figure 11) The color shrouds are attached to the black plastic cover by Velcro and can be removed by gently pulling them off.

  • Page 23: Operating Guide

    Turn on power to the chair; program as needed. d. Remove plug and cycle ON/OFF switch to drive chair. NOTE– Review the Quickie QTRONIX Programmer Owner’s Manual for more details on how to program your chair. NOTE– Program settings that are not matched for the capabilities of the rider can result in serious injury.

  • Page 24: D.circuit Breakers

    Circuit 1. Notes: Breaker Your Quickie P-11 has a circuit breaker on the battery case. • In the unlikely event of a short circuit or heavy overload, all power to your chair will be shut off. • To reset your chair, depress the circuit breaker button located at the rear corner of the chair.

  • Page 25: Motor Locks

    I X . O p e r a t i n g G u i d e E n g l i s h F. MOTOR LOCKS Disconnect the motor locks when you need to manually push the chair. (For example, in an emergency, or if batteries fail). Do not disengage motor locks unless power to the chair is off.

  • Page 26: Batteries

    X . B a t t e r i e s E n g l i s h X. BATTERIES A. INTRODUCTION 1. Notes: • Batteries supply the power for your chair. They contain a finite amount of energy and have limits on how long they can store and supply energy.

  • Page 27: Acid Burns

    X . B a t t e r i e s E n g l i s h C. ACID BURNS (SEALED LEAD ACID BATTERIES) Acid in batteries is corrosive. If the battery pack is damaged or punctured, the acid inside can cause serious burns to the eyes and skin and can damage floors, furniture, clothing and your wheelchair.

  • Page 28: Charging Batteries

    X . B a t t e r i e s E n g l i s h E. CHARGING BATTERIES To avoid the risk of severe injury or death from electrical shock, fire or explosion while charging: 1. Never connect charger to a 240 volt source. The main input voltage is 110 volts. 2.

  • Page 29: Maintenance

    X I . M a i n t e n a n c e E n g l i s h XI. MAINTENANCE A. NOTES 1. Proper maintenance will improve performance and extend the useful life of your chair. 2. Clean your chair regularly. This will help you find loose or worn parts and will make your chair easier to use.

  • Page 30: To Repair Or Replace A Tire

    X I . M a i n t e n a n c e E n g l i s h E. TO REPAIR OR REPLACE A TIRE Drive Wheels: a. Elevate and securely support chair so that wheel is off the ground. b.

  • Page 31: Sunrise Limited Warranty

    X I I . S u n r i s e L i m i t e d W a r r a n t y E n g l i s h XII. SUNRISE LIMITED WARRANTY QUICKIE P-11 1. FOR FIVE YEARS We warrant the main frame of this wheelchair against defects in materials and workmanship for 5 years use of the first consumer purchaser.
