MAJESTIC OUTDOOR GAS FIREPLACE
Gas Types: Natural Gas (NG) or Propane (LPG)
Thank you for purchasing a Majestic Outdoor Gas Fireplace
1.
To operate and maintain this appliance safely and correctly, please read these instructions
thoroughly.
2.
This appliance must be installed in accordance with:
a. Local Gas Fitting Regulations
b. Municipal Building Codes
c. Australian Standard for Gas Appliance Installations AS/NZS5601.1:-2010
d. Any other relevant Statutory Regulation
e. Manufacturer‟s installation instructions
3.
This appliance must be serviced by a qualified person.
To suit Models:
ODGSR36ANAU & ODGSR36APAU
CUSTOMER INSTALLATION
OPERATING INSTRUCTIONS
AND
Page 1 of 20
Advertisement
Table of Contents
Summary of Contents for Raypak MAJESTIC ODGSR36ANAU
- Page 1 MAJESTIC OUTDOOR GAS FIREPLACE To suit Models: ODGSR36ANAU & ODGSR36APAU Gas Types: Natural Gas (NG) or Propane (LPG) CUSTOMER INSTALLATION OPERATING INSTRUCTIONS Thank you for purchasing a Majestic Outdoor Gas Fireplace To operate and maintain this appliance safely and correctly, please read these instructions thoroughly.
-
Page 2: Table Of Contents
CONTENTS For Your Safety General Information Installation Instructions General Information Fireplace Dimensions Clearance to Combustibles Mantels Mantel Chart Hearth Framing and Finishing Final Finishing Gas Specifications Gas Inlet and Burner Pressures High Elevations Valve Access Gas Fitting Line Installation Operating Instructions Log Installation Lava Rock First Firing... -
Page 3: For Your Safety
For Your Safety For your safety do not operate this appliance before reading this instruction book. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For assistance or additional information consult with Rheem Australia, your qualified installer or accredited Rheem Australia Service agency. WHAT TO DO IF YOU SMELL GAS? DO NOT try to light any gas appliance. -
Page 4: General Information
General Information FOR SAFE INSTALLATION AND OPERATION OF YOUR GAS APPLIANCE PLEASE NOTE THE FOLLOWING: a) This appliance gives off high temperatures and should be located out of high traffic areas and away from outdoor furniture and blinds or curtains. b) Children and adults should be alerted to the hazards of high surface temperatures of this appliance and should stay away to avoid burns or ignition of clothing. -
Page 5: Installation Instructions
Installation Instructions General Information The gas log fires must be installed by a licensed gas fitter in accordance with requirements set out in AS5601.1:2010 and any applicable building code regulations. The ODGSR Series are radiant gas log fires and are designed for outdoor installation only and must be located so it is protected from rain. - Page 6 See examples below of Outdoor Areas: Figure 1: Overall and framing dimensions. Page 6 of 20...
-
Page 7: Clearance To Combustibles
Clearance to Combustibles (Refer Figure 1) Top framing ……………………………………………………0 mm to standoff spacer Bottom……………………………………………………………0 mm Side framing …………………………………………………..0 mm to standoff spacer Back framing ………………………………………………….0 mm to standoff spacer Perpendicular Sidewall……………………………………..0 mm Top of unit to ceiling………………………………………..915 mm Front of unit to combustibles…………………………….915 mm Hearth A hearth is not mandatory but is recommended for aesthetic purposes. -
Page 8: Framing And Finishing
Figure 2a Figure 2b Framing and Finishing Warning: Check appliance to make sure it is levelled and properly positioned. The appliance should only be mounted on the following surfaces: A flat combustible (burnable) surface. A raised wooden platform. A concrete block or other solid object placed beneath each of the four corners of the appliance. To mount the appliance: Choose unit location. -
Page 9: Gas Specifications
Figures 2a and 2b. Gas Specification (always refer to appliance Data plate) GAS SPECIFICATION MODEL GAS TYPE Max Input Min Input CONTROL MJ/h MJ/h ODGSR36ANAU Millivolt Hi/Lo ODGSR36APAU Propane Millivolt Hi/Lo GAS INLET AND MANIFOLD PRESSURE kPa NATURAL PROPANE Min Supply Pressure 1.13 2.75... -
Page 10: Valve Access
Valve Access Valve can be accessed in one of two ways: 1. Remove the front panel just below the front of the hearth pan. This is accomplished by lifting on the panel. To replace the valve access panel line up the two pins with the holes in the surround bottom and push the panel over the hearth pan. -
Page 11: Operating Instructions
Operating Instructions Log Installation Warning: As with all plastic bags, these bags are not toys and should always be kept away from children and infants. 1. Remove logs from packaging. 2. Place left rear log on rear support. Ensure that log is firmly positioned and there is no side to side movement. -
Page 12: Flame Adjustment
Flame Adjustment For units equipped with Hi/Lo valves, flame adjustment is achieved by rotating the Hi/Lo adjustment knob located near the centre of the gas control valve. Figure 12 – SIT 820 Gas Control Knob Flame Characteristics It is important to periodically perform a visual check of the pilot and the burner flames (refer Figures 13 &... - Page 13 Page 13 of 20...
-
Page 14: Troubleshooting
Troubleshooting Nova SIT 820 Standing Pilot START CHECK Gas supply connected Gas Supply Shut off valve open Lockout has engaged. Wait 60 seconds and try again. Piezo not tight enough for good ground. For spark at electrode while depressing Piezo 1/8”... -
Page 15: Maintenance
Maintenance Burner and burner compartment It is important to keep the burner and the burner compartment clean. At least once a year the logs should be removed and the burner compartment vacuumed and wiped out. Remove and replace the logs as per the instructions in this manual. Always handle the logs with care as they are fragile and may also be hot if the fireplace is in use. -
Page 16: Parts List
Parts List Page 16 of 20... - Page 17 Where a failed component is replaced under this warranty, the balance of the original warranty period will remain effective. The replacement does not carry a new Raypak/Paloma warranty. c. Where the heater is installed outside the boundaries of a metropolitan area as defined by Rheem or further than 25km from either a regional branch office or an Accredited Rheem Service Agent‟s office, the cost of transport, insurance and travelling between the nearest...
- Page 18 If you require a call out and we find that the fault is not covered by Raypak/Paloma‟s warranty, you are responsible for our standard call out charge. If you wish to have the relevant components repaired or replaced that service will be at your cost.
- Page 19 Paloma/Rheem warranty (set out above) is in addition to any rights and remedies that you may have under the Australian Consumer Law.
-
Page 20: Service & Spare Parts
Rheem Australia has a service and spare parts network in all states. Our service network personnel are fully equipped to give the best service on your Raypak/Paloma gas heater. If your heater requires a repair or service please contact Rheem Service on 131 031.
